Marco Beverage Systems Ltd.
INSTRUCTIONS FOR MODELS
ECOSMART PB10, ECOSMART PB10 Hi Deck
(P/N: 1000677, 1000678, 1000677US, 1000678US, 1000677MJ, 1000678MJ)
Water pressure : 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.)
Marco Beverage Systems Limited.
63d Heather Road,
Sandyford Industrial Estate,
Dublin 18.
Ireland Tel: +353 (0)1 295 2674
Ireland Fax: +353 (0)1 295 3715
email: sales@marco.ie
www.marco.ie
(4EF8)
(4JD5)
E337347
Marco Beverage Systems Limited.
Shire House, Strixton Manor,
Strixton, Wellingborough, Northants,
NN29 7PA
UK Tel: +44 (0)2072 744 577
UK Fax: +44 (0)2079 788 141
email: sales@marco-bev.co.uk
www.marco-bev.co.uk
Advertisement
Table of Contents
Related Manuals for Marco ECOSMART PB10
Summary of Contents for Marco ECOSMART PB10
- Page 1 Marco Beverage Systems Ltd. INSTRUCTIONS FOR MODELS ECOSMART PB10, ECOSMART PB10 Hi Deck (P/N: 1000677, 1000678, 1000677US, 1000678US, 1000677MJ, 1000678MJ) (4EF8) (4JD5) E337347 Water pressure : 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.) Marco Beverage Systems Limited. Marco Beverage Systems Limited.
-
Page 2: Installation Details
S AFETY: This appliance must be earthed. Risk of flooding. A hose is not supplied with this unit. When connecting to the water mains it should be considered that a hose is not a permanent connection. It is, therefore, advisable to switch off boiler and close the stopcock valve when boiler is not in use, e.g. - Page 3 The “power on” light will glow green and the machine will fill to a safe level, above the elements, before heating. The display will show the current water temperature and the status “Filling…”. The “Ready/Status” light will cycle two red flashes while the machine is filling to the safe level.
-
Page 4: User Set Up Options
Entering Setup Mode To enter setup mode press power and eco buttons on the front panel at the same time. The display will show “USER SETUP” message: Release the buttons now to enter the user setup mode. ... -
Page 5: Service Setup Options
SERVICE SETUP OPTIONS: Default Screen view Description value No. 1 Sets and shows remaining weeks before de-scaling is needed (“DESCALE TANK” message on the screen). Setting it to OFF will disable the function. Range: 1 – 60 weeks No. 2 Sets and shows remaining litres of water before filter change is needed (“CHANGE FILTER”... - Page 6 DISPLAY INFORMATION DESCRIPTIONS: Status Description Machine off. Display backlight off but temperature read- BOILER OFF out still working. Water level below low level probe. Machine is filling FILLING ... automatically. Status LED – 2 red blinks. Water level below low level probe. Machine has to be FILL THE TANK refilled manually (shown only in MANUAL mode).
-
Page 7: Eco Mode Operation
MODES OF OPERATION (Service setup setting 5) : The boiler can operate in 4 different modes: HEAT FILL – Standard operation the boiler will take in water until the temperature in the tank drops, the inlet will close and the heating element is activated. When the temperature reaches the set temperature the inlet will reopen to take in more water. -
Page 8: Troubleshooting
Remove as much scale as possible by hand, paying particular attention to level probes (White plastic with steel tab). Be very careful not to damage any attachments. Use ScaleKleen, Marco part No. 8000270 or similar. Follow instructions carefully. Thoroughly clean and flush the machine before re-use. - Page 9 LIMESCALE: In common with all water boiler manufacturers, service calls resulting from limescale are not covered by warranty. Fitting a scale reducer is recommended, especially in hard water areas. This can reduce the build-up of scale but may not stop it altogether. The frequency that descaling is required depends on the local water supply;...
- Page 10 Intentionally Blank 1900051 REV.1 Page 10 of 12...
- Page 11 Intentionally Blank 1900051 REV.1 Page 11 of 12...
- Page 12 Intentionally Blank 1900051 REV.1 Page 12 of 12...
