Summary of Contents for XENO XDR Series

  • Page 1: Chap

    Installation and User Manual for XDR Range of Digital Video Recorders...
  • Page 2 INSTALLATION & SAFEGUARDS All the safety and operating instructions should be read before operation. All the safety and operating instructions should be read before operation. Environment Condition for Installation 1. To prevent electric shock or other hazard, do not expose this unit to rain, moisture or dust. 2.

  • Page 3: Table Of Contents

    Table of Contents Features and Package Contents CHAP. 1 -------------------------------------------------------- 1-1. Features -------------------------------------------------------- Package Contents & Description 1-2. -------------------------------------------------------- CHAP. 2 Function of Buttons -------------------------------------------------------- 2-1. Front Panel -------------------------------------------------------- 2-2. Rear Panel -------------------------------------------------------- 2-3. Connector Pin -------------------------------------------------------- CHAP. 3 Installation -------------------------------------------------------- 3-1.
  • Page 4 CHAP 7 CHAP. 7 DVR Operation DVR Operation ---------------------------------------------------------- 7-1. Live Monitoring ---------------------------------------------------------- 7-2. Event Monitoring ---------------------------------------------------------- 7-3. Mouse Operation ---------------------------------------------------------- 7-4. Record ---------------------------------------------------------- 7-5. Audio ---------------------------------------------------------- 7-6. Search ---------------------------------------------------------- 7-7. Playback ---------------------------------------------------------- 7-8. Network Setup ---------------------------------------------------------- CHAP. 8 Integrated Remote Station ---------------------------------------------------------- 8-1.

  • Page 5: Features And Package Contents

    CHAPTER 1. Features and Package Contents 1-1. Features Live Display PIP (Picture in Picture), Freeze, Zoom, Sequence, PTZ function 1/4/6/8/9/13/16 Split display Record Picture image quality setup in 4 steps Schedule recording / Holiday setup Event recording by alarm and motion detection Panic recording Video Loss detection BOOKMARK function...

  • Page 6: Package Contents & Description

    1-2. Package contents 2. Remote Control 1. Digital Video Recorder ALARM BOOKMARK 6. Software CD 5. User’s Manual 3. Power Cable 4. Power Adapter 11. Mouse 8. HDD Absorber 9. Batteries 10. Rack Mount Bracket, 7. Rubber Pad HDD Bolts...

  • Page 7: Chap

    CHAPTER 2. FUNCTION BUTTONS 2-1. Front Panel <Note> This manual covers the 4 channel, 8 channel and 16 channel digital video recorders. For simplicity, the illustrations and descriptions in this manual refer to the 16 channel model. Name Function Indicating operation status ALARM Panic recording (Press ALARM and channel button together.
  • Page 8 Name Function Direction Key Navigate in the menu (while playback) OK/PAUSE/ MENU(OK), LIVE(FREEZE), PLAY(PAUSE) LEFT Backward playback (In FRZ mode: Step Backward) RIGHT Forward Playback (In FRZ mode: step Forward) Increase playback speed (Press AUDIO and UP button together for audio volume up) DOWN Decrease playback speed (Press AUDIO and Down button together for audio volume...

  • Page 9: Rear Panel

    2-2. Rear Panel <Note> <Note> You cannot mix NTSC and PAL equipment. For example you cannot use a PAL camera and a NTSC monitor. Name Function RS485 Connection with PTZ Camera or other external devices using RS485 RELAY Output Relay Output terminal SENSOR Input Sensor Input terminal VGA Output to CRT or TFT LCD Monitors...

  • Page 10: Connector Pin

    2-3. Connector Pin [1] RS232 Connection with PC to view and control DVR. Details Details N/C (Normal Close) N/C (Normal Close) RxD (Data Transmission) N/C (Normal Close) TxD (Data Transmission) N/C (Normal Close) N/C (Normal Close) N/C (Normal Close) GND (Ground) [2] VGA VGA monitor output port to view screen via PC.
  • Page 11 [4] CAMERA input & LOOP output Camera Input Loop Output [5] AUDIO AIN1 ~ AIN 4: Audio Input CH1 ~ CH4 MIC: Microphone Input AOUT: Audio Output [6] RELAY OUT Connection with PTZ camera, sensor, relay output. Details Details Details RS485 D RS485 D- ALARM D14...

  • Page 12: Installation

    CHAPTER 3. INSTALLATION 3 1 C 3-1. Configuration [Typical DVR Installation]...

