Contents
CH1. MOTHERBOARD FEATURE...........................................................1
!SPECIFICATIONS ..........................................................................1
!POWER OFF CONTROL SOFTWARE .........................................3
!PACKAGING CHECK LIST ..........................................................3
CH2. SETUP GUIDE ....................................................................................4
!MAINBOARD LAYOUT DRAWING ...........................................4
!JUMPER & CONNECTOR SETTING ...........................................5
CONNECTOR SETTING ...............................................................5
JP7 OTHER JUMPER SETTING ..................................................8
CPU TYPE SELECT ......................................................................9
FAN CONNECTOR .....................................................................14
!MEMORY INSTALLATION........................................................15
CH3. AWARD BIOS SETUP......................................................................16
!THE MAIN MENU .......................................................................18
!STANDARD CMOS SETUP ........................................................20
!BIOS FEATURES SETUP ............................................................21
!CHIPSET FEATURES SETUP .....................................................27
!POWER MANAGEMENT............................................................28
!PNP / PCI CONFIGURATION SETUP ........................................34
!INTEGRATED PERIPHERALS ...................................................36
!LOAD BIOS DEFAULT ...............................................................37
!LOAD SETUP DEFAULT ............................................................37
!SUPERVISOR / USER PASSWORD SETTING..........................37
!IDE HDD AUTO DETECTION....................................................38
CH4. SOFTWARE SETUP.........................................................................39
✒ P
®
II CPU I
ENTIUM
REMARK
®
INTEL
is a registered trademark of Intel Corporation.
All other brands and product names are trademarks registered trademarks of their
respective companies.
CONTENTS
G
NSTALLATION
i
...........................................P-1
UIDE
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Procomp B785
Summary of Contents for Procomp B785
-
Page 1: Table Of Contents
Contents CONTENTS CH1. MOTHERBOARD FEATURE............1 !SPECIFICATIONS ................1 !POWER OFF CONTROL SOFTWARE .........3 !PACKAGING CHECK LIST ............3 CH2. SETUP GUIDE ..................4 !MAINBOARD LAYOUT DRAWING ...........4 !JUMPER & CONNECTOR SETTING ...........5 CONNECTOR SETTING ...............5 JP7 OTHER JUMPER SETTING ..........8 CPU TYPE SELECT ..............9 FAN CONNECTOR ..............14 !MEMORY INSTALLATION............15 CH3. -
Page 2: Specifications
B785 Chapter 1 Motherboard Feature Introduction SPECIFICATIONS ® Intel 440BX chip set , ALi 513X System Chipset ® Pentium /III 66/100 MHz CPU CPU Bus Speed 200MHz ~ 550MHz CPU Clock Expandable to 768MB(3 banks) with 168-Pin Memory Subsystem SDRAM(DIMM) Socket X3 AGP Interface Specification Rev 1.0 Compliant... - Page 3 B785 2MB Award PnP BIOS with enhanced ACPI feature for PC98 compliance. Supports Trend ™ ChipAway AntiVirus. BIOS DMI feature support Support secondary device boot Three 32-bit PCI Slots & One 16-bit ISA Slots Expansion slot Support 3.3/5V PCI 2.1 bus Interface...
-
Page 4: Power Off Control Software
The motherboard comes securely packed in a gift box and shipping carton. If any of the above items are missing or damaged , please contact your supplier. The motherboard contains: Q’ TY Description Motherboard : B785 Driver : CD-Title Cable : FDD. IDE. Connector Manual... - Page 5 B785 Chapter 2 Setup Guide Motherboard Layout Drawing T: Mouse CPU Fan B: K/B U S B 1/2 T: LPT1 B:COM1 COM2 T: Game Port 5135SIR B: Audio Port JSB1 Battery PCI 1 PCI 2 JWOL1 PCI 3 Connector Front View...
-
Page 6: Jumper & Connector Setting
B785 Jumper & Connector Setting CONNECTOR SETTING PS1- Keyboard Connector Description Keyboard Data Keyboard CLK Mouse Data N.C. Ground Mouse Clock J88 - ATX Power Supply Connector Description 1,2,11 + 3.3 V 3,5,7,13,15,16,17 Ground 4,6,19,20 + 5 V POWER GOOD... - Page 7 B785 LPT1 - Printer Connector Signal Name Signal Name Strobe- Data Bit 0 Error Data Bit 1 INIT Data Bit 2 SLCTIN Data Bit 3 Data Bit 4 Data Bit 5 Data Bit 6 Data Bit 7 Busy SLCT COM1,COM2 –Serial Connectors...
- Page 8 B785 J3 - Universal Serial Bus (USB) Connectors USB1 Pin Signal Name USB2 Pin Signal Name USB VCC 0 USB VCC 1 USB Data - USB Data - USB Data + USB Data + USB GND 0 USB GND 1...
