XENO XNR44P User Manual

4 channel nvr with poe
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
XNR44P 4 Channel NVR
with PoE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XNR44P and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for XENO XNR44P

Summary of Contents for XENO XNR44P

  • Page 1 XNR44P 4 Channel NVR with PoE...

  • Page 4: Safety Information

    User’s Manual | 2 Safety Information Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: A basic knowledge of CCTV systems and components ...

  • Page 5: Warnings And Cautions

    3 | FULL HD Network Video Recorder The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do not dispose of these products as unsorted municipal waste.
  • Page 6 User’s Manual | 4 Contents 1 : XNR44P U HAPTER ANUAL ETTING TARTED 1.1 C HECKING UPPLIED TEMS 1.2 S YSTEM TARTUP XPLANATION FOR UNCTION 2.1 F RONT ANEL 2.2 R ANEL PERATION 3.1 U 3.2 Q UICK ETUP 3.3 L ISPLAY 3.4 F...
  • Page 7 5 | FULL HD Network Video Recorder URVEILLANCE 5.1 W OGIN 5.2 W ONFIGURATION 5.3 W EB MONITORING 5.4 W LAYBACK 6 CMS USER G UIDE 6.1 PC REQUIREMENT 6.2 INSTALL 6.3 UNINSTALL 6.4 BASIC OPERATION 6.5 CMS FUNCTIONS 6.6 CMS SETUP 7 MAC ACS U UIDE 7.1 S...
  • Page 8 User’s Manual | 6 Chapter 1 XNR44P U ANUAL...
  • Page 9 7 | Chapter 1 : NVR...

  • Page 10: Checking Supplied Items

    User’s Manual | 8 ETTING TARTED 1.1 Checking Supplied Items Make sure that you have the following items supplied with your NVR. If any of these items are missing or damaged, notify your vendor immediately. Keep the packing utilities for moving or storage purposes afterwards. Items Photo Quantity...

  • Page 11: System Start-Up

    9 | Chapter 1 : NVR 1.2 System Startup 1.2.1 System Startup After connecting peripheral devices such as cameras, monitors and a mouse to the NVR, power up the NVR by connecting DC12V 3A adaptor to the power jack on the rear panel. The boot logo will display as shown below. Please wait until the boot process completes.

  • Page 12: Front Panel

    User’s Manual | 10 XPLANATION FOR UNCTION 2.1 Front Panel [4CH (W)280x(H)48x(D)273mm] Items Functions Indicate System Status LED Indicator Power, Record, Network USB Port USB Port (Ver. 2.0) for Mouse Operation, Backup Device or Firmware Update 2.2 Rear Panel [4CH (W)280x(H)48x(D)273mm] Functions PoE Power PoE Power Input (48V/1.4A)

  • Page 13: Operation

    11 | Chapter 1 : NVR PERATION 3.1 User Log-in Check the power connection. The system can be used after power-on. The NVR has various setting categories. The administrator can set the system password and <User> to prevent unauthorized changes to setting values and alteration of recorded file. Enter the <Admin>...

  • Page 14: Quick Setup

    User’s Manual | 12 3.2 Quick Setup 3.2.1 NVR Setup Quick Setup is specially designed to enable easier & faster for the major NVR settings such as NVR network setup, IP camera search & registration. When the NVR boots up and login, the Quick Setup will be operated automatically. Quick Setup pop-up is controllerable in main menu.

  • Page 15: Live Display Mode

    13 | Chapter 1 : NVR 3.3 Live Display Mode 3.3.1 Full HD(1080p) Live Display Full HD Live Display can be supported in live mode by using HDMI. In playback mode, the maximum resolution is 1920*1080(main) and 640*360(secondary) <Full HD Live & Playback Display> 3.3.2 Display CH selection can be done by CH1, CH4 buttons and display mode can be changed by MODE button.

  • Page 16: Icons Description

    User’s Manual | 14 3.3.3 Icons Description The live mode display’s icons or messages will be indicated on the screen to indicate the system mode or status. Below is the icon categories that are indicated on the monitor. Icon to be shown Icon to be shown at Left-upper corner on each channel screen at Left-bottom corner on full screen.
  • Page 17 15 | Chapter 1 : NVR 3.3.4 Pop-up Menu You can click the right button of the mouse to pop up a sub-menu as shown below. When “SEQUENCE” is selected, icon is shown on the bottom left corner of the screen, and display screen will be sequentially changed.