  • Page 13: Detailed Configuration

    3-2. Detailed Configuration 1) Rack mount ALARM BOOKMARK 1. Remove all 4 bolts on side caps. 2. Attach Rack mount bracket to DVR. 3. Attach DVR with rack mount bracket to 19” Rack. 2) HDD (Hard Disk Drive) connection 1. Connect Main Board and HDD1 using SATA cable and HDD power cable. 2.
  • Page 14 [3] Camera LEVEL VIDEO VIDEO LENS AC24V/DC12 Rear view of CAMERA Connect cameras to the camera input on rear panel of DVR marked CAMERA IN. [4] Monitor VIDEO A VIDEO B VIDEO C Connect the video output marked MONITOR to VIDEO-IN of Main Monitor.
  • Page 15 [6] SPOT Connect with the spot monitor as needed. [7] OTHERS SPEAKER MONITOR PAN /TILT CAMERA CAMERA SENSOR SIREN RS232C : Control DVR through RS232C port by using PC. RS485 : Control external device such as PTZ Cameras. (Pin No.1 ~ 2 at Terminal Block). RELAY Output : (Pin No.4 ~6 at Terminal Block).

  • Page 16: Display Configuration

    CHAPTER 4. Display Configuration Date/Time, HDD, Playback Current Status Display status icons Displa Stat s Display Status Monitoring popup menu in live mode Playback popup menu in playback mode Popup Menu PTZ control popup menu in PTZ mode Playback toolbar, PTZ toolbar Toolbar...

  • Page 17: Current Status

    4-1. Current Status [1] Date/Time Live mode : Shows current date & time Playback mode : Shows recorded date & time of the playback image [2] HDD Live mode : HDD recorded space is marked red on the percentage bar. Available remaining days/time at current record mode is shown.

  • Page 18: Popup Menu

    4-3. Popup Menu By clicking right button of mouse, Monitoring popup menu appears in live mode, Playback popup menu appears in playback mode, PTZ control popup menu appears in PTZ p p p mode. 1) MONITORING POPUP MENU While in LIVE display, click right button of mouse and MONITORING popup appears. In full screen mode: All sub-menus are activated.
  • Page 19 3) Previous Page In full screen mode, clicking Previous Page menu will switch screen to lower number channel. After channel 1, it rotates to channel 16. In split screen mode, clicking Previous Page menu will switch screen to lower number channel groups.
  • Page 20 11) Search Only the Admin and Manager have authority to access this Menu. It is to search recorded data easily and playback. Search by Time/Date, Event list and Bookmark is available. 12) Setup Menu Only the Admin and Manager have authority to access and change all settings on all Sub-Menus. [2] PTZ CONTROL Popup While in PTZ mode, click right button of mouse and PTZ popup appears.
  • Page 21 7) Zoom : On / Off In full screen mode, Zoom icon activates and Live screen zooms in x2. Move selected frame by mouse control or arrow keys. In split screen mode select channel button to activate zoom icon and live screen zooms in x2 In split screen mode, select channel button to activate zoom icon and live screen zooms in x2.

  • Page 22: Toolbar

    4-4. Toolbar [1] PLAYBACK Toolbar Button Function Go to the first image Move to the beginning of playback Decrease speed Playback speed decreases in forward playback (Playback speed increases in backward playback) Backward playback Playback in reverse direction Previous image Shows previous image in freeze mode Freeze Freeze...

  • Page 23: Dvr Setup

    CHAPTER 5. DVR SETUP 5-1. Operation 1) Main Menu Setup Group Details System Information, Date/Time, Storage, User, Logout Network LAN, Notification Devices Display, Camera, Audio, Remote Control Record Setup, Schedule, Pre-event, Backup Event Alarm, Motion, Video Loss, Alarm-out, Buzzer...
  • Page 24 [2] Initialization INITIALIZE DVR SYSTEM… When powered on messages When powered on, messages BOARD/PERI DEVICE.. HDD2 displays in order. INITIALIZE DVR SYSTEM INITIALIZE DVR SYSTEM… System will check for connected CHECK INTERNAL HDD1.. SKIP HDDs. If no HDD is connected, it will move to the next message.
  • Page 25 [3] System Login MONITORING go to CHANNEL go to CHANNEL SPLITTER 1) Press right button of mouse or press [MENU] button and MONITORING screen appears. PTZ CONTROL FREEZE ZOOM SEQUENCE AUDIO PANIC PANIC PLAYBACK SEARCH SETUP MENU 2) Click Setup Menu and Login window appears. 3) Click User and you can select user grade from the scroll box.

