SecurView SV- 6915.IR.AS Installation Instructions

Hanging style rear view camera with night vision and auto shutter

Table of Contents

Download this manual

SHUTTER OPEN

The SV-6915.IR.AS is a hanging style Rear View Camera with Night Vision and an Automatic

shutter system which opens and closes as the vehicle is taken in and out of reverse. It can be

mounted up high on the back of the vehicle which makes it perfect for bigger vehicles such as

Semi Trucks, Motor Homes, Trailers, and Vans. It can also be mounted down low on the

vehicle, either on the bumper or under a license plate bezel if there is adequate space.

• Hanging style CMOS color camera

• 180° Viewing Angle

• Equipped with Infra Red LED for Night Vision

• Auto shutter system for lens protection (Opens automatically when camera is engaged)

• Optional Audio Input. Perfect for hooking up to a DVR system

• Perfect for Semi Trucks, Motor Homes, Buses, or Vans

• Normal Image built-in

• Durable Zinc Alloy Die Cast Body

• Swiveling lens shield to keep excess light out of camera lens

• Provides extra security when backing-up

• Waterproof Camera Design (IP68)

INSTALLATION INSTRUCTIONS:

SV- 6915.IR.AS

Hanging Style Rear View

Camera with Night Vision

and Auto Shutter

SHUTTER CLOSED

Table of Contents

Do you have a question about the SV- 6915.IR.AS and is the answer not in the manual?

Page 1: Installation Instructions
SV- 6915.IR.AS Hanging Style Rear View Camera with Night Vision and Auto Shutter SHUTTER OPEN SHUTTER CLOSED INSTALLATION INSTRUCTIONS: The SV-6915.IR.AS is a hanging style Rear View Camera with Night Vision and an Automatic shutter system which opens and closes as the vehicle is taken in and out of reverse. It can be mounted up high on the back of the vehicle which makes it perfect for bigger vehicles such as Semi Trucks, Motor Homes, Trailers, and Vans.
Page 2: Side View
INSTALLATION INSTALLATION PRECAUTIONS: 1. The Securview™ SV-6915.IR.AS is designed to be mounted up high on the vehicle. Make sure there will be adequate space to mount the camera. 2. Make sure to double check that the camera will not be blocking any brake lights or turn signals on the vehicle.
Page 3 WIRING: 1. Carefully choose a hidden out-of-sight location for drilling the cable hole. Some vehicles may have an existing hidden rubber grommet or plug available to avoid having to drill into the body. Be sure to double-check for any wiring or obstructions behind the surface where you are going to drill the cable hole.
Page 4 SPECIFICATIONS: 1/4 Color CMOS Sensor Video Output: 1.0 V P-P composite (75 Ohm load) Dimension (In.): 3¼"(L) × 4⅜"(W) × 2⅞"(D) Supply Voltage: +12VDC Power Consumption: 250mA with Night Vision Electronic Shutter: 1/50(1/60) s – 1/100000s Weight: 22 Oz. White Balance: Automatic Pixels: NTSC: 510 (H) x 496 (V) Gamma Correction: 0.45 PAL:...
