Procomp BIW1A Series User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

BIW1A
series
Safety and Regulatory Information
FCC Part 15: This equipment has been tested and found to comply with
the limits for a class B digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and
can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio
communications. However, this notice is not a guarantee that interference
will not occur in a particular installation.
CAUTION: To comply with the limits for the class B device, pursuant
to Part 15 of the FCC Rules, this device must be installed in computer
equipment certified to comply with the Class B limits.
All cables used to connect the computer and peripherals must be shielded and
grounded. Operation with non-certified computers or non-shielded cables
may result in interference to radio or television reception.
Any changes or modifications not expressly approved by the grantee of
this device could void the user' s authority to operate the device.
COPYRIGHT: This publication, including all photographs, illustrations
and software, is protected under international copyright laws, with all rights
reserved. Neither this manual, nor any of the material contained herein, may
be reproduced without the express written consent of the manufacturer.
DISCLAIMER: The information in this document is subject to change
without notice. The manufacture makes no representations or warranties with
respect to the contents hereof and specifically disclaims any implied
warranties of merchantability or fitness for any particular purpose.
Notice for the USA
~0~

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BIW1A Series and is the answer not in the manual?

Questions and answers

Related Manuals for Procomp BIW1A Series

Summary of Contents for Procomp BIW1A Series

  • Page 1 BIW1A series Safety and Regulatory Information Notice for the USA FCC Part 15: This equipment has been tested and found to comply with the limits for a class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 2: Table Of Contents

    BIW1A series TABLE OF CONTENTS CH1. MOTHERBOARD FEATURE ............. 2 1.1 ABOUT THE MANUAL ............4 1.2 SPECIFICATIONS............. 5 1.3 DIFINITION OF BVC1A MODEL ....... 7 series 1.4 POWER OFF CONTROL SOFTWARE ......7 1.5 PACKAGING CHECK LIST..........8 CH2. SETUP GUIDE................9 2.1 MOTHERBOARD LAYOUT..........

  • Page 3: Ch1. Motherboard Feature

    BIW1A series Chapter 1 Motherboard Feature Introduction Based on Intel’ s 810 GMCHset & ICH (82810-DC100 + 82801) chipsets, the BIW1A is an advanced motherboard that comes with onboard audio and video capabilities, an audio modem riser slot, a 4MB BIOS that includes built-in anti-virus protection and UltraDMA/66 technology for lightning-fast IDE transfer speeds.
  • Page 4 BIW1A series speed configurations are automatically set through the board’ s firmware, which means changing switch or jumper settings on the motherboard is not necessary. High Performance - The board has two DIMM sockets for the installation of 168-pin, 3.3V non- buffered DIMM memory modules.

  • Page 5: About The Manual

    BIW1A series motherboard header to add in an infrared port. In addition, the motherboard has two PCI-IDE channels and a floppy disk drive interface. ACPI Ready - APCI (Advanced Configuration and Power Interface) technology provides for more energy saving functions for future operating systems supporting OS Director Power Management (OSPM) functionality.

  • Page 6: Specifications

    BIW1A series 1.2 SPECIFICATIONS Intel 810 GMCHset & ICH (82810-DC100 + 82801) Chipset solution. Socket 370 Support. Processor Intel Celeron processor 300MHz ~ 500MHz and higher. PCI/ISA. Architecture Clock Generator 66.8, 68.3, 70, 75, 100 up to 150 MHz. 2 x 168 pin DIMM Sockets Support Maximum Memory Size to 512 MB SDRAM DRAM Modules PC100 SDRAM.
  • Page 7 BIW1A series 1 x Digital Video. 1 x Floppy port (up to 2.88MB, 3 mode floppy supported & LS-120). 2 x Serial ports. 1 x Parallel port (SPP/EPP/ECP). On Board I/O 2 x USB. 1 x PS/2 mouse. 1 x PS/2 keyboard. 1 x IrDA.

  • Page 8: Model

    BIW1A series 1.3 DEFINITION OF BIW1Aseries MODEL BIW1A have different function for meeting customer demand. When you series purchase the motherboard of BIW1A you just follow below description to series know which extra function you have. 1. Find the model of BIW1A you have purchased.