  • Page 26: System

    5-2. System [1] Information - Language : Select language of System Menu among English, French, Spanish, Italian, Portuguese, Dutch, Russian, German, Turkish and Polish. - Version : Current firmware version Version : Current firmware version. - Upgrade SW : Update current firmware. - Import Setup : Bring setup values saved from USB storage.
  • Page 27 Click Upgrade SW button and pop-up box appears. - Storage Status : Shows firmware update progress. (See chapter 11 for warning and error messages). - Upgrade File : Name of file to upgrade. -Information : Shows error code in case of error. Recording will stop while upgrading.
  • Page 28 [2] Date / Time 1) Date / Time Set Date/Time of system. DATE/TIME HOLIDAY TIME SYNC DATE 2007 TIME DATE FORMAT 2007/12/10 MONTH FORMAT TIME FORMAT TIME ZONE TIME ZONE (GMT+00:00) UK (GMT) (GMT+00:00) UK (GMT) USE DST SAVE DEFAULT CANCEL - Date : Set Year, Month, Day.
  • Page 29 2) Holiday Set national holidays or holidays on calendar to record as setting for Sunday in Schedule Record l h lid h lid i S h d l R Setup. DATE/TIME HOLIDAY TIME SYNC MONTH 01/01 DELETE SELECT DAY OF WEEK SUNDAY SAVE DEFAULT...
  • Page 30 3) Time Sync - Automatic Sync : Choose between On/Off. Automatic Sync : Choose between On/Off - Time Server : Input sync server IP address (SNTP). - Retry Count : Select from 1 to 30 retries. - Interval : Automatic Sync Interval (0.5, 1, 2, 3, 4, 5, 6, 12, 24 hours) - Last Sync-Time : Shows time of Last Sync.
  • Page 31 When format button is pressed, new window appears to confirm. Press Format button again to begin. [4] User [4] User Set password for each user grade or check Auto Login checkbox for auto Login. - User : Choose from admin, manager, user 1 ~ user 8. - Password : Set password for each user grade.
  • Page 32 If you click Password, Change Password message box appears. Click Current Password, Current Password message box appears. Password is from 1 digit to 8 digit numbers. Click Authority button and Authority Setup window appears. Assign authority level for each user grade. Check checkbox of contents for Manager &...
  • Page 33 [5] Logout 1) Warning message box 1) Warning message box When Logout is selected from [Menu] [System] [Logout], warning message box appears as below. - If you press Logout button from the message box, the device will not remember current user ID and in order to Login to system menu again, system login window will appear again.

  • Page 34: Network

    5-3. Network 1] LAN 1) Ethernet Setup to enable viewing live screen or searching/backup recorded data on HDD remotely over the network. ETHERNET ETHERNET DDNS DDNS TRANSMISSION TRANSMISSION MAC ADDRESS 00 - 0A - A2 - 0B - 08 - 83 IP TYPE DYNAMIC DHCP...
  • Page 35 2) DDNS Set DDNS Server Connection. - DDNS On/Off : Select On to enable, Off to disable. - DDNS Server : Input server domain name address. Input server domain name, or select Static IP to input IP address manually. - PORT : In case of firewall, contact your network administrator. Port setup is from 10 to 65000.
  • Page 36 [2] Notification 1) EMAIL - Send E-mail On/Off : Select ON to enable, OFF to disable. - Retry Count : Number of times of retrial (Set from 1~30) - Send Sever IP : Enter the SMTP server IP. Send Sever IP : Enter the SMTP server IP. - Send Port: Enter the SMTP server port number obtained from your system administrator.
  • Page 37 2) Event DVR can be set to send event lists to CMS program. DVR can be set to send event lists to CMS program. See Chapter 7-9 [5] Event for more details. - Active : Check checkbox to activate. - IP address : Shows IP address of the PC, in which event server program runs. - Port : Shows Port of the PC, in which event server program runs.