  • Page 18: Alarm Status

    User’s Manual | 16 select “Zoom-In size(x1.5, x2, x2.5 or x3)” on zoom pop-up menu. After selecting, move a yellow box by using the mouse to drag in the desired area of the camera to zoom. In order to go back to live display mode, please click “Zoom-In size” again. When a camera is disconnected, a warning sound may be generated depending on the system settings.

  • Page 19: Freeze Mode

    17 | Chapter 1 : NVR 3.4 Freeze Mode Click the right button on the mouse and select the Freeze mode while viewing a live image. In the Freeze mode, the image pauses; the date/ time information does not; and the system clock continues running. Press FREEZE to pause the live view. To resume the live view, press FREEZE again, or click the right button on the mouse and select the FREEZE again.
  • Page 20 User’s Manual | 18...

  • Page 21: Instant Record

    19 | Chapter 1 : NVR 3.6 Instant Record In the case of emergency, you can enable Instant Record. Click the right button on the mouse and select ‘Instant Record’ and the icon will be appeared and changed to Red ( After clicking ‘Instant Rec’, the icon will be changed as picture below.

  • Page 22: Playback Of Recorded Video

    User’s Manual | 20 3.7 Playback of Recorded Video It is easy to use the USB mouse to playback recording files. The recorded files can be seen backwards or forwards. Press the rewind and fast-forward buttons, and the playback speed can be controlled in steps of 2, 4, 8, 16, 32 times, real time when playing backwards( ) or forwards( You can also play ‘Frame by Frame’...

  • Page 23: Simultaneous Live And Playback (Cameo)

    21 | Chapter 1 : NVR 3.8 Simultaneous Live and Playback (CAMEO) 1Channel playback can be displayed in live view mode simultaneously, so called ‘Cameo’ function. In live view mode, mouse-right click on the channel that is desired to playback and then select Cameo to activate this function. You will see the blue frame on the CH1 screen when Cameo function is activated as shown below.

  • Page 24: Quick Backup During Live & Playback

    User’s Manual | 22 3.9 Quick Backup during Live & Playback You can easily archive video while viewing the video during live and playback mode. In live & playback mode, you can press right click of mouse and Backup menu will appear immediately. When desired back period is decided, set the start time and end time with target channels.

  • Page 25: Search Recording Image

    23 | Chapter 1 : NVR 3.10 Search Recording Image 3.10.1 Date/Time Search The user can select the date and time to search for a certain file within the recorded video. In the calendar, dates in RED means that there is recorded video data. Click a desired date in Red. Then, the recorded data for the selected date will be shown.
  • Page 26 User’s Manual | 24 The colors of the time bar are different, depending on the recording mode. - NONE No color “NONE” means no recording by setup of schedule and recording. - Instant recording Red color In continuous recording mode, the system records all the time as set by “CAMERA”. - Continuous recording Yellow color - Motion-detection recording...

  • Page 27: Event Log

    25 | Chapter 1 : NVR 3.10.2 Event Log The Event log search is used to find particular event, quickly and easily. Click the right button on the mouse as shown below and select the ‘Event Log’ to move. Click play icon to play back the selected event data.

  • Page 28: System Log

    User’s Manual | 26 3.10.3 System Log The system log search can be used to find particular system log information, quickly and easily. You can copy this event list to USB memory device in text file format. Click the right button on the mouse as shown below and select the ‘System Log’ to move.

  • Page 29: First Data

    27 | Chapter 1 : NVR Log by network 20 numbers of log record will be shown on one page of the <System Log> and <Event Log> window. You can click the arrow icon to search the log records on another page. 3.10.4 First Data Go to the first screen of the recorded video.

