User’s Manual | 2 Safety Information Before You Begin Read these instructions before installing or operating this product. Note: This installation should be made by a qualified service person and should conform to local codes. This manual provides installation and operation information. To use this document, you must have the following minimum qualifications: ...
Page 3
3 | Full HD Digital Video Recorder The crossed-out wheeled bin mark symbolizes that within the European Union the product must be collected separately at the product end-of-life. This applies to your product and any peripherals marked with this symbol. Do not dispose of these products as unsorted municipal waste.
User’s Manual | 4 Contents 1 : DVR U HAPTER ANUAL ETTING TARTED 1.1 Checking Supplied Items 1.2 Connecting Peripheral Device 1.3 System Startup and Shutdown XPLANATION FOR UNCTION 2.1 Front Panel 2.2 Rear Panel PERATION 3.1 User Log-in 3.2 Live Display Mode 3.3 PTZ Operation 3.4 Playback of Recorded Video 3.5 Search Recording Image...
Page 5
5 | Full HD Digital Video Recorder 2 : CMS C HAPTER LIENT OFTWARE ANUAL 6 CMS U UIDE 6.1 PC REQUIREMENT 6.2 INSTALL 6.3 UNINSTALL 6.4 BASIC OPERATION 6.5 CMS FUNCTIONS 6.6 CMS SETUP 3 : MAC ACS C HAPTER LIENT OFTWARE...
7 | Full HD Digital Video Recorder ETTING TARTED 1.1 Checking Supplied Items Make sure that you have the following items supplied with your DVR. If any of these items are missing or damaged, notify your vendor immediately. Keep the packing utilities for moving or storage purposes afterwards. Items Photo Quantity...
2.5~3U (1U=1.75 inch or 4.45 cm) space for proper ventilation. Install the system in a location with good ventilation to prevent overheating. 4ch (1 HDD Case) Dimensions: 11.0” W x 1.9” H x 9.6” D 8ch (1 HDD Case) Dimensions: 11.0” W x 1.9” H x 9.6” D...
Page 9
9 | Full HD Digital Video Recorder 8ch (2 HDD Case) Dimensions: 14.1” W x 2.6” H x 14” D 16ch (2 HDD Case) Dimensions: 14.1” W x 2.6” H x 14” D ※When connecting power cord to the system, it is strongly recommended first to plug the power cord ARNING to the system and then plug the other side of power cord into the wall socket.
User’s Manual | 10 CAMERA CONNECTION Example 1) All TVI 4CHs 1080P/720P support Example 2) All AHD 4CHs 1080P/720P support Example 3) All Analog 960H 4CHs In order to set TVI or AHD at the same time, the channel combination must be 2 pairs used.
11 | Full HD Digital Video Recorder 1.3 System Startup and Shutdown 1.3.1 System Startup After connecting peripheral devices such as cameras, monitors and a mouse to the DVR, power up the DVR by connecting DC12V 3A adaptor to the power jack on the rear panel. The boot log will display as shown below. Please wait until the boot process completes.
Page 12
User’s Manual | 12 1.3.2 System Shutdown and change password Option 1. Click the Shutdown button and input password on pop-up to power off the DVR Option 2. Click the right button on the mouse and select the Shut Down to power off the DVR. It is not recommended to disconnect the power cable abruptly from the back of the DVR because it may affect the DVR and Hard Drive.
13 | Full HD Digital Video Recorder XPLANATION FOR UNCTION 2.1 Front Panel 4/8/16ch DVR Front Panel (1 HDD Case) 8/16ch DVR Front Panel (2 HDD Case) Items Functions Indicate System Status LED Indicator Power, Record, Network USB Port USB Port (Ver. 2.0) for Mouse Operation, Backup Device or Firmware Update...
Page 15
USB 2.0 Port for Mouse Operation, Backup Device, or Firmware Update HD OUTPUT HD OUTPUT 1 x 10/100/1000M LAN Port Power Input 4ch : 12V 2A 8ch(1 HDD) : 12V 3A 8/16ch(2HDD) : 12V 5A Alarm Output Alarm Output Sensor Input...
User’s Manual | 16 PERATION 3.1 User Log-in The DVR has various setting categories. The administrator can set the system password and <User> to prevent unauthorized changes to setting values and alteration of recorded file. Enter the <Admin> or <User> password which had been set by using the virtual keyboard. 1) <LOGIN>...