  • Page 38: Devices

    5-4. Devices [1] Camera 1) Camera Set title, colour, hue, contrast of cameras. - No.: Click to display Copy Setting box. - Title : Change the Title of each camera using the virtual keyboard (Maximum 12 letters) - Covert : Select ON channel will not be displayed on Live View screen. - Adjustment : Adjust display brightness, contrast, saturation, hue, horizontal position of each camera.
  • Page 39 <Note> After typing in title, press Set button to save title. * Title can be of maximum 12 letters. Click Adjustment button and Camera colour /H setup window appears. - Brightness : -32 ~ +31 - Contrast : -32 ~ + 31 - Saturation : -32 ~ +31 - Hue : -32 ~ +31 - Position : -16 ~ +15...
  • Page 40 2) PTZ - Protocol : Click Protocol column and select camera from the list. - PTZ ID : Assign IDs to each camera from 0 to 255. - Speed : Set PTZ control speed from 1 to 7 level. - Baud rate : Set RS232 communication speed. Set communication speed among 9600, 19200, 38400, 67600 and 116200.
  • Page 41 [3] Display 1) OSD OSD window allows you to select what information will be displayed n Live and Playback screen. - Date/Time : Check checkbox to display Date/Time on Live screen. - Percentage Bar : Check checkbox to display Percentage Bar : Check checkbox to display recorded percentage on HDD on Live screen.
  • Page 42 Main If Event Popup is Off, you can set DVR to sequence cameras. If Event Popup is On event channel screen appears If Event Popup is On, event channel screen appears. MAIN SPOT SEQUENCE MODE SEQUENCE MODE FULL 1 Ch FULL 1 Ch SEQUENCE INTERVAL SECOND...
  • Page 43 3) Spot - Spot Monitor : Set Spot monitor On or Off. - Spot Event Type : Select Event type among Motion, Alarm and both. - Spot Dwell : Set dwell-time among 1, 2, 3, 4, 5, 10, 15, 20, 30 seconds. g , , , , , - Spot Channel : Click Spot Channel button to popup Spot Channel Selection window.
  • Page 44 [4] Remote Control 1) RS232 REMOTE CONTROL - Baud rate : Set value among 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200. - Data bite : Set value from 5 to 8. - Stop bite : Set value between 1 and 2. - Parity : Set value among None, Odd and Even.
  • Page 45 [5] Buzzer Select Buzzer On/Off Select Buzzer On/Off. ALARM-IN - Key Beep : Set On/Off in case mouse or keyboard panel is pressed. - Video Loss : Set On/Off in case of Camera Loss. - Alarm-In : Set On/Off in case external sensor input is detected. - Motion Detect : Set On/Off in case motion is detected.

  • Page 46: Record

    5-5 Record [1] Setup Channel : Set the recording profile for Time recording Event/Panic : Set the recording profile for Alarm, Motion detection and Panic 1) Channel Set the recording quality for each channel in time recording. - No.: Click to display Copy Setting box. - Resolution : Set resolution among CIF, H-D1 &...
  • Page 47 2) Event/Panic Set the event recording quality for each channel. Set Event/Panic Record Profile. - The channel with latest EVENT/PANIC will follow setting for ACTIVE and the rest channels will follow setting for NON ACTIVE. -RESOLUTION : Set Resolution among NO CHANGE, CIF, 2CIF & D1. NO CHANGE : Follow same setting for CHANNEL SETUP.
  • Page 48 [2] Schedule S t Ti Set Time and Type of Schedule recording for each channel. f S h d l - Record Type : Time : CONTINUOUS ALARM-IN : Sensor In MOTION MOTION : Motion Detection M ti Channel button : Click to display Copy Setting box. In normal cases (Unless you press Panic button), DVR records based on the schedule established in the Schedule screen.
  • Page 49 [3] Pre-Event Set Quality and recording time for Pre-Event, which saves recorded data before event occurs. - Channel checkbox : Check checkbox to turn each camera on for pre-event recording. - Set each camera on or off for pre-event recording. - Quality : Set recording quality among Low, Normal, High &...
  • Page 50 [4] Backup 1) CD-RW Backup Recorded video Information - From : Start time of recorded data on HDD. -To : End time of recorded data on HDD. Backup Information - Media : Size of the inserted media (CD/DVD). - From : Start time of data to backup on CD-RW. - To : End time of data to backup on CD-RW.
  • Page 51 [4] USB Backup Recorded Image information - From : Start time of recorded data on HDD. -To : End time of recorded data on HDD. Backup Information - Media : Size of the recorded data on HDD. - From : Start time of data to backup on USB. - To : End time of data to backup on USB.

  • Page 52: Event

    5-6. Event [1] Alarm [1] Alarm 1) Alarm-In Set sensor On / Off and dwell-time for each channel in case external sensor activates. - No.: Click to display Copy Setting box. - Type : Set external sensor input NO/NC/Off for each camera. - Beep : Set beeping sound On / Off.
  • Page 53 2) Alarm-Out - Day : Select day of a week for output among All, Monday ~ Sunday, Weekday and Weekend. - Start Time : Select start time for Alarm output Start Time : Select start time for Alarm output. - End Time : Select end time to finish alarm output. - Mode : Select mode among Event, On and Off.
  • Page 54 [2] Motion 1) S t 1) Setup Set Motion Detection for each channel. - No.: Click to display Copy Setting box. - Type : Set motion mask On/Off for each channel. - Beep : Set beeping sound On / Off in case preset event occurs. - Sensitivity : Set sensitivity among Very High, High, Standard, Low &...
  • Page 55 Motion Mask Zone setup window Motion Mask Zone setup window Deactivates Motion Detection Activates Motion Detection - Cell Setup Click left button of mouse to set Motion Mask Zone by selecting or clearing blocks. - Block Setup Click selected cell and drag it to desired position All cells within the block will be selected Click selected cell and drag it to desired position.
  • Page 56 2) Action Set Alarm-Out On / Off for each channel in case motion is detected. - No.: Click to display Copy Setting box. - Alarm-Out : Set On / Off for sending alarm signal to relay output terminal. - Duration : Set alarm dwell-time from 1 to 99 seconds. - Event Refresh Time : Set interval from 1 to 99.