  • Page 9: Packaging Check List

    BIW1A series Note: BIOS Setup. Please refer the “Chapter 3 Award BIOS Setup” PS_BT In Windows 98/95, under the “SHUT DOWN” option, the computer’ s power will switch off automatically and put the PC in a suspend mode. This will be indicated by a blinking power light. To restart the system, simply press the Power Button.

  • Page 10: Ch2. Setup Guide

    BIW1A series Chapter 2 Setup Guide 2.1 Motherboard layout...

  • Page 11: Connector & Jumper Reference Chart

    BIW1A series 2.2 Connector & Jumper Reference Chart T : Mouse B : K/B USB 1/2 Socket 370 T : LPT1 B: COM1 Intel T: Game Port 810 GMCH CPU FAN B: Audio Port Battery COM2 CD-IN PCI 1 PCI 2 FAN2 PCI 3 FAN3...

  • Page 12: The Setup Steps

    BIW1A series 2.3 The setup steps Please refer to the following steps to setup your computer: Refer to the Jumper Setup section to set up the jumpers correctly. Install the DIMM modules on the motherboard; be sure to set up safely.
  • Page 13 BIW1A series PS/2 Mouse Connector Color : Green ; Panton : 3395C This connector can connect PS/2 Mouse and has better performance. Description Description Mouse Data N.C. Ground Mouse Clock ATX Power Supply Connector This connector allows the motherboard to draw the power form ATX power supply.
  • Page 14 BIW1A series Printer Connector Color : Burgundy ; Panton : 235C This Connector can transfer the data to printer for printing on paper. Signal Name Signal Name Strobe- Data Bit 0 Error Data Bit 1 INIT Data Bit 2 SLCTIN Data Bit 3 Data Bit 4 Data Bit 5...
  • Page 15 BIW1A series COM1–Serial Connectors Color : Turquoise ; Panton : 322C These connectors allow mouse or the other device which use this type connector for transferring data between computer and devices. Signal Name Signal Name SOUT VGA – VGA Out Connector Color : Blue ;...
  • Page 16 BIW1A series USB- Universal Serial Bus (USB1, USB2) Connectors Color : Black ; Panton : 426C These connectors allow the device which use this type connector for transferring information between computer and devices. USB1 Pin Signal Name USB2 Pin Signal Name USB VCC 0 USB VCC 1 USB Data -...
  • Page 17 BIW1A series IrDA - Infrared Connector: IR This connector is used to connect IR Device. Signal Name SIRRX IRTX WOL – Wake-up On LAN Connector This connector is used to connect an add-in NIC ( Network Interface Card ) which gives WOL function to the motherboard. Enable this function for remotely managing PC on a network.
  • Page 18 BIW1A series CD-IN: CD audio Connector This connector is used to connect CD-ROM audio output to motherboard, through this, the CD audio can output to audio chip directly. Description Left Ground Ground Right JP1: Jump for Cyrix CPU This jump only is reserved for Cyrix CPU, but the Cyrix CPU is not available yet.
  • Page 19 BIW1A series JP3 – CMOS Clear This jumper is able to clear the current data stored in the CMOS memory. Description Normal (default) Clear CMOS JP4 – On Board AC97 Sound Switch This jumper is able to Open/Close the on board sound function. Description Disable Enable (Default)
  • Page 20 BIW1A series JP6 – Password Power on Jump Select This jumper is able to Open/Close the Power On by Password function. Your system will be under security, when you use this function. (When you want to use this function, you should check the Integrated Peripherals of BIOS utility is setup firstly.) Description Enable (Default)
  • Page 21 BIW1A series PANEL CONNECTORS SETTING Locate the bank of switch and indicator connectors. These connectors provide control functions to your system case. Such as Speaker, HD LED, Power LED, Key Lock, SMI Switch, SMI ED and Reset … etc. Please use the cable below to make the connections.
  • Page 22 BIW1A series FAN1, FAN2, FAN3 - FAN CONNECTORS These connectors allow the fans of CPU and system to draw the power from the motherboard. SYS-FAN CPU FAN (FAN2, FAN3) Fan Out Fan Out FAN1 : CPU FAN CONNECTOR. FAN2 : For SYSTEM COOL FAN CONNECTOR. FAN3 : For SYSTEM COOL FAN CONNECTOR.