17 | Full HD Digital Video Recorder 3.2 Live Display Mode 3.2.1 Full HD(1080p) Live Display Full HD Live Display can be supported in live mode by using its HD output. In playback mode, the maximum resolution is 1080P. <Full HD Live Display>...
User’s Manual | 18 3.2.2 Channel Selection Channel selection can be done by following one of the steps below: CH1~CH16 buttons in the IR Remote Control. 1~16 virtual buttons at the bottom of the GUI display. The display mode can be changed by pressing the ‘MODE’ button on the DVR’s front panel. The live images can be displayed in real-time in 1, 4, 9, 16 screen splits.
Page 19
19 | Full HD Digital Video Recorder 3.2.3 Icons The live mode display’s icons or messages will be indicated on the screen to indicate the system mode or status. Below are the icon categories that are indicated on the monitor: Icon to be shown Icon to be shown at Left-upper corner on each channel screen...
Page 20
User’s Manual | 20 3.2.4 Pop-up Menu User can click the right button of the mouse to pop up sub-menu as shown below. DISPLAY- Select the display split from the available options: - 1 Screen- Single channel. Automatically displays CH1. If 1 Screen is selected again, next chronological channel will be displayed.
Page 21
21 | Full HD Digital Video Recorder When a camera is disconnected, a warning sound may be generated depending on the system settings. As the Admin user, you can seup up multiple users with different levels of authorization. If a certain user is not allowed to view a certain camera in live or playback, then no image will appear on the display screen.
User’s Manual | 22 3.3 PTZ Operation Before starting PTZ control, please make sure the camera you wish to control is a supported PTZ camera and is installed and configured properly. See section 4.2.6 PTZ for setup information. To enter PTZ mode, follow one of the options below: Right-click on the screen and select PTZ Control.
23 | Full HD Digital Video Recorder User can automatically switch PTZ camera positions according to defined presets by using the GUARD TOUR function. The connected PTZ camera must support touring functions. “GUARD TOUR” on the pop-up menu can be enabled only in full screen mode.
User’s Manual | 24 The picture below shows the system playing back a video. In playback screen, user can make various playback modes, make an instant manual backup (archive), go to calendar search mode, change channel, and change screen modes. By clicking the left mouse button in the colored-time bar, the user can jump to a different time in the recording.
25 | Full HD Digital Video Recorder 3.5 Search Recording Image 3.5.1 Date/Time Search To search your recorded data by date/ time, follow one of the options below: Click the quick Menu button at the left side of the menu bar, select Search Date/ Time Right-click anywhere on the screen, select Search ...
User’s Manual | 26 Software over the network. If “SENSOR” is disabled in the “DEVICE” menu, and recording mdoe is set to “CONT + SENS”, the system will record with continuous recording even when a sensor is triggered. To view video from the selected time, follow one of the options below: Use the manual hour option to view specific hours of the day.
27 | Full HD Digital Video Recorder 3.5.3 System Log The system log search allows you to search for any changes made to the system, quickly and easily, displaying the search results in a detailed table format. To open System Log Search, perform one of the following options: Click quick menu button, select Search...
User’s Manual | 28 9 numbers of log record will be shown on one page of the <System Log> and <Event Log> window. User can click the arrow icon to search the log records on another page. 3.5.4 First Data Go to the first screen of the recorded video.
29 | Full HD Digital Video Recorder 3.6 DST Setting DST starts at 2:00 local time on 2 Sunday of March, and ends at 2:00 DST on 1 Sunday of November. During DST (Daylight Saving Time) period, DVR time clock has to be adjusted according to regional time zone. That is, the DVR time clock will be shifted by one hour after the DST settings start, and the DVR will restore the time clock back to normal after DST finishes.
User’s Manual | 30 When user click on such overlapped period, a message titled “Recorded video Selection” will pop up. The user can then select whether to play DST data or Non-DST data. Click OK to play DST image. Click CANCEL to play Non-DST image. [“DST”...
31 | Full HD Digital Video Recorder ETTING General setting structure consists of “System”, “Device”, “Record”, “Network”, “Backup,” and ‘Quick Setup” as shown below. <SYSTEM> <DEVICE> <RECORD> <NETWORK> <BACKUP> <Q-SETUP> Main Classification Sub Classification SYSTEM INFO USER SYSTEM EXPORT/IMPORT FACTORY DEFAULT CAMERA AUDIO SENSOR...