  • Page 57: Search

    CHAPTER 6. Search To search for recorded data in various modes (Schedule, Event, Continuous) easily and then playback. Search by Calendar, Event list and Bookmark are available. Pressing the right button of mouse will display MONITORING screen and click Search. Or press [SEARCH] button to enter into Search menu.
  • Page 58 Days with recorded data display on the calendar with white numbers. Click the number and information of selected date and time appears as below. - If dots are white, it means it contains recorded data. If dots are black, there is no recorded data. - Select white dot, or input time in ‘go to’...

  • Page 59: Event Search

    6-2. Event Search Recorded data for Event (Motion, Alarm, Loss, Panic) displays on Event Search. - << Shows previous month. - >> Shows next month. >> Sh First : Date/Time of the first event recorded. Last : Date/Time of the last event recorded. - Exit : Exit search menu.
  • Page 60 Click Time of event you wish to see and click PREVIEW or PLAYBACK. - All Type : Event selection among All Type, Motion, Alarm, Loss and Panic. List of selected event will be shown. - Channel : Channel selection among All, 1ch~16ch. List of selected channel will be shown.

  • Page 61: Bookmark Search

    6-3. Bookmark Search The Bookmark search screen displays a list of the video associated with bookmark in the playback mode. - Time : Shows time of the bookmarked list. - Login : Shows user grade who bookmarked the list. S o s use g ade o boo a ed t e st - Delete Checkbox : Check box of the list to delete.

  • Page 62: Dvr Operation

    CHAPTER 7. DVR OPERATION 7-1 Live Monitoring Once the DVR completes its initialization, the live screen is displayed on the connected monitor with live th DVR it i iti li th li i di ith li audio through connected speaker. Default mode is displaying all connected camera channels at once. Pressing a certain camera channel button will switch display to the full screen mode of the selected camera.
  • Page 63 3] Sequence While in full screen mode, press [SEQ] button to cause the connected cameras to display sequentially according to the preset dwell-time. Access [MENU]-[Device]-[Display]-[Main Monitor]-Sequence Interval Popup for dwell-time setup. Access [MENU]-[Device]-[Display]-[Main Monitor]-Sequence Mode Popup for channel display mode. Press the button again or switch to other display format to exit sequence mode.
  • Page 64 7] PTZ User with PTZ Control Authority can control PTZ cameras. (Access [Menu]-[System]-[User]-Authority and check checkbox for user authority for PTZ control) Access [Menu]-[Device]-[Camera]-[PTZ] to setup PTZ model, PTZ ID and Baud rate. MONITORING MONITORING go to CHANNEL go to CHANNEL SPLITTER SPLITTER PTZ CONTROL...
  • Page 65 Set preset position for PTZ cameras. Press [SET PRESET] button or click Set Preset from PTZ Control popup menu or click Set Preset from PTZ Control popup menu. SET PRESET By setting the position of cameras, user can view the area of preset position of cameras easily.

  • Page 66: Event Monitoring

    Easy PTZ control with mouse operation: With virtual joystick, user can control PAN left/right, TILT up, down with mouse operation. Button Button Function Function WIDE Zoom in TELE Zoom out NEAR Focus near Focus far OPEN Iris open CLOSE Iris close EXIT Exit PTZ control JOYSTICK...

  • Page 67: Mouse Operation

    7-3. Mouse Operation For easy operation while live monitoring, user can use mouse instead of key buttons. In split screen mode, double clicking a certain channel screen will switch the channel into a full screen mode. Double clicking the screen again will return to previous split display mode. Click right button of mouse while live monitoring and popup menu appears as below: MONITORING MONITORING...

  • Page 68: Record

    7-4. Record [Record Setup] (1) F (1) For Record, user must have authority for Record. th it f (Access [Menu]-[System]-[User]-[Authority] and check Record) (2) For Continuous record: Access [Menu]-[Record]-[Setup]-[Channel]-[Resolution] and set record quality settings. If you set FPS to OFF, recording will stop. For Event/Panic record: Access [Menu]-[Record]-[Setup]-[Event/Panic]-[Resolution] and set record quality settings.
  • Page 69 [1] Calendar Search Days with recorded data will be highlighted in white colour. Click a day to see the recorded data in details by time and minute. Channel : If ALL is selected, the dots will show if it contains recorded data or not, but if a certain channel number is selected, dots will show in 4 colours showing its recording mode.
  • Page 70 [2] Event search Every time an Alarm-Input port is activated, a new event list will be created. Days with recorded data will be highlighted in white colour. Click a day to see the recorded data lists. Click a day to see the event list of the day. -Select type of events to be listed among All Type, Motion, Alarm, Loss and Panic.

