NEC EXPRESS5800/R110d-1E Configuration Manual page 4

CONFIGURATION GUIDE
Model
Power
Consumption
Acoustical Noise
(Sound Pressure
3
Level)
Dimensions (W x D x H )
Weight (Minimum / Maximum)
Temperature, Relative Humidity
(non-condensing)
Regulatory and Safety
Pre-installed Operating System
Operating Systems
1
RAID 10 configured with 2 TB HDDs is not supported on the on-board SATA Controller.
2
The on-board SATA RAID controller is not supported on Linux operating systems.
3
Noise emission was measured in accordance with ISO 7779. The actual value may vary by the operating
environment.
4
For Linux support, contact our sales representative or go to the NEC website at:
http://www.nec.com/global/prod/express/linux/index.html
2.5-inch Drive Model
Model
Part Number
Processor
Chipset
Memory
Internal Storage
NEC Corporation
–
NEC EXPRESS5800/R110d-1E
(100VAC, Max. Config,
Idling)
(100VAC, Max. Config,
Operating)
Minimum Config.
Maximum Config.
Type
Clock Speed
Number of Processor
Cache
Cores and Threads
Type
Standard Capacity
Maximum Capacity
Standard Capacity
Maximum Capacity
Disk Controller
Revision 1.0, June 2011
R110d-1E
108 VA / 102 Watt 109 VA / 105 Watt
161 VA / 159 Watt 223 VA / 222 Watt
42.3 dB 39.3 dB
43.1 dB 48.8 dB
444.0 x 615.2 x 43.6 mm / 17.5 x 24.2 x 1.7 in (1U)
10 kg / 18 kg, 22.05 lbs. / 39.68 lbs.
Operating: 10° to 35° C / 50° to 95° F, 20 to 80%
Non-Operating: -10° to 55° C / 14° to 131° F, 20 to 80%
FCC, CE, BSMI, CCC, UL, CB, RoHS, WEEE
-
Microsoft® Windows Server® 2003 R2, Standard Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Standard x64 Edition SP2 or later
Microsoft® Windows Server® 2003 R2, Enterprise x64 Edition SP2 or later
Microsoft® Windows Server® 2008 Standard
Microsoft® Windows Server® 2008 Standard (x64)
Microsoft® Windows Server® 2008 Enterprise
Microsoft® Windows Server® 2008 Enterprise (x64)
Microsoft Windows Server 2008 R2 Standard
Microsoft Windows Server 2008 R2 Enterprise
Red Hat Enterprise Linux 5.6 or later
Red Hat Enterprise Linux 5.6 or later (EM64T)
R110d-1E
N8100-1745F
Intel® Pentium® Intel® Xeon®
processor G620 processor E3-1220
2.60 GHz 3.10 GHz
1/1
3 MB 8 MB
2C / 2T 4C / 4T
Intel® C204 Chipset
DDR3-1333 ECC Unbuffered DIMM
0 GB
32 GB (4 x 8 GB)
0 GB
SAS : 5.4 TB (6 x 900 GB)
SATA : 6 TB (6 x 2 TB)
SSD : 600 GB (6 x 100 GB)
SATA : 3 Gb/s (Integrated)
SAS : 6 Gb/s (Optional)
109 VA / 106 Watt
281 VA / 270 Watt
39.3 dB
48.8 dB
4
4
Intel® Xeon®
processor E3-1270
3.40 GHz
8 MB
4C / 8T
4