User’s Manual | 32 4.1 System The system menu button is selected by clicking “TOOL” on the menu bar or clicking the right mouse button. Users can move mouse pointer from “System” through “Quick Setup” to instantly look around the sub-menus on the menu screen.
Page 33
33 | Full HD Digital Video Recorder Date/ Time- manually enter the DVR’s date and time, time zone, and enable/ disabled DST. Using the available options, manually adjust the date and time from the calendar, select the display mode for the time, and the date, and select the appropriate time zone.
Page 34
User’s Manual | 34 NTP Setup- Setup the DVR to automatically sync with a Network Time Protocol. There are two types of TIME SYNC MODE: Server Mode- The DVR is set as a Time Sync Server, which can synchronize its own time with another DVR(s) connected over the same network environment.
Page 35
35 | Full HD Digital Video Recorder 4.1.2 User Master user of this system is always Admin with factory default of No password. This user cannot be deleted. It is recommended that the Admin change the password for extra security. Admin can designate a new user with different permission levels by: functions, menu access, and live &...
Page 36
User’s Manual | 36 4.1.3 Export/Import Users can copy and paste the system configuration values in this menu. “Export” allows the user to copy the settings for this system to USB memory devices. “Import” allows the user to recall the settings saved from other systems using USB memory devices.
37 | Full HD Digital Video Recorder 4.1.5 Factory Default With an authorized password, users can get the system back to factory default configuration. Upon clicking “Start” button and entering the admin password, all the configuration values made by the user will be deleted.
User’s Manual | 38 4.2 Device There are Seven sub menus in the Device menu, such as Camera, Audio, Sensor, Motion Alarm, Extra Alarm, and PTZ. Users can easily move to the “Device” menu by selecting the icon on the top right of the menu screen. 4.2.1 Camera Users can setup camera title, brightness, contrast, motion sensitivity, and audio mapping for each camera.
Page 39
39 | Full HD Digital Video Recorder 4.2.2 Audio Users can select the audio input and output during live display and match the audio input to a designated channel. (Please refer to Section 4.3.1 Camera Record). Adjust the audio volume using the volume control panel, enable or disable audio recording for each channel, and enable or disable audio during live video.
Page 40
User’s Manual | 40 Preset- User can select the camera to move to a preset position, once the sensor is triggered. (User should setup preset position in PTZ menu 4.2.6 in advance). In addition, users can set multi-preset with a single PTZ camera.
41 | Full HD Digital Video Recorder 4.2.4 Motion Alarm Select Motion alarm to record only when motion detection is triggered by DVR S/W upon user’s defined motion area. An alarm signal is sent via the selected sensor-out channel. COPY SETTINGS ...
Page 42
User’s Manual | 42 4.2.6 PTZ Full control of PTZ camera is available in this menu. For details, please refer to Section 3.3 PTZ Operation. Protocol Select the proper protocol of the connected PTZ camera. Address Set the PTZ driver address of the connected camera. Check the below items for proper P/T/Z operation.
43 | Full HD Digital Video Recorder 4.3 Record Users can configure various record settings such as Continuous, Event, and Panic for each individual camera channel in the Record Setup Menu. Network Stream settings are independently configured from the Record settings in this menu as well. Therefore, the user can optimize the bandwidth used by configuring the resolution, FPS, and image quality separately.
Page 44
User’s Manual | 44 Users also have the option to configure Panic Record settings. The Panic Record setting is intended to be used under emergency situations. You engage Panic recording by pressing the “Instant Record” button on the frontal keypad, or clicking the icon from the control panel in live mode.
Page 45
45 | Full HD Digital Video Recorder 4.3.2 Schedule You can set up the record schedule by applying a various record modes to each date and time. Simply select a record mode by mouse and drag it to the desired date and time. 4.3.3 Holiday Users can setup a specific day of a month or day of week as a holiday as shown below.
User’s Manual | 46 4.4 Network 4.4.1 Network The system has built-in web server. ETHERNET - DVR network system - ETHERNET LAN port Network Type Select network connect type. Select either LAN for fixed (Static) IP or DHCP for dynamic IP. If DHCP is selected, click ‘IP DETECT’...