  • Page 30: Dst Setting And Screen Saver

    User’s Manual | 28 3.11 DST Setting and Screen Saver DST starts at 2:00 local time on 2 Sunday of March, and ends at 2:00 DST on 1 Sunday of November. During DST (Daylight Saving Time) period, NVR time clock has to be adjusted according to regional time zone. That is, the NVR time clock will be shifted by one hour after the DST settings start, and the NVR will restore the time clock back to normal after DST finishes.
  • Page 31 29 | Chapter 1 : NVR When you click on such overlapped period, a message titled “Recorded video Selection” will pop up. Then you can then select whether to play DST data or Non-DST data. Click OK to play DST image. Click CANCEL to play Non-DST image.

  • Page 32: S Etting

    User’s Manual | 30 ETTING General setting structure consists of “Quick Setup”, “System”, “Device”, “Record”, “Alarm,” and ‘Network” as shown below. <QUICK SETUP> <SYSTEM> <DEVICE> <RECORD> <ALARM> <NETWORK > Main MENU Sub MENU QUICK SETUP REGISTER SYSTEM INFO USER EXPORT/IMPORT SYSTEM BACKUP MONITORING...

  • Page 33: System Info

    31 | Chapter 1 : NVR 4.1 System The system menu button is selected by clicking the right mouse button. The sub-menu window will be displayed and you can choose specific menu by selection of sub-menu to set up and/or edit. 4.1.1 System Info Use this sub-menu to check system information status or to change the system-related configuration.
  • Page 34 User’s Manual | 32 In “DATE/TIME SET,” you can activate DST (Daylight Saving Time). Select the time synchronization server and other basic settings like time zone/time format. There are two types of TIME SYNC MODE. 1) NVR as NTP Sever mode The operating NVR is set as a Time Sync Server, which can synchronize the time clock of another NVR(s) connected over same network environment.
  • Page 35 33 | Chapter 1 : NVR ROCEDURE How to upgrade system firmware by using USB memory stick 1) Insert the USB thumb-drive formatted by FAT32 in any USB port of NVR (compatible with USB 2.0) 2) Once the system detects the thumb-drive, you can see its brand or model name in the “DEVICE”...
  • Page 36 User’s Manual | 34 4.1.2 User Master User of this system is always Admin with factory default of No password. Admin must change the password of the NVR for extra security. Admin can designate a new User with different permission levels by functions, menu access and live & playback. “Function”...
  • Page 37 35 | Chapter 1 : NVR 4.1.3 Export/Import You can copy and paste the system configuration values in this menu. “Export” allows you to copy the settings for this system to USB memory devices. “Import” allows the you to recall the settings saved from other systems using USB memory devices. During import process, make sure that the firmware version of source NVR is the same as the destination NVR.
  • Page 38 User’s Manual | 36 On the NVR system, NVR Health Check is represented in % sign as shown below. It indicates the lifetime and the temperature in Celsius of the hard disk drive. If system resources are occupied with task, such as making a network connection or performing video playback during the format process, the format may fail.
  • Page 39 37 | Chapter 1 : NVR 4.1.5 Backup You can archive a video clip recorded for a certain period on a selected channel or channels as shown below. Connect an appropriate USB memory device, like USB thumb drive, USB HDD and press the “SCAN” button to get the system to recognize it before archiving.
  • Page 40 User’s Manual | 38  Backup Video Player There will be a single file after archiving, if “Auto Player” was selected. You can double click “Player.exe” file to open the video data file (PSF format) in the folder. You can print out, capture a still image, zoom out, or make an ASF file format, by using the icons located on top of the player window.

  • Page 41: Factory Default

    39 | Chapter 1 : NVR 4.1.6 Monitoring Monitoring menu enables you to see the status information. Network status display receiving bandwidth from cameras and transmitting bandwidth to external access in graph. Property shows NVR network information and Client status displayed by external access through network. It keeps showing the time & date with IP address.
  • Page 42 User’s Manual | 40 4.2 Device There are Device sub-menu to set-up Register, Camera and Audio function. 4.2.1 Register Network cameras should be registered in NVR to transmit the video streaming. Connected cameras can be found on a local network by clicking the ‘Search’ button. When camera are discovered, you can assign the discovered cameras o specific channels on the NVR by Add to Camera list .
  • Page 43 41 | Chapter 1 : NVR  Motion Area Setup The default motion area setup relies on network camera setting and direct control of network camera is supported for approved models. Choose the desired motion area by dragging a mouse using left button. The whole image or upto 4 individual areas of the image can be selected.
  • Page 44 User’s Manual | 42 Mac Address of the IP camera is not activated. Mac Address Adjusting to the light of screen automatically responding to external Illuminance variation. Not activated. Auto Iris Available to set to Off, 50Hz or 60Hz. Flicker Back Light Of Compensation.