  • Page 71: Playback

    [3] Bookmark search Admin or Manager can create bookmark list up to 24 lists each. While in Playback mode, every time Admin or Manager presses the BOOKMARK button, a new time data will be created on the list. Bookmark : 09 2009/04/21 06:23:47 When bookmark lists are full, message appears as below: Bookmark Over !
  • Page 72 SEARCH / STOP Pressing STOP button from Playback mode will switch screen to Live mode. Pressing SEARCH button from Live mode will switch screen to Search mode. SEARCH b tt it h CHANNEL BUTTON Press camera channel button and the associated camera screen will display in full screen mode.

  • Page 73: Network Setup

    7-8. Network Setup [1] DVR Network Setup Check Network 1) Click Windows START button. 2) Click RUN and input “cmd”. 3) Input “ipconfig” from COMMAND AND PROMPT. 4) Check IP address, Subnet Mask and Gateway. 5) Type “Ping xxx.xxx.xxx.xxx (IP address)”. If you see “Request timed out”...
  • Page 74 [2] Static IP Input IP address assigned from Internet Service Provider in IP SETUP. 1) Verify if IP address is OK with your PC before connecting the DVR. 2) Connect static IP LAN cable to DVR after verification: Router connection Router ISP Company Remote PC...
  • Page 75 3) Access [Menu]-[Network]-[LAN]-[Ethernet] in DVR. 4) Set IP TYPE to STATIC. 5) IP address popup button p p p In case of router connection As in PC setup, assign internal IP address to DVR. (Ex: 192.168.0.105) Assigned IP address should only be used for DVR internally. In case of direct connection As in PC setup, assign static IP address to DVR.
  • Page 76 12) Cli k Cli 12) Click Client Setup and click Add t S t d li k Add button. 13) Address / Port / User ID / Password Box : In case of Router connection Internal connection Address : Input assigned IP address to DVR. (Access [Menu]-[Network]-[LAN]-[Ethernet] to see assigned IP address) Port: Input Port number.
  • Page 77 [3] Dynamic IP Select DYNAMIC IP from DVR’s TCP/IP SETUP and IP address will be assigned from ISP’s DHCP server. 1) Verify if IP address is OK with your PC before connecting DVR. 2) Connect dynamic IP LAN cable to DVR after verification. Router connection Router ISP Company...
  • Page 78 3) Turn off Modem provided by ISP company and turn it on again. (This process is to reset client’s MAC from ISP company. Wait for 30 seconds after turning it on.) 4) If modem works fine, turn DVR off and turn it on again. 5) Access [Menu]-[Network]-[LAN]-[Ethernet] in DVR.
  • Page 79 11) Click Client Setup and click Add button 11) Click Client Setup and click Add button. 12) Address / Port / User ID / Password Box : In case of Router connection Internal connection Address : Input assigned IP address to DVR. d IP dd t DVR (Access [Menu]-[Network]-[LAN]-[Ethernet] to see assigned IP address)
  • Page 80 [4] e-mail setup 1) Send Server IP address setup In Send Server IP box, input SMTP server IP address received from System Manager. Open Outlook Express and click Ope Out oo p ess a d c c TOOLS(T) – ACCOUNT(A). Click PROPERTY(P) and property window appears as left image.
  • Page 81 Click SERVERS tap and you can check SMTP address. Click Windows START button and click RUN and input “cmd”. Input “ping xxxxx.xxx(SMTP address)” and you can check IP address. Set this IP address in Send Server IP popup button.
  • Page 82 2) Send Port Setup Input 25 for e-mail port number in DVR. 3) Send Server ID / Send Server PW Setup Input ACCOUNT NAME(C) to Send Server ID on your DVR. Input PASSWORD(P) to Send Server PW on your DVR. 4) Recipient Setup Input E-MAIL ADDRESS(M) to Recipient on your DVR.
  • Page 83 Received e-mail will show details as below:...

  • Page 84: Integrated Remote Station

    CHAPTER 8. Integrated Remote Station 8-1. IRS Setup 1) See PC specification below for IRS operation. Contents Minimum system Recommended system requirement requirement Intel Pentium 4 3.0GHZ Intel Pentium 4 Core2Duo 1.8 or higher Main memory 512MB 1GB or higher Video memory 128MB 512MB or higher...
  • Page 85 4) If you want to review or change any of installation settings, click [BACK], or if you want to proceed, click [NEXT]. 5) When you click [NEXT] button, you will see installation process and when installation is done, S-IRS icon will be created on windows background.