Page 47
47 | Full HD Digital Video Recorder XHDRA-04 XHDRA -05 XHDRA -06 Simply double click on the desired icon. Then, it will open an internet browser that connects to the DVR via the remote control software as shown below. Please type in your User ID and Password to login and click ‘Connect’ button to connect. Auto Private IP Setup (NAT Traversal) ...
Page 48
User’s Manual | 48 4.4.2 DDNS The User has to mark the “Use DDNS” check box to use it. DDNS Server Joinip.net or joinip2.net is the fixed domain name of DDNS server User cannot change the DDNS name. The standard DDNS domain name is joinip2.net, and users can use joinip.net or dyndns.com by drop- down list.
Page 49
49 | Full HD Digital Video Recorder 4.4.3 Notification Remote Notify The system can notify an alarm message to the IP address of Central Monitoring Software over the network. User can choose from a selection of different kinds of alarms by pressing “ADD.” Alarms can be generated by Sensor, Motion Detection, Disk Full, Admin PW Changed, Video Loss, and Power On/Off.
User’s Manual | 50 4.4.1 Health Check The DVR offers a uniquely true DVR health monitoring, with pop-up messages and e-mail notification on video loss, recording failure, and HDD failure. To setup: 1. Check the box next to "Enable Health Check" 2.
51 | Full HD Digital Video Recorder 4.5 Backup 4.5.1 Backup Users can archive a video clip recorded for a certain period on a selected channel or channels as shown below. Connect an appropriate USB memory device, like USB thumb drive, USB HDD, and press “SCAN” button to get the system to recognize it before archiving.
Page 52
User’s Manual | 52 4.5.1 Backup Video Retrieve There will be a single file after archiving, if “Auto Player” was selected. User can double click “Player.exe” file to open the video data file (PSF format) in the folder. User can print out, capture a still image, zoom out, or make an ASF file format, by using the icons located on top of the player window.
53 | Full HD Digital Video Recorder 4.6 Quick Setup Quick Setup helps user make simple configuration for recording resolution, entire recording speed by frame, recording mode, and recording periods. The system will put the first priority for configuration on this quick setup and will follow this rule regardless of configurations set in other menus.
User’s Manual | 54 URVEILLANCE The DVR has a built-in web server. Using an ordinary web-browser over a network, users can always stay connected to the system for live monitoring, playback, or remote configuration without installing any remote client software. 5.1 Web Login The user is required to input the correct IP address in the web browser after making the web port available in the router.
55 | Full HD Digital Video Recorder 5.2 Web Configuration Menu of Web Configuration Main Classification Sub Classification SYSTEM INFO USER SYSTEM DEFAULT CAMERA AUDIO DEVICE SENSOR MOTION ALARM EXTRA ALARM RECORD SETUP RECORD PANIC RECORD SCHEDULE NETWORK DDNS NETWORK NOTIFICATION HEALTH CHECK QUICK SETUP...
Page 56
User’s Manual | 56 [Record] [Network] [Quick Setup] This web CGI screen is directly supported from the built-in web server in the DVR, regardless of Internet connection. <System Reboot> enables user to reboot the system without any changes to the setup. When the network is disconnected due to abnormal operation of the system, user can use this function and try to reconnect.
57 | Full HD Digital Video Recorder 5.3 Web monitoring The first time you access your DVR via the Web viewer, you will be asked to install Active-X file before monitoring live video. Please follow the installation process to complete the Active-X installation. Without it, you will not be able to view video from any of the DVR’s channels.
Page 58
User’s Manual | 58 ⑭ ⑬ ① ② ③ ④ ⑫ ⑪ ⑩ ⑤ ⑥ ⑦ ⑨ ⑧ Title Function Connection Mode Select to view the DVR in Live or Playback Mode. Connection Option Select to Connect or Disconnect from the DVR. PTZ control options, including: virtual direction arrows, zoom and focus, and preset.
Page 59
59 | Full HD Digital Video Recorder User can monitor live video in 1, 4, 9 or 16 screen modes. If user wants to see single channel in full screen, user can double- click on the left mouse button when the cursor is positioned on the live video screen. User can change to single mode by clicking the mode icon located at the bottom left.