  • Page 45: Record Setup

    43 | Chapter 1 : NVR 4.3 Record You can configure various record settings such as Continuous, Motion, and Sensor for each individual camera channel in the Record Setup Menu. Network Stream settings relies on network camera for recording. Approved network camera setting will be set by NVR menu and you can set up streaming video quality, FPS, bitrates in network camera menu as well.
  • Page 46 User’s Manual | 44 Select channel to set the registered network camera Channel  Select resolution up to 1920*1080(Full HD) for main stream and 640*360 for secondary stream.  Resolution Select between CBR(Constant Bit Rate) and VBR(Variable Bit Rate)  Bit Rate type Select the desired Quality level(Lowest/Low/Normal/High/Highest) ...
  • Page 47 45 | Chapter 1 : NVR 4.4 Alarm 4.4.1 Sensor You can select the sensor input between NVR and supported network cameras. Mapping is only available for either of Network camera sensor or the local sensor of NVR on the same channel. ...

  • Page 48: System Alarm

    User’s Manual | 46  Relay Off / Relay Output to trigger other device. Dwell Time  Set the recording period from the start of sensor input activation. During this period, the corresponding camera video will record according to the frame and alarm (relay) output set. The recording stops and alarm output is turned off when the dwell time has elapsed.

  • Page 49: Motion Alarm

    47 | Chapter 1 : NVR You also set the percentage for HDD Usage. For example, when Usage is 50%, NVR will notify by a camera popup or a beep sound when HDD is 50%. 4.4.3 Motion Alarm Select Motion alarm to record only when motion detection is triggered by NVR S/W upon you defined motion area. An alarm signal is sent via the selected sensor-out channel.
  • Page 50 User’s Manual | 48  E-Mail Notify The system can send notification to an Email address or Advanced Client Software and the Central Management System over the network. You can choose from a selection of different kinds of alarms by pressing “ADD.” Alarms can be generated by Sensor, Motion Detection, Disk Full, Admin PW Changed, Video Loss, and Power On/Off.
  • Page 51 49 | Chapter 1 : NVR 4.5 Network 4.5.1 Network The system has built-in web server.  Internet Protocol Version Not selectable. TCP / IP v4 support only.  Network Type Select network connect type. Select either LAN for fixed (Static) IP or DHCP for dynamic IP. If DHCP is selected, click ‘IP DETECT’...
  • Page 52 User’s Manual | 50  DNS Server Enter the IP address of the Domain Name Server. There are two DNS settings. (The preferred DNS and the alternative DNS) *You should enter the DNS Server information in order to use internet. (Provided by your ISP) ...
  • Page 53 51 | Chapter 1 : NVR  Auto Private IP Setup (NAT Traversal) The UPnP NAT Traversal function will help to automatically setup a router if the NVR connects to the internet via a router. When a PC connects to a NVR, which is not in the same local area network, a real IPO address and corresponding port number is required.
  • Page 54 User’s Manual | 52 4.5.2 DDNS You have to tick the “Use DDNS” check box to use it.  DDNS Server joinip.net or joinip2.net is the fixed domain name of DDNS server. You cannot change the DDNS name. The standard(default) DDNS domain name is joinip2.net, and you can use joinip.net or dyndns.com by drop-down list.
  • Page 55 53 | Chapter 1 : NVR 4.5.4 System Shutdown and change password The system can be power off by ‘Shut Down’ button. The ‘Shut Down’ can be done by clicking a right button of mouse. The default password for ‘admin’ account is none. Therefore, just click ‘OK’ button on the popup window. If you change the password for ‘admin’...