  • Page 86: Irs Operation

    8-2. IRS Operation [1] IRS (I t [1] IRS (Integrated Remote Station) Display t d R t St ti ) Di - CLIENT SETUP: Setup for network connection. - REMOTE SETUP: Change DVR setup remotely over network. - REMOTE VIEWER: View live display of DVR. - SEARCH: Search recorded data on DVR HDD.
  • Page 87 [2] Client Setup - ADDRESS : Input same IP address set on DVR. - PORT : Input same Port number set on DVR. - USER ID: Input same ID as in DVR. - Password: Input same Password as in DVR. <Note>...
  • Page 88 - REGISTERING SITE : Register IP Setup Value of IP SETUP box to SITE SETUP box. - UPDATE : Edit IP Setup Value registered on SITE SETUP box. - DELETE : Delete IP Setup Value registered on SITE SETUP box. - SAVE : Save IP Setup Value registered on SITE SETUP box.

  • Page 89: Remote Viewer

    8-3. Remote Viewer [1] Remote Viewer 1) DVR connection setup: Input IP address, Port number, ID, Password for network connection to DVR. 2) System Information: Displays DVR connection and progress status. 3) Audio channel : Select an audio channel to turn on. Note that the ‘Enable Audio’ checkbox in 7) Setup should be checked as enabled and both Refresh Rate and Quality should be set to ‘Low’, otherwise audio quality may suffer.

  • Page 90: Search

    8-4. Search [1] Search [1] Search 1) DVR connection setup : Input IP address, Port number, ID, Password for network connection. 2) System information : Displays connection status and system operation information. 3) Start/End/Now : Displays start time, end time of total recorded data and current time. 4) Event : Click to pop up window for search by date, event and bookmark.
  • Page 91 <Buttons from left to right> Backward playback Freeze Playback go to the first image Fast backward playback Fast playback go to the last image 11) A di 11) Audio channel : Select audio channel to turn on. l S l l t t [2] Percent / Date search Click EVENT button from main Search page.
  • Page 92 [3] Event list search Click date on calendar and Event List of the day will be displayed. Select event and click OK to Select event and click OK to playback, or just double click the event. Left / Right button : Displays Previous / Next 100 lists.

  • Page 93: Backup

    8-5. Backup 1) To run BACKUP, input IP Address and Port and click Connect Test button. 2) Click Connect Test button and when network connection is successful, “Success Connect Test!“ message will appear in the message box.
  • Page 94 3) Click Lock button and receive information about the recorded start time / end time from DVR. It will automatically update information every 10 seconds, or click Update button for immediate update. 4) Click Set Backup Time button and set Start Time, End Time, Save File Path, File Size and click Apply button.
  • Page 95 - Recorded Start Time : Start time of recorded data on HDD at the time of clicking LOCK button. - Recorded End Time : End time of recorded data on HDD at the time of clicking LOCK button. - Save File Path : Set path to save backup file on PC. - Maximum Save File Size : Split file size into 10MB,50MB,100MB,150MB, 200MB ~ 700MB.

  • Page 96: Player

    8-6. Player [1] Player 1) TIME : Displays start time, end time, current playback time. 2) SPEED/SLOW MOTION : Control playback speed. SPEED: Set fast playback speed : 2x, 4x, 8x, 16x 32x SLOWMOTION: Set slow playback speed : 1x, 1/2x, 1/4x, 1/8x, 1/16x, 1/32x 3) Audio channel : Select audio channel to turn on.
  • Page 97 [2] Player – Edit Panel < IMAGE EDIT > 1) CONTRAST: Set contrast in full screen mode. : Make bright part brighter and dark part darker. : To reduce light and shade, lower contrast. 2) BRIGHT: Set brightness in full screen mode. : Make image brighter.
  • Page 98 [3] Player – AVI Save Panel < AVI SAVE > 1) AVI Save Option: Set frame rate, size of file to be saved in AVI format. CHANNEL : Select channel of image to save. FRAMERATE : Select FPS of image to save. SIZE : Select file size of the image to save.

  • Page 99: Appendix A Frequently Asked Questions

    Appendix A. Frequently Asked Questions 1. Turned power switch to ON, but DVR doesn’t turn on. Check if power cord is properly connected to DC 12V power jack. 2. After turning on DVR, Power LED on front panel lights, but no video output on monitor. Check if monitor is turned on.

