SecurView SV-6704.IR Installation Instructions

Flush mount camera with night vision

Table of Contents

Download this manual

The SV-6704.IR is a bumper-fit flush-mount camera with night vision that can be installed

almost anywhere on the body of the vehicle as long as there is adequate space behind the

mounting surface to fit it into place.

Since the SV-6704.IR is a flush mount camera, a small hole must be drilled for installation. A

hole saw bit is included in the kit to help assist you in the installation process for drilling this

hole.

• Flush Mount design gives the camera a factory look.

• Reverse Image built-in

• Perfect for Vehicle Owners that want to keep the vehicle looking factory with no

aftermarket equipment.

• The 170° ultra wide-angle CMOS color camera provides rear images in real time and

eliminates the dangerous "blind-spot" directly behind your vehicle when backing up.

• Includes Hole Saw bit for installation.

• Easily connects with other SecurView products such as any of the LCD monitors. It can

also be integrated with your existing OEM or aftermarket LCD/TFT displays.

• Waterproof Design (IP68)

INSTALLATION INSTRUCTIONS:

SV-6704.IR

Flush Mount Camera

with Night Vision

Table of Contents

Do you have a question about the SecurView SV-6704.IR and is the answer not in the manual?

Page 1: Installation Instructions
SV-6704.IR Flush Mount Camera with Night Vision INSTALLATION INSTRUCTIONS: The SV-6704.IR is a bumper-fit flush-mount camera with night vision that can be installed almost anywhere on the body of the vehicle as long as there is adequate space behind the mounting surface to fit it into place.
Page 2: Camera Installation
INSTALLATION MOUNTING: 1. The Securview™ SV-6704.IR Rear Vision System uses a wide-angle lens for best all around performance. The Camera will display the full width of most parking spaces up to 7 feet or even wider. 2. The SV-6704.IR is designed to be flush mounted on vehicle’s surface. It can be mounted anywhere on the vehicle that has a flat surface.
Page 3 WIRING: 1. Once you have drilled the hole in the outer body to mount the camera, route the RCA wires and power harness through the hole. Find a place behind the mounting surface to secure the wires so that they do not move around freely. 2.
Page 4 Federal Motor vehicle codes with regards to modifications of vehicle license plates. The manufacturer of the Securview™ assumes no liability or responsibility whatsoever with regards modifications of the license plate. www.crimestopper.com email@crimestopper.com Phone (800) 998-6880 FAX (805) 581-9500 © 2011 Crimestopper Security Products 3-1-2011...