  • Page 56: Web Surveillance

    User’s Manual | 54 URVEILLANCE The system has a built-in web server. Using an ordinary web-browser over a network, you can always stay connected to the system for live monitoring, playback, or remote configuration without installing the Advanced Client Software (ACS). 5.1 Web Login You need to input the correct IP address in the web browser after making the web port available in the router.

  • Page 57: Web Configuration

    55 | Chapter 1 : NVR 5.2 Web Configuration Menu of Web Configuration Main Classification Sub Classification QUICK SETUP REGISTER SYSTEM INFO. USER SYSTEM DEFAULT REGISTER DEVICE CAMERA AUDIO RECORD SETUP RECORD SCHEDULE SENSOR SYSTEM ALARM MOTION NOTIFICATION NETWORK NETWORK DDNS IP FILTER After logging in with the right ID and password, you can make various configuration changes in the Web Configuration window...
  • Page 58 User’s Manual | 56 [System] [Device] [Record] [Network] [Quick Setup] This NVR system has its own built-in web server. This web CGI screen is directly supported from the built-in web server in the NVR, regardless of Internet connection.

  • Page 59: Web Monitoring

    57 | Chapter 1 : NVR 5.3 Web monitoring You have to download Active-X file from NVR and install it at workstation PC before monitoring live video. [Web Active X Install ] You can get into web monitoring after log in as shown below. In order to connect to NVR, you have to click “...
  • Page 60 User’s Manual | 58 You can monitor live video in 1, 4, 9 or 16 screen modes. If you want to see single channel in full screen, you can double-click on the left mouse button when the cursor is positioned on the live video screen. You can change to single mode by clicking the mode icon located at the bottom left.

  • Page 61: Web Playback

    59 | Chapter 1 : NVR 5.4 Web Playback You can remotely playback the NVR images by clicking “SEARCH” button in the middle of bottom window. In order to connect to NVR, the you have to click “ Connect ” button which is located at the top left corner. Playback Time ...
  • Page 62 User’s Manual | 60 Chapter 2 CMS C USER M LIENT OFTWARE ANUAL...
  • Page 63 61 | Chapter 1 : NVR 6 CMS USER G UIDE 6.1 PC REQUIREMENT Recommended PC Requirement Windows 7, 8 Intel Core i7 ATI Radeon HD 1GB RAM 100MB Free space Minimum PC Requirement Windows 7, 8 Intel Core i5 ATI Radeon HD 512MB RAM 20MB Free space 6.2 INSTALL...
  • Page 64 User’s Manual | 62 Press if you want to install the program in a different directory. Press to move to the next screen. Press to move to the next screen.
  • Page 65 63 | Chapter 1 : NVR Press to move to the next screen. Click to begin installation. When the installation is complete, the following message will be appeared.
  • Page 66 User’s Manual | 64...
  • Page 67 65 | Chapter 1 : NVR 6.3 UNINSTALL To uninstall CMS, press UNINSTALL CMS from Start Menu of your PC. A window will appear in Windows7 or Windows Vista. Press YES to begin the process. The following window will appear. When the process is complete, the below message will appear.

  • Page 68: Basic Operation

    User’s Manual | 66 6.4 BASIC OPERATION Click on CMS icon on Desktop or click START on Windows PC and go to CMS Folder. 6.4.1 LOG IN The default ID is Administrator, and there is no default password so please leave it blank. The administrator account has the highest level of authority on the CMS.

  • Page 69: Screen Layout

    67 | Chapter 1 : NVR 6.4.2 SCREEN LAYOUT...
  • Page 70 User’s Manual | 68 Item Description Main Toolbar The Main Toolbar has three (3) selectable tabs named "Main", "Export" and (Setup Tab) "Setup". In the Setup tab, there are CMS setup and Remote setup. Main Toolbar In the Export tab, able to save JPEG, AVI and Print the images. (Export Tab) Main Toolbar In the Main tab, able to connect Live and Search, disconnect, change display...
  • Page 71 69 | Chapter 1 : NVR 6.4.4 MAIN TOOLBAR (EXPORT) Description Item Image Capture the image of the selected (focused) channel. Movie Save the selected channel in ASF format movie file. Print Print the selected channel. Windows Exit Minimize/Maximize the CMS Window or close the CMS program. 6.4.5 MAIN TOOLBAR (MAIN) Description Item...
  • Page 72 User’s Manual | 70...