  • Page 23: Memory Installation

    BIW1A series you to find the CPU type. The Clock Frequency is 66 by default. But you can change the frequency in the BIOS Setup, so you can refer 3.3 - Chipset Features setup of ® Chapter 3. That’ s mean Even if your Intel Pentium CPU doesn't support an external bus speed of 100MHz, you can still set your motherboard's external bus speed to 100MHz.
  • Page 24 BIW1A series How to Install DIMM Modules on Motherboard 1. The SDRAM sockets are keyed with notches and the DIMMs are keyed with cut-outs so that they cannot be installed incorrectly. Check that the cut-outs on the DIMM edge connector match the notches in the SDRAM socket.
  • Page 25 BIW1A series NOTE: Samples of System Memory Combinations Options DIMM1 DIMM2 TOTAL ------ 8MBytes ------ 8MBytes 16MBytes ------ 16MB 16MBytes 16MB ------ 16MBytes 16MB 24MBytes 16MB 24MBytes 16MB 16MB 32MBytes 32MB ------ 32MBytes ------ 32MB 32MBytes 32MB 40MBytes 32MB 32MB 64MBytes ------ 64MB...

  • Page 26: How To Install The Cpu

    BIW1A series 2.3-3 How to install the CPU Prepare the motherboard by installing the supplied CPU-Socket 370, then install the CPU according to the instructions supplied. Complete the processor installation by installing the supplied heat-sink support, and connecting the heat sink power cable to the motherboard connector. Referential Steps of installing the Socket 370 CPU This section is only for CPU installation, the motherboard in the picture is not the BIW1A...
  • Page 27 BIW1A series 3. Locate Pin 1 in the socket and look for the cut edge in the CPU, match Pin 1 with the cut edge then insert the CPU. It should be inserted easily. Cut edge Socket 370 4. Press the lever down to lock the CPU into the socket. Note: Regarding the heatsink installation, please refer to the...

  • Page 28: Installing The Motherboard

    BIW1A series CPU & Power Supply Fan Connectors (3-pin FanPWR) These connectors support cooling fans of 500mAMP (6 watts) or less. Position the fans so that the heat-sink fins allow the airflow to go across the onboard heat-sink(s) instead of the expansion slots. Depending on the fan manufacturer, the wiring and plug may be different.

  • Page 29: Installing The Interface Card

    BIW1A series 2.3-5 Installing the interface card This section explains how to install new interface cards on your motherboard. It covers installing ISA cards and PCI cards. There are five expansion card slots on the motherboard, four PCI slots and one ISA slots.(BIW1A-Ionly) When you get an expansion card, it will come with instructions on how to install it, so this section covers relevant information for the motherboard only.

  • Page 30: Installing Accessory Cables

    BIW1A series 2.3-6 Installing Accessory Cables This section describes how to connect the accessory cable that motherboard or system housing supports. In the case of ATX, there is no need to use a bracket to extend the connectors to the rear panel, so here we will discuss only the installation instructions for Floppy, IDE.
  • Page 31 BIW1A series Floppy Cable The floppy cable for floppy drives is a 34-pin flat cable with 5 connectors classified as follows: 1. Female header (For floppy connector onboard) 2. Female header and Edge connector (For driver B) 3. Female header and Edge connector (For driver A) The end-most connector cable is twisted to support floppy drive A, while the middle connectors are for floppy drive B.

  • Page 32: Ch3. Award Bios Setup

    BIW1A series Chapter 3 Award BIOS Setup This chapter explains how to use and modify the BIOS setup utility that is stored on the motherboard. The setup utility stores information about the motherboard components, and the configuration of other devices that are connected to it.

  • Page 33: Control Keys

    BIW1A series When an option is highlighted, you can execute the option by pressing the Enter key. Some options lead to dialog boxes which ask you verify that that you wish to execute that option. You usually answer these dialogs by typing Y for yes and N for no.