User’s Manual | 60 5.4 Web Playback Users can remotely playback the DVR images by clicking “SEARCH” button in the middle of bottom window. In order to connect to DVR, the user has to click “ Connect ” button which is located at the top left corner. Playback Time ...
Page 61
61 | Full HD Digital Video Recorder Chapter 2 CMS C LIENT OFTWARE ANUAL...
User’s Manual | 62 6 CMS U UIDE 6.1 PC REQUIREMENT Recommended PC Requirement Windows XP, Vista, 7 Pentium Dual core 1.8Ghz or higher 1024X768, 256MB supporting DirectX 20MB for installation, 10GB for Remote Backup Minimum PC Requirement. Windows XP, Vista Pentium 4, 2Ghz 1024X768, 64MB 24bit color graphic card 20MB Free Space...
Page 63
63 | Full HD Digital Video Recorder Press to move to the next screen. Press to move to the next screen.
Page 64
User’s Manual | 64 Press to move to the next screen. Click to begin installation. When the installation is complete, the below message will appear.
65 | Full HD Digital Video Recorder 6.3 UNINSTALL To uninstall CMS, press UNINSTALL CMS from Start Menu of your PC. A window will appear in Windows7 or Windows Vista. Press YES to begin the process. The following window will appear.
User’s Manual | 66 When the process is complete, the below message will appear. 6.4 BASIC OPERATION Click on CMS icon on Desktop or click START on Windows PC and go to CMS Folder.
67 | Full HD Digital Video Recorder 6.4.1 Log In The default ID is Administrator, and there is no default password so please leave it blank. The administrator account has the highest level of authority on the CMS. 6.4.2 Screen Layout...
Page 68
User’s Manual | 68 Item Description Main Toolbar The Main Toolbar has three (3) selectable tabs named "Main", "Export" and (Setup Tab) "Setup". In the Setup tab, there are CMS setup and Remote setup. Main Toolbar In the Export tab, able to save, AVI and Print the images. (Export Tab) Main Toolbar In the Main tab, able to connect Live and Search, disconnect, change display...
Page 69
69 | Full HD Digital Video Recorder 6.4.4 Main Toolbar (Export) Description Item Image Capture the image of the selected (focused) channel. Movie Save the selected channel in MP4 format movie file. Print Print the selected channel. Windows Exit Minimize/Maximize the CMS Window or close the CMS program. 6.4.5 Main Toolbar (Main) Description Item...
User’s Manual | 70 6.4.6 Site List Panel The Site List displays all of the DEVICE that are currently setup for remote connection with the CMS application, and its cameras are available for view. From the Site List Panel, select the desired camera and drag it on to the viewing area. Then, select the options Live or Search ( If an DEVICE site is dragged onto the viewable area, then the selected Device or all cameras from the DEVICE will display.
71 | Full HD Digital Video Recorder Description Button 8 directional arrows allow the user to move the PTZ camera. The PTZ Camera is Navigation moved when one of these arrows are pressed to the direction desired, and stops the movement if mouse button is released.
Page 72
User’s Manual | 72 Each record mode is similar to below. No Record White Continuous (Yellow Color) Panic (Red Color) Alarm (Orange Color) Motion (Green Color) Click the time or move the time bar to the time you want to playback in the search panel. For a more detailed search like below, double-click the time that you want to jump into.
Page 73
73 | Full HD Digital Video Recorder Playback Control Panel Button Description Go to First. Forward Playback : Decrease the speed / Reverse Playback : Increase the speed. Step Forward. Reverse Playback. Pause. Forward Playback. Step Backward. Forward Playback : Increase the speed / Reverse Playback : Decrease the speed. Go to Last.
User’s Manual | 74 6.4.9 Display Panel In live mode, the text LIVE will be displayed in white, and the channel will be bordered in blue. In search mode, the text SEARCH will be displayed in red, and the channel will be bordered in red. The selected channel will be bordered in yellow.
75 | Full HD Digital Video Recorder Start the playback by double-clicking the Index number of each even list. System log shows CMS start/end, live/search, option, remote setup, image/movie export etc. 6.4.11 Information Panel The current date/time, site name, IP address, ID, channel and Live/Search status will be shown.Favorite Panel Cameras currently displayed on the screen can be added, deleted and edited as a favorite site group.