  • Page 73: Site List

    71 | Chapter 1 : NVR 6.4.6 SITE LIST The Site List displays all of the DEVICE that are currently setup for remote connection with the CMS application, and its cameras are available for view. From the Site List Panel, select the desired camera and drag it on to the viewing area. Then, select the options Live or Search ( If an DEVICE site is dragged onto the viewable area, then the selected DEVICE or all cameras from the DEVICE will display.
  • Page 74 User’s Manual | 72 6.4.7 SEARCH The Search panel is activated only in Search mode. When you connect to a site in Search mode, the date is highlighted in Red colour in the calendar, if the recorded data exist. Select a specific date in the calendar and then recording information will be shown in the table. (Go button) should be pressed to start playback from the selected time.
  • Page 75 73 | Chapter 1 : NVR Playback Control Panel Button Description Go to First. Forward Playback : Decrease the speed / Reverse Playback : Increase the speed. Step Forward. Reverse Playback. Pause. Forward Playback. Step Backward. Forward Playback : Increase the speed / Reverse Playback : Decrease the speed.
  • Page 76 User’s Manual | 74 6.4.8 DISPLAY In live mode, the text LIVE will be displayed in white, and the channel will be bordered in blue. In search mode, the text SEARCH will be displayed in red, and the channel will be bordered in red. The selected channel will be bordered in yellow.

  • Page 77: Event Search

    75 | Chapter 1 : NVR 6.4.9 EVENT SEARCH CMS can receive any event data from the DEVICE as shown below. You can select a desired date to view the event list of the selected date. You can choose either event log or system log. Start the playback by double-clicking the Index number of each even list.
  • Page 78 User’s Manual | 76 6.4.10 INFORMATION The current date/time, site name, IP address, ID, channel and Live/Search status will be shown. 6.4.11 FAVORITE Cameras currently displayed on the screen can be added, deleted and edited as a favorite site group. Place cameras of DEVICE site into a desired channel location of the screen and then click to create a new...

  • Page 79: Cms Functions

    77 | Chapter 1 : NVR 6.5 CMS FUNCTIONS 6.5.1 EVENT SEARCH When you right click on a site in the site list, the quick access menu will be shown. Select EVENT SEARCH to run Event Search. Description Item System Connection Info Input the information of DEVICE to connect.

  • Page 80: Remote Backup

    User’s Manual | 78 6.5.2 REMOTE BACKUP When you right click on a site in the site list, the quick access menu will be shown. Select REMOTE BACKUP to run Remote Backup. Description Item System Connection Info Input the information of DEVICE to connect. Recording Directory Decide the recording directory to backup.
  • Page 81 79 | Chapter 1 : NVR...

  • Page 82: Firmware Upgrade

    User’s Manual | 80 6.5.3 FIRMWARE UPGRADE When you right click on a site in the site list, the quick access menu will be shown. Select FIRMWARE UPGRADE to run Firmware Upgrade. Description Item DEVICE Connection Info Input the information of DEVICE to connect. Firmware File Directory Decide the firmware file directory to upgrade.

  • Page 83: Multi Monitor

    81 | Chapter 1 : NVR 6.5.4 MULTI MONITOR Click MULTI MONITOR in the Main Toolbar to run the Multi Monitor function. When you click MULTI MONITOR, you will see another separate window with the same split display as the main window. 6.5.5 PANORAMA Click PANORAMA in the main tool bar to run Panorama View.
  • Page 84 User’s Manual | 82...

  • Page 85: Thumbnail Search

    83 | Chapter 1 : NVR 6.5.6 THUMBNAIL SEARCH Click THUMBNAIL in the main toolbar to run Thumbnail Search. This feature is only available in Search mode. First select a channel and click THUMBNAIL; then, you will see the Thumbnail Search window as shown below. Description Item Date...
  • Page 86 User’s Manual | 84 6.5.7 BOOKMARK Click icon to bookmark the selected one channel search data. Once the selected search data is bookmarked, the bookmark data is listed with an image in the bookmark list as shown below. Select a bookmark list and click search or double click the bookmark list to search the bookmarked data. Click REMOVE button to remove a selected bookmark list and click DELETE ALL to delete all of bookmark list.
  • Page 87 85 | Chapter 1 : NVR 6.5.9 Switch Stream You can switch the Main stream to Secondary stream or vise versa on the site of a selected channel.