  • Page 34: The Main Menu

    BIW1A series 3.1 The Main Menu Once you enter Award BIOS CMOS Setup Utility, the Main Menu will appear on the Screen.. Use arrow keys to select among the items and press to accept or enter the sub-menu. Some options lead to tables of items. These items usually have a value on the right side.
  • Page 35 BIW1A series Advanced Chipset Features This setup page includes all the items of chipset special features. Integrated Peripherals This section page includes all the items of IDE hard drive and Programmed Input / Output features. Power Management Setup This menu provides functions for Green products by allowing users to set the timeout value for monitor and HDD.

  • Page 36: Standard Cmos Setup

    BIW1A series 3.2 Standard CMOS Setup The item in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or <PgDn>...
  • Page 37 BIW1A series cannot be automatically detected, you can use these items to select USER, and then manually enter the characteristics of the drive. The documentation provided with your drive provides the data you need to fill in the values for CYLS (cylinders), HEAD (read/write heads), and so on.

  • Page 38: Advanced Bios Features Setup

    BIW1A series 3.3 Advanced BIOS Features This section allows you to configure your system for basic operation. You have the opportunity to select the system’ s default speed, boot-up sequence, keyboard operation, shadowing and security. CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Advanced BIOS Features Anti-Virus Protection Enabled...
  • Page 39 BIW1A series Enabled : Activates automatically when the system boots up, if anything attempts to access the boot sector or hard disk partition table will cause a warning message to appear. Disabled : No warning message will appear when anything attempts to access the boot sector or hard disk partition table.
  • Page 40 BIW1A series Boot Up Floppy Seek Default: Disabled During POST, BIOS will determine if the Floppy disk drive installed is 40 or 80 tracks. 360 K type is 40 tracks while 720K, 1.2M and 1.44M drive type as they are all 80 tracks. Enabled: BIOS searches for floppy disk drive to determine if it is 40 or 80 tracks.

  • Page 41: Advanced Chipset Features Setup

    BIW1A series 250 msec 500 msec 750 msec 1000 1000 msec Security Option Default: Setup If you have installed password protection, this item defines if the password is required at system start up, or if it is only required when a user tries to enter the setup utility.
  • Page 42 BIW1A series CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Advanced Chipset Features SDRAM CAS Latency Time Item Help SDRAM Cycle Time Tras/Trc SDRAM RAS-to-CAS Delay Menu Level SDRAM RAS Precharge Time System BIOS Cacheable Enabled Video BIOS Cacheable Enabled Memory Hole At 15M-16M Disabled...
  • Page 43 BIW1A series installed in the system. System BIOS Cacheable Default: Enabled Selecting Enabled allows caching of the system BIOS ROM at F0000h- FFFFFh, resulting in better system performance. However, if any program writes to this memory area, a system error may result. Video BIOS Cacheable Default: Enabled Select Enabled allows caching of the video BIOS , resulting in better system...

  • Page 44: Integrated Peripherals

    BIW1A series RAS# Precharge Timing Default:Fast This item controls RAS# precharge (in local memory clocks). 3.5 Integrated Peripherals This option displays a list of items which defines the operation of some peripheral items on the system's input/output ports. CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Integrated Peripherals OnChip Primary PCI IDE Enabled...
  • Page 45 BIW1A series On-Chip Primary/Secondary PCI IDE Default: Enabled This setup item allows you to either enable or disable the primary/secondary controller. You might choose to disable he controller if you were to add higher performance or specialized controller.. IDE Primary/Secondary Master/Slave Default: Auto The four IDE PIO (Programmed Input/Output) fields let you set a PIO mode (0-4) for each of the four IDE devices that the onboard IDE interface supports.
  • Page 46 BIW1A series POWER ON Function Default: BUTTON ONLY The Power On Function item allows you to power on the system by pressing hot-keys. If you set this item to Hot Key, you can use the item Hot Key Power On to choose which hot keys are installed.If you set this item to Password, you can use the item KB Power On Password to choose which password are installed.

