Summary of Contents for LSI MegaRAID Adapters Host Bus Adapters
- Page 1 LSI Logic Distribution Product Guide MegaRAID Adapters Host Bus Adapters...
- Page 2 ....9 • LSI Logic Ultra320 SCSI controllers first to full production, now shipping in volume ....10 •...
- Page 3 Retained Training Information (RTI). Integrated Mirroring‘ (RAID-1) of two Ultra320 SCSI hard drives provides "hot spare" capability. PCI SCSI host bus adapters, designed around LSI Logic’s innovative technologies and features sets, offer unparalleled performance, reliability and interoperability, a must for today’s I/O-intensive desktop, server and workstation environments.
- Page 4 Ultra320 MegaRAID Products LSI Logic was the first to offer advanced PCI SCSI RAID storage adapters with Ultra320 support. Backed by the technology for 64-bit addressing, a robust RAID feature set, and advanced memory and caching policies, LSI Logic’s Ultra320 MegaRAID solutions deliver enterprise-class data throughput and fault tolerant capabilities, plus easy-to-use management utilities –...
- Page 5 Ultra320 PCI-X MegaRAID Products LSI Logic’s MegaRAID solutions are available to support PCI-X 1.0 and, thus, address the need for increased bandwidth of PCI devices. With PCI-X, you can design systems and devices that operate at clock speeds up to 133 MHz or 1 GB/s. What’s more, PCI-X protocol enhancements enable devices to operate much more efficiently, providing more useable bandwidth at any clock frequency.
- Page 6 MegaRAID Express 500 Ultra160 MegaRAID Products MegaRAID Express Products MegaRAID Express 500 – most popular single-channel SCSI RAID controller in the world features powerful, advanced MegaRAID features at a very low cost. • High performance Intel i960 RISC I/O processor driving a single Ultra160 SCSI channel •...
- Page 7 What Is Serial ATA? With LSI Logic’s Serial ATA solutions, you can take advantage of an evolutionary replacement for the Parallel ATA physical storage interface. Serial ATA is scalable and allows future enhancements to the computing platform, with a roadmap expecting to span over 10 years.
- Page 8 MegaRAID ATA 133-2 MegaRAID i4 ATA MegaRAID Products LSI Logic ATA RAID products feature both non-processor and processor-based implementation to meet a wide range of entry-level and sub-entry-level server and performance workstation environments. MegaRAID ATA Products MegaRAID i4 – The cost-effective MegaRAID i4 offers the same advanced RAID functionality found in today’s high-performance PCI SCSI RAID solutions.
-
Page 9: Fibre Channel Host Bus Adapters
Fibre Channel Host Bus Adapters LSI Logic Fibre Channel Host Bus Adapters (HBAs) deliver a new level of reliability, speed and distance in interconnect technology. Designed with a low-profile PCI form factor, these adapters are available in cost-effective, single-channel models, ideal for workstations or entry-level servers, or in dual-channel models, for high-performance applications such as digital media, data warehousing or data mining. - Page 10 • 5 year limited warranty LSI21320 – The LSI Logic LSI21320 Ultra320 SCSI Dual Channel host adapter is ideal for use in high performance workstations and entry-level to mid-range servers. With 320 MBps and capability of up to 100,000 I/Os per second, this adapter is ideal for transferring high speed and high capacity data.
- Page 11 Ultra320 SCSI Host Bus Adapter Products LSI20320 – The LSI Logic LSI20320 Ultra320 SCSI Single Channel host adapter is the right choice for increasing internal storage performance within ISP, rackmount and high performance workstations. Designed for applications that don't require as many external connections, this cost effective solution gives you the performance you need, at a price that is right.
- Page 12 Ultra Value Line SCSI Host Bus Adapter Products LSI Logic SCSI host bus adapters deliver the performance and power that OEMs, VARs and system integrators depend on to keep data moving faster and more reliably. LSI Logic's SCSI HBAs feature SureLINK configuration of the SCSI bus and automatically tests and adjusts the SCSI transfer rate to optimize interoperability.
- Page 13 Ultra Value Line SCSI Host Bus Adapter Products LSIU40SE Value Line -- Ultra SE SCSI Host Adapter. This multi-function board provides two identical, independent, single-ended Ultra SCSI channels, for increased connectivity without utilizing additional PCI slots. The single board delivers a powerful dual- channel, multi-tasking interface for Ultra SCSI peripherals, including disk, tape, CD-ROM and other SCSI devices, in applications requiring SE connections.
- Page 14 Host Bus Adapter Solutions From LSI Logic Host Adapter Solutions from LSI Logic LSI Logic is a leader in the industry because of our engineering expertise and ability to combine a variety of I/O functions on a single Host Adapter. These functions include;...
- Page 16 LSI Logic; nor does the purchase, lease, or use of a product or service from LSI Logic convey a license under any patent rights, copyrights, trademark rights, or any other of the intellectual property rights of LSI Logic or of third parties.