  • Page 88: Cms Setup

    User’s Manual | 86 6.6 CMS SETUP There are options for DEVICE Registration, Network, User, Display, Event and Misc. 6.6.1 NVR REGISTRATION Add, Edit, Import, Export or Remove DEVICE site information. Ex) Adding a new device site In order to add a NVR, click ‘Add’ button, and put right information. NVR can be detected by ‘Search’...
  • Page 89 87 | Chapter 1 : NVR To edit and/ or remove DEVICE information, click ADD or REMOVE to amend DEVICE site information. Able to export the current site list and save as a file or import the file to the site list. Once the new DEVICE site is added, the new DEVICE information will be displayed at DEVICE site panel as shown below.
  • Page 90 User’s Manual | 88 Enable Auto Connect: When you restart the CMS program again, after CMS is closed, it will reconnect to the sites just as before.
  • Page 91 89 | Chapter 1 : NVR 6.6.3 USER User authority can be changed by Administrator. “admin” is the built-in account for administrating the DEVICE and CMS program. Ex) User authority change User authority can be changed by Administrator. ID cannot be changed but should be removed.
  • Page 92 User’s Manual | 90 6.6.4 DISPLAY Options for OSD setting. Title: Able to turn on/off the DEVICE title with the channel number. Date/Time: Able to turn on/off the Date/Time of the site. DEVICE Name: Able to turn on/off the name of the site. Time Format Sync: Synchronize the DEVICE time format to CMS.
  • Page 93 91 | Chapter 1 : NVR 6.6.5 EVENT Setup the event port, event type and popup settings for event. Item Description Input the same event port number of DEVICE setting to receive event notification from the Port DEVICE. Filter Select the type of event to receive. Action Setup the popup duration and enable beep sound.
  • Page 94 User’s Manual | 92 6.6.6 MISC. Setup the Recording Directory, Language, Auto Upgrade, and Auto Login. Item Description Recording Directory Decide the recording directory to save images and moving images. Language Select a desired language. In order to have Auto Upgrade, input FTP information. Once the FTP setup is FTP Information done, CMS will detect the latest firmware is in the FTP and start upgrading automatically.
  • Page 95 93 | Chapter 1 : NVR Chapter 3 MAC ACS C LIENT OFTWARE ANUAL...

  • Page 96: System Requirement

    User’s Manual | 94 7 MAC ACS U UIDE 7.1 System Requirement Recommended System Requirement Mac OS X 10.6(snow leopard) Intel i5 CPU or upper Recommended More than 256MB Recommended More than 1GB 20MB Free Space Minimum System Requirement. Mac OS X 10.5( Leopard) Built-in Intel CPU MAC 128MB 512MB...
  • Page 97 95 | Chapter 1 : NVR Select the HDD to be installed. Press the [Continue] button to move to the next screen. Press the [Continue] button to move to the next screen Press the [Install] button to Install MAC ACS.
  • Page 98 User’s Manual | 96 Put in the password and Click [OK] to begin installation. When the installation is complete, the message appears as below. 7.3 Basic Operation Click on ACS icon on Application Folder...
  • Page 99 97 | Chapter 1 : NVR...
  • Page 100 User’s Manual | 98 7.3.1 Screen Layout Description Item Main Toolbar AVS Setting, Live and Search Connect, Disconnect, Image Save, Screen Mode and Change NVR List Panel Registered NVR Site List. Possible to connect by Dragging Live or Search Click Live or Search mode to connect the panel Connect Panel PTZ Panel PTZ camera control is not available.

  • Page 101: Main Toolbar

    99 | Chapter 1 : NVR 7.3.2 Main Toolbar Description Button Site Manager Register or Delete NVR on the list Connect Connect to a site that is listed on the NVR list panel (Select Live and Search mode at Connect Mode Panel) Disconnect Disconnect a selected channel Disconnect All...