User’s Manual | 76 6.5 CMS FUNCTIONS 6.5.1 Event Search When you right click on a site in the site list, the quick access menu will be shown. Select EVENT SEARCH to run Event Search. Description Item System Connection Info Input the information of DEVICE to connect.
Page 77
77 | Full HD Digital Video Recorder Description Item System Connection Info Input the information of DEVICE to connect. Recording Directory Decide the recording directory to backup. System Recording Info Displays the start and end time of the recorded data in the system. Backup Setting Setup the start and end time of the data to backup.
User’s Manual | 78 6.5.3 Firmware Upgrade When you right click on a site in the site list, the quick access menu will be shown. Select FIRMWARE UPGRADE to run Firmware Upgrade. Description Item DEVICE Connection Info Input the information of DEVICE to connect. Firmware File Directory Decide the firmware file directory to upgrade.
Page 79
79 | Full HD Digital Video Recorder 6.5.4 Multi Monitor Click MULTI MONITOR in the Main Toolbar to run the Multi Monitor function. When you click MULTI MONITOR, you will see another separate window with the same split display as the main window. 6.5.5 Panorama Click PANORAMA in the main tool bar to run Panorama View.
User’s Manual | 80 6.5.6 Thumbnail Search Click THUMBNAIL in the main toolbar to run Thumbnail Search. This feature is only available in Search mode. First select a channel and click THUMBNAIL then, you will see the Thumbnail Search window as shown below. Item Description Date...
Page 81
81 | Full HD Digital Video Recorder Select a bookmark list and click search or double click the bookmark list to search the bookmarked data. Click REMOVE button to remove a selected bookmark list and click DELETE ALL to delete all of bookmark list. Click RENAME to rename the selected bookmark list.
User’s Manual | 82 6.6 CMS SETUP Options for DEVICE Registration, Network, User, Display, Event and other options. 6.6.1 Registration Add, Modify, Import, Export or Remove DEVICE site information. Ex) Adding a new DEVICE site.
Page 83
83 | Full HD Digital Video Recorder Item Description Name The name of the site. IP Address. Search Search the DEVICE sites in the same local network. (UPnP function) Port Port of the site. (Default: 9010) Web port Web Port of the site. (Default: 80) User ID of the site.
Page 84
User’s Manual | 84 Enable Reconnect: When the network is unstable or disconnected, it will try to reconnect periodically. When the network gets stable again, it’s reconnected. Enable Auto Connect: When you restart the CMS program again, after CMS is closed, it will reconnect to the sites just as before.
Page 85
85 | Full HD Digital Video Recorder User authority can be changed by Administrator. ID cannot be changed but should be removed. 6.6.4 Display Options for OSD setting...
Page 86
User’s Manual | 86 Title: Able to turn on/off the DEVICE title with the channel number. Date/Time: Able to turn on/off the Date/Time of the site. DEVICE Name: Able to turn on/off the name of the site. Time Format Sync: Synchronize the DEVICE time format to CMS. Record Status: Able to turn on/off the Record Status of the site.
Page 87
87 | Full HD Digital Video Recorder 6.6.6 Misc. Setup the Recording Directory, Language, Auto Upgrade, and Auto Login. Item Description Recording Directory Decide the recording directory to save images and moving images. Language Select a desired language. In order to have Auto Upgrade, input FTP information. Once the FTP setup is FTP Information done, CMS will detect the latest firmware is in the FTP and start upgrading automatically.
Page 88
User’s Manual | 88 Chapter 3 MAC ACS C LIENT OFTWARE ANUAL...
89 | Full HD Digital Video Recorder 7 MAC ACS U UIDE 7.1 System Requirement Recommended System Requirement Mac OS X 10.6(snow leopard) Built-in Intel CPU MAC Recommended More than 128MB Recommended More than 1GB 20MB Free Space Minimum System Requirement. Mac OS X 10.5( Leopard) Built-in Intel CPU MAC 64MB...
Page 90
User’s Manual | 90 Select the HDD to be installed. Press the [Continue] button to move to the next screen. Press the [Continue] button to move to the next screen Press the [Install] button to Install MAC ACS.
91 | Full HD Digital Video Recorder Put in the password and Click [OK] to begin installation. When the installation is complete, the message appears as below. 7.3 Basic Operation Click on ACS icon on Application Folder...