  • Page 100: Appendix B Map Of Screens

    Appendix B. Map of Screens Setup Menu System Information Information Date/Time Date/Time Holiday Time Sync Storage Information User User Logout Network Ethernet Ethernet DDNS DDNS Transmission Transmission Email Event Notification Devices Camera Camera Audio Audio Display Main Spot Remote Control RS232 REMOTE CONTROL Buzzer...

  • Page 101: Appendix C Factory Default Settings

    Appendix C. Factory Default Settings When you press Default All button on [Menu]-[System]-[Information] all the settings will be defaulted as ex- When you press Default All button on [Menu] [System] [Information] all the settings will be defaulted as ex factory setting values. See below for detailed factory default values. <...
  • Page 102 < Network Menu > MENU SUBMENU MENU TITLE FACTORY DEFAULT SETTINGS Ethernet MAC Address 00-0A-A2-08-08-68 IP TYPE Dynamic Port 50000 DDNS DDNS On/Off DDNS Server DDNS Server Static IP Static IP 211.062.253.088 00080 DVR ID SDVR16CH Update Interval Last Update Last Update ----/--/-- --.--.-- Transmission...
  • Page 103 < Device Menu > MENU SUBMENU MENU TITLE FACTORY DEFAULT SETTINGS Camera Camera Copy Settings CH1: Checked, CH2~CH16: Not checked Title CAM01 ~ CAM16 Covert Adjustment Brightness Contrast Saturation Position -> +7 Copy Settings S tti CH1 Ch CH1: Checked, CH2~CH16: Not checked CH2 CH16 N t h Protocol Vista PowerDome...
  • Page 104 MENU SUBMENU MENU TITLE FACTORY DEFAULT SETTINGS OSD Margin Left Right + 15 Bottom Main Sequence Mode Full 1 Ch Sequence Interval Event Popup Popup Event Type Alarm Popup Dwell 7(Lower left location) DURATION 1(PIP SWITCHING INTERVAL) Spot Spot Monitor Spot Event Type Spot Dwell Spot Channel...
  • Page 105 < Record Menu > MENU SUBMENU MENU TITLE FACTORY DEFAULT SETTINGS Setup Setup Channel Channel Resolution Resolution 2CIF 2CIF Quality High Overwrite Not checked Event/Panic e / a c EVENT ACTIVE NON ACTIVE Resolution 2CIF NO CHANGE Quality High NO CHANGE PANIC ACTIVE NON PANIC...
  • Page 106 < Event Menu > MENU SUBMEN MENU TITLE FACTORY DEFAULT SETTINGS Alarm Alarm-In Type Beep Alarm-Out 1 Not checked Alarm-Out 2 Not checked Duration Event Refresh Time Alarm-Out Start Hour 00, 00 End Hour 23, 59 Mode Event Alarm-Out 1 Checked Alarm-Out 2 Checked...
  • Page 107 MENU SUBMENU MENU TITLE FACTORY DEFAULT SETTINGS Action Alarm-Out 1 Not checked Alarm-Out 2 Not checked Duration Event Refresh Time Video Loss Video Loss Video Loss Video Loss Beep Beep Alarm-Out 1 Not checked Alarm-Out 2 Not checked Duration Event Refresh Time Event Refresh Time...

  • Page 108: Appendix Dhdd Calculation

    Appendix D. HDD Calculation Below is the 500GB HDD calculation for Estimated Size/Day and Estimated Day/HDD according to Resolution and Quality Quality: Low Quality: Normal Quality: High Quality: Very High 1fps 16GBx27day 19GBx23day 23GBx19day 27GBx16day 2fps 19GBx23day 20GBx21day 26GBx17day 31GBx14day 3fps 20GBx21day 23GBx19day...

  • Page 109: Appendix E Specification

    Appendix E. Specification • Real-Time Live Display in all Channel • Quadplex (Live, Playback, Recording, Network) • Multi Language • Remote monitoring and Download through Network • Convenient Search Function with Jog/Shuttle • Firmware Upgrade via USB Port ALARM BOOKMARK •...
  • Page 110 Contents 4 Channel 8 Channel 16 Channel Recording & Playback Quadplex Multi-tasking (Live, Playback, Recording, Network) Multi Channel Playback Available Event Log information Available Pre-Alarm Available Alarm / Relay Video Loss Alarm Available Motion detection Alarm Available Network Remote S/W Integrated Remote Station : Monitoring, Search &...

  • Page 111: Appendix F Remote Control

    Appendix F. Remote Control PTZ CONTOL PTZ On/Off SET PRESET Search Menu SEARCH CLEAR PRESET CLEAR Menu MENU go to PRESET go to AUTO PAN <No functions> AUTO <No functions> <No functions> Select Ch / Input Number <No functions> Indicates 2 digits ‘0’+‘0’...