-
Page 9: Jp7 Other Jumper Setting
B785 J7 – OTHER JUMPER SETTING SPEAKER PWR_LED KEYLOCK EXTSMI SUS_LED HD_LED PB_BT Name Description EXTSMI Suspend mode SUS _ LED Suspend mode LED 13-15 PB _ BT Power buttem 23-25 HD – LED Hard Disk LED SPEAKER Speaker 12-14... -
Page 10: Cpu Type Select
B785 CPU TYPE Select CPU Bus Speed - 66MHz part : 1. 233MHz Short Open Open Short Short Short JP1 JP2 JP3 2. 266MHz Short Short Short Open Short Short JP1 JP2 JP3 3. 300MHz Short Open Short Open Short Short... - Page 11 B785 4. 333MHz Short Short Open Open Short Short JP1 JP2 JP3 5. 366MHz Short Open Open Open Short Short 6. 400MHz Open Short Short Short Short Short...
- Page 12 B785 7. 433MHz Open Open Short Short Short Short 8. 466MHz Open Short Open Short Short Short 9. 500MHz Open Open Open Short Short Short...
- Page 13 B785 CPU Bus Speed - 100MHz part : 1. 300MHz Short Short Open Short Open Short JP1 JP2 JP3 2. 350MHz Short Open Open Short Open Short JP1 JP2 JP3 3. 400MHz Short Short Short Open Open Short JP1 JP2 JP3...
- Page 14 B785 4. 450MHz Short Open Short Open Open Short JP1 JP2 JP3 5. 500MHz Short Short Open Open Open Short JP1 JP2 JP3 6. 550MHz Short Open Open Open Open Short JP1 JP2 JP3...
-
Page 15: Fan Connector
B785 CPU TYPE SELECTION LIST JP1~JP5 (For RATIO select) RATIO Short Short Open Short Short Open Open Short Short Short Short Open Short Open Short Open Short Short Open Open Short Open Open Open JP6 (For BUS clock) CLOCK 66 MHz... -
Page 16: Memory Installation
B785 MEMORY INSTALLATION No jumper setting is necessary for DRAM setting, BIOS will check DRAM type and size automatically. This motherboard contains 2 by 168-pin DIMM socket (DIMM1, DIMM2, DIMM3). This motherboard has table-free ( or auto-bank ) feature and user can install DIMM into any bank. - Page 18 B785 Chapter 3 Award BIOS Setup Award BIOS ROM has a built-in Setup program that allows users to modify the basic system configuration. This type information is stored in battery-backed RAM so that it retains the Setup information when the power is turned off.
- Page 19 B785 Right Arrow Move to the item in the right hand Esc Key Main Menu Quit and not to save changes to CMOS Status Page setup menu and Option Page Setup Menu Exit current page and return to Main Menu...
-
Page 20: The Main Menu
B785 The Main Menu Once you enter Award BIOS CMOS Setup Utility, the Main Menu will appear on the Screen.. Use arrow keys to select among the items and press to accept or enter the sub-menu. ROM PC/ISA BIOS (2A69KPNH) CMOS SETUP UTILITY AWARD SOFTWARE, INC. - Page 21 B785 Power Management Setup This menu provides functions for Green products by allowing users to set the timeout value for monitor and HDD. PNP / PCI CONFIGURATION SETUP This menu allows the user to modify PNP / PCI configuration function.
-
Page 22: Standard Cmos Setup
B785 Standard CMOS Setup The item in Standard CMOS Setup Menu are divided into several categories. Each category includes no, one or more than one setup items. Use the arrow keys to highlight the item and then use the <PgUp> or... -
Page 23: Bios Features Setup
B785 BIOS Features Setup ROM PCI/ISA BIOS (2A69KPNH) BIOS FEATURE SETUP AWARD SOFTWARE, INC Anti-Virus Protection : Enabled Video BIOS Shadow : Enabled CPU Internal Cache : Enabled C8000-CBFFF Shadow : Disabled External Cache : Enabled CC000-CFFFF Shadow : Disabled... - Page 24 B785 Enabled Activate automatically when the system boots up causing a warning message to appear when anything attempts to access the boot sector or hard disk partition table. Disabled No warning message to appear when anything attempt to access the boot sector or hard disk partition table.
- Page 25 B785 C,A,SCSI/ D,A,SCSI/ E,A,SCSI/ F,A,SCSI: System will first search for IDE hard disk driver ( C: D: or E: or F☺ then second search floppy disk driver then SCSI hard disk driver. SCSI,A,C: System will first search SCSI hard disk driver then second search for floppy disk driver then IDE hard disk driver.
- Page 26 B785 Boot Up NumLock Status The default value is On. On: Keypad is number keys Off: Keypad is arrow keys Boot Up System Speed It selects the default system speed – the speed that the system will run at immediately after power up.
- Page 27 B785 15 : 15 characters per second 20 : 20 characters per second 24 : 24 characters per second 30 : 30 characters per second Typematic Delay (Msec) When holding the a key, the time between the first and second character will be displayed.
- Page 28 B785 Video BIOS Shadow It determines whether video BIOS will be copied to RAM, however, it is optional from chipset design. Video shadow will increase the video speed. Enabled: Video shadow is enabled Disabled: Video shadow is disabled C8000-CBFFF Shadow/DC000-DFFFF Shadow These categories determine whether optional ROM will be copied to RAM by 16K byte.