  • Page 47: Power Management Setup

    BIW1A series 3.6 Power Management Setup CMOS Setup Utility – Copyright © 1984 – 1998 Award Software Power Management Setup ACPI function Enabled Item Help ACPI Suspend S1(POS) Power Management User Define Menu Level Video Off Method DPMS Video Off In Suspend Suspend Type Stop Grant MODEM Use IRQ...
  • Page 48 BIW1A series User Allows you to set each mode individually. Defined When not disabled, each of the ranges are from I min. to I hr. except for HDD Power Down which ranges from I to 15min. and disable If you would like to use Software Power-off Control function, you cannot choose"...
  • Page 49 BIW1A series off. If the value is set to Delay 4 Sec. the power button must be held down for a full four seconds to cause a software power off. PowerOn by Ring Default: Disabled Enabled: when system in suspend mode, it can be wake up by modem. Disabled: it cannot be wake up by modem.

  • Page 50: Pnp/Pci Configuration Setup

    BIW1A series 3.7 PNP/PCI Configuration Setup The PNP/PCI Configuration Setup allows you to configure the ISA and PCI devices installed in your system. The following screen appears if you select the option PNP/PCI Configuration setup from the main menu. CMOS Setup Utility – Copyright © 1984-1998 Award Software PnP/PCI Configurations PnP OS Installed Item Help...

  • Page 51: Pc Health Status

    BIW1A series requires a special IRQ and DMA, you can modify the list of assignments. Change the values of the IRQ and DMA that are required to Legacy ISA. IRQ 3/4/5/7/9/10/11/12/14/15 DMA 0/1/3/5/6/7 (BIW1A-I Only) This item allows you to determine the IRQ/DMA assigned to the ISA bus and is not available to any PCI slot.

  • Page 52: Frequency/Voltage Control

    BIW1A series CPU Warning Temperature Default: Disabled When this item is enabled, we can set the CPU warning temperature . If the CPU temperature is higher than the setting temperature, the system will beep. Current System Temp. This field displays the current system temperature. Current CPU1 Temperature It shows the current CPU temperature.

  • Page 53: Load Fail-Safe Defaults

    BIW1A series Spread Spectrum Modulated Default: Disabled Enable / Disable this item the BIOS will Enable / Disable the clock generator spread spectrum . CPU/SDRAM/PCI Clock Default: Default This item allows you to select the CPU/SDRam/PCI frequency.We recommend that you leave this item at the default value. CPU Clock Ratio Default: X 3 This item allows you to select the CPU frequency.

  • Page 54: Save And Exit Setup Option

    BIW1A series To install a Supervisor or User Password, follow these steps: 1. Highlight the item Supervisor/User password on the main menu and press Enter. 2. The password dialog box will appear. 3. If you are installing a new password, carefully 4W in the password. You cannot use more than 8 characters or numbers.

  • Page 55: Ch4. Software Setup

    BIW1A series Chapter 4 Software Setup The support software for this motherboard may be supplied on a CD- Title, or it may be supplied on diskettes. All the support programs are stored in separate folders, so you can find the program you need easily enough. The support software contains the following programs: "...
  • Page 56 BIW1A series 3. Press “Intel Chip” button. Intel Chip button 4. Press “Win9x INF Update for Bus Master” and follow the instructions to this software. Then Re-boot your PC. Win9x INF Update for Bus Master button 5. Click Next when the Welcome screen appears. 6.

  • Page 57: Installing The Intel 810 Vga Driver

    BIW1A series 4.2 Installing the Intel 810 VGA Driver According the follow steps for Intel 810 graphics driver installation: Turn on your PC then put the “CD title” into your CD-ROM drive. (Please make sure it’ s under Win98/95 mode) The CD title will be auto-run.

  • Page 58: Installing The Adi 1881 Audio Driver

    BIW1A series Follow the instructions to complete the software installation, then re-boot your PC. 4.3 Installing the ADI 1881 Audio Driver According the follow steps for ADI 1881 audio driver installation: Turn on your PC then put the “CD title” into your CD-ROM drive. (Please make sure it’...
  • Page 59 BIW1A series 5. Press “Win 98 [WDM]” button. Win 98 [WDM] button Note: If your O.S. is Win95, please press “Win95 [Vxd] & Win95 Wavetable” button to install the audio driver. 6. Follow the instructions to complete the software installation, then re-boot your PC.
  • Page 60 BIW1A series ~59~...
  • Page 61 BIW1A series This page was intentionally left blan ~60~...
  • Page 62 BIW1A series This page was intentionally left blank ~61~...