Page 92
User’s Manual | 92 7.3.1 Screen Layout Description Item Main Toolbar AVS Setting, Live and Search Connect, Disconnect, Image Save, Screen Mode and Change DVR List Registered DVR Site List. Possible to connect by Dragging Panel Live or Search Connect Click Live or Search mode to connect the panel Panel PTZ Panel...
Page 93
93 | Full HD Digital Video Recorder 7.3.2 Main Toolbar Button Description Site Manager Register or Delete DVR on the list Connect Connect to a site that is listed on the DVR list panel ( Select Live and Search mode at Connect Mode Panel ) Disconnect Disconnect a selected channel Disconnect All...
User’s Manual | 94 7.3.4 PTZ Panel PTZ camera controls in Live Mode. PTZ Camera can control if the channel is activated on PTZ operation. Description Button Navigation PTZ camera can be moved in 8 directions and Whenever click the direction key, it moves slowly. ZOOM Zoom In and Zoom Out FOCUS...
Page 95
95 | Full HD Digital Video Recorder 7.3.6 Search Panel Activated in Search Mode - The Search panel shows the record information for each channel. - Each record mode is like below. No Record Background Color Continuous (Yellow Color) Panic(Red Color) Alarm(Orange Color) Motion(Green Color) - Click the time or move the time bar to the time you want to playback in the search panel.
Page 96
User’s Manual | 96 7.3.7 Site Manager Add or Modify or Remove DVR site information. Press to register the DVR as follows : The default value is registered...
Page 97
97 | Full HD Digital Video Recorder To fix, Double-Click on the item. For example, Double-click “ New Site “ to change the name. After modifications have been made, press Description Function Name Fill in the name of the site to be registered Fill in the IP of the site to be registered Port Fill in the PORT No of the site to be registered ( Default 9010)
Page 119
119 | Full HD Digital Video Recorder DNS S PPENDIX EGISTRATION 1) Go to www.dyndns.com 2) Log in to the Site after registration 3) Click “ Add Hostname“ button on “Host Services”...
Page 120
User’s Manual | 120 4) Put in the IP address and Host name on the blank 5) Click “NEXT” Button 6) Click “Activate Services” button...
Page 121
121 | Full HD Digital Video Recorder 7) Confirm the domain name and IP address 8) Check the connection status It may take a little time to be completely done for DNS deployment after changed sub domain. Please recheck DVR’s IP address registered in the My Service Menu, if you can’t access DVR using dyndns. If you are using dyndns to change the IP address for the DVR to the update request, dyndns update by the circumstances that may be late.
Page 122
User’s Manual | 122 PPENDIX ETWORK ETUP FOR XTERNAL SAGE Please note: The following information are general guidelines. These may vary by networkand router specifications. Contact your installer or ISP for additional information. If you are not connecting to your DVR from within the same network, you will have to perform port forwarding on your router to be able to access the DVR externally, via the internet.
Page 123
123 | Full HD Digital Video Recorder 10 A PPENDIX PECIFICATION Model Front Image (1 HDD Case) Compression H.264 HDD Interface 1 x SATA Operation System Embedded Linux Input 4BNC 8BNC Video Output 1 x HD Output (1080p Live Display) Video Mode NTSC/PAL auto detection Display Speed...
Page 124
User’s Manual | 124 Model Central Management System Remote Web(IE) Live monitoring, Playback & System Configuration Management Internal Backup Device Local backup by USB memory stick (2ea) , External Network backup by CMS support Multi-Language, System Upgrade by USB & Network, Help menu on Major Function, Call Monitor Configuration, Advanced Function Import &...
Page 125
125 | Full HD Digital Video Recorder Model 16CH Front Image (2 HDD Case) Compression H.264 HDD Interface 2 x SATA Operation System Embedded Linux Input 8BNC 16BNC Video Output 1 x HD Output (1080p Live Display) Video Mode NTSC/PAL auto detection Display Speed 240fps@1080P 480fps@1080P...
Page 126
User’s Manual | 126 Model 16CH Central Monitoring Software Remote Web(IE) Live monitoring, Playback & System Configuration Management Internal Backup Device Local backup by USB memory stick (2ea) , External Network backup by CMS support Multi-Language, System Upgrade by USB & Network, Help menu on Major Function, Call Monitor Configuration, Advanced Function Import &...