  • Page 102: Calendar Panel

    User’s Manual | 100 7.3.4 Calendar Panel Activated in Search Mode The recorded data will be shown in blue bold with the dot which is located below the number When you click the recorded date on the search mode, the playback time will be detected automatically ( Go Button ) should be pressed to start playback from the selected date and time If DST is enabled, the earlier one-hour overlapped video will be shown first.

  • Page 103: Search Panel

    101 | Chapter 1 : NVR 7.3.5 Search Panel Activated in Search Mode - The Search panel shows the record information for each channel. - Each record mode is like below. No Record Background Color Continuous (Yellow Color) Instant(Red Color) Alarm(Orange Color) Motion(Green Color) - Click the time or move the time bar to the time you want to playback in the search panel.

  • Page 104: Site Manager

    User’s Manual | 102 7.3.6 Site Manager Add or Modify or Remove NVR site information. Press to register the NVR as follows : The default value is registered...
  • Page 105 103 | Chapter 1 : NVR To fix, Double-Click on the item. For example, Double-click “ New Site “ to change the name. After modifications have been made, press Description Function Name Fill in the name of the site to be registered Fill in the IP of the site to be registered Port Fill in the PORT No of the site to be registered (Default 9010)
  • Page 106 User’s Manual | 104...
  • Page 107 105 | Chapter 1 : NVR Chapter 4 OBILE HONE OFTWARE ANUAL...

  • Page 108: Iphone Application Software

    User’s Manual | 106 OBILE HONE OFTWARE UIDE 8.1 iPhone application software...
  • Page 109 107 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 110 User’s Manual | 108...
  • Page 111 109 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 112 User’s Manual | 110...
  • Page 113 111 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 114 User’s Manual | 112...
  • Page 115 113 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 116 User’s Manual | 114 PTZ camera control is not available on the NVR system. ...
  • Page 117 115 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 118 User’s Manual | 116...
  • Page 119 117 | Chapter 4 : Mobile Phone Software User Manual...

  • Page 120: Android Application Software

    User’s Manual | 118 8.2 Android application software...
  • Page 121 119 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 122 User’s Manual | 120...
  • Page 123 121 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 124 User’s Manual | 122...
  • Page 125 123 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 126 User’s Manual | 124 PTZ camera control is not available on the NVR system. ...
  • Page 127 125 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 128 User’s Manual | 126...
  • Page 129 127 | Chapter 4 : Mobile Phone Software User Manual...

  • Page 130: Using Wap+3G Connection

    User’s Manual | 128 8.3 Using WAP+3G Connection...
  • Page 131 129 | Chapter 4 : Mobile Phone Software User Manual...
  • Page 132 130 | FULL HD Network Video Recorder...
  • Page 133 131 | Appendix : DynDNS Site Registration DNS S PPENDIX EGISTRATION 1) Go to www.dyndns.com 2) Log in to the Site after registration 3) Click “ Add Hostname“ button on “Host Services”...
  • Page 134 User’s Manual | 132 4) Put in the IP address and Host name on the blank 5) Click “NEXT” Button 6) Click “Activate Services” button...
  • Page 135 133 | Appendix : DynDNS Site Registration...
  • Page 136 User’s Manual | 134 7) Confirm the domain name and IP address 8) Check the connection status  It may take a little time to be completely done for DNS deployment after changed sub domain. Please recheck NVR’s IP address registered in the My Service Menu, if you can’t access NVR using dyndns. If you are using dyndns to change the IP address for the NVR to the update request, dyndns update by the circumstances that may be late.
  • Page 137 135 | FULL HD Network Video Recorder...
  • Page 138 User’s Manual | 136 10 A PPENDIX PECIFICATION Full HD Network Video Recorder 4/8CH Design Video H.264, JPEG supported Compression Audio ADPCM, PCM supported HDD Interface 1EA x SATA I / II / III Operation System Embedded Linux Video Output HDMI (1920x1080p/1280x720p/1280x1024/1024x768) Decoding Max 120fps @ 1080P (30fps per CH)
  • Page 139 137 | Appendix : Specification...