-
Page 29: Chipset Features Setup
B785 Chipset Features Setup ROM PCI/ISA BIOS (2A69KPNH) CHIPSET FEATURES SETUP AWARD SOFTWARE, INC Auto Configuration : Enabled Auto Detect DIMM/PCI Clk : Enabled DRAM Speed Selection : 60ns Spread Spectrum : Enabled EDO CASX# MA Wait State EDO RASX# Wait State... -
Page 30: Power Management
B785 Power Management ROM PCI/ISA BIOS (2A69KPNH) POWER MANAGEMENT SETUP AWARD SOFTWARE, INC. ACPI function : Enabled Reload Global Timer Events ** Power Management : User Define IRQ [3-7,9-15],NMI : Disabled PM Control by APM : Yes Primary IDE 0... - Page 31 B785 Item Options Descriptions A. Power Management 1. Disable Global Power Management will be disabled 2. User Define Users can configure their own power management 3. Min Saving Pre-defined timer values are used such that all timers are in their MAX value 4.
- Page 32 B785 −> Off STANDBY or SUSPEND mode 4. All Modes Screen off when system is in −> Off DOZE, STANDBY or SUSPEND mode D. Video 1. Blank Screen The system BIOS will only blanks off the screen when disabling video...
- Page 33 B785 Item Options Descriptions 3 Doze Mode Disable System will never enter DOZE mode (*) Remark 1 Defines the continuous idle time before the system entering DOZE mode. If any item defined in (J) is enabled & active, DOZE timer will be reloaded.
- Page 34 B785 Item Options Descriptions H. Suspend Mode 1. Disable System will never enter (*) Remark 1 SUSPEND mode 2. 10 Sec Defines the continuous idle time 20 Sec before the system entering 30 Sec SUSPEND mode. 40 Sec 1 Min...
- Page 35 B785 * Remark 1: All items mark with (*) in this menu, will be loaded with predefined values as long as the item "Power Management" is not configured to "User Defined" These items are: Item "System Doze", "System Standby" & "System Suspend"...
-
Page 36: Pnp / Pci Configuration Setup
B785 PNP / PCI Configuration Setup ROM PCI/ISA BIOS(2A69KPNH) PNP/PCI CONFIGURATION AWARD SOFTWARE, INC. PNP OS Installed : No PCI IDE IRQ Map To : PCI-AUTO Resources Contorlled By : Manual Primary IDE INT# Reset Configuration Data : Disabled Secondary IDE INT#... - Page 37 B785 Item Options Descriptions B. PCI IDE 2nd Channel Enable Enable/disable 2nd channel of PCI/IDE card. Disable It includes I/O port (170H~177H) and IRQ 15 assignment C. PCI IDE IRQ Map To PCI- PCI-AUTO AUTO The BIOS will: PCI- − scan for PCI IDE devices &...
-
Page 38: Integrated Peripherals
B785 INTEGRATED PERIPHERALS ROM PC/ISA BIOS(2A69KPNH) INTEGRATED PERIPHERALS AWARD SOFTWARE, INC. IDE HDD Block Mode : Enable UR2 Mode : IrDA IDE Primary Master PIO : AUTO UR2 Duplex Mode : Half IDE Primary Slave : AUTO Half Duplex time-out... -
Page 39: Load Bios Default
B785 Load BIOS Default When you access "Load BIOS Default", the following message appears: Load BIOS Default (Y/N) ?N The BIOS Default values are the "worst case" default, and are the most stable values for the system. Use them if the system is performing erratically due to hardware problems. -
Page 40: Ide Hdd Auto Detection
B785 anytime you try to enter Setup. If you select Setup at Security Option of BIOS Features Setup Menu, you will be prompted only when you try to enter Setup. IDE HDD Auto Detection This feature allows you to check all the informations on your hard disk formation. - Page 41 Software Setup After you have finished the hardware setup, you need install the software of B785 then you can enjoy the advance Motherboard. Please follow the steps for installation: 1. Turn on your PC and put the “driver CD” into your CD-ROM drive.
- Page 42 B785 5. Repeat step1.~step3. Then press “4.SOUND APPLICATION INSTALL” and follow the instructions to setup this software. Re-boot your PC. SOUND APPLICATION INSTALL button 6. Congratulation!! You have installed completely and enjoy it Now … ..
- Page 43 B785 ♦ Audio Control System Introduction The AudioRack32 enables you to take advantage of your computer's audio capabilities with all of the controls conveniently in one comp- act space. You can play audio CDs, wave files (in WAV and .AUD formats), and MIDI files (in.
- Page 44 B785 The System Diagram The Mixer Control Close the AudioRack32 window. Displays or hides the 3-D/Tone Controller. Enables the Miniature mode, minimizing the AudioRack32 display. Displays or hides the Digital Audio Player.
- Page 45 B785 Accesses On-line Help. Displays or hides the Compact Disk Player. Displays or hides the Audio Mixer. Displays or hides the MIDI Player.
