Instruction Manual
Marco Beverage Systems Ltd.
INSTRUCTIONS FOR MODELS
(where # is either blank or a suffix of one or more alphanumeric characters)
E337347
Water pressure: 5 - 50 psi (min.-max.)35 - 345 kPa (min.-max.)
Marco Beverage Systems Limited.
63d Heather Road,
Sandyford Industrial Estate,
Dublin 18.
Ireland Tel: +353 (0)1 295 2674
Ireland Fax: +353 (0)1 295 3715
Email: sales@marco.ie
www.marco.ie
Ecoboiler UC4L 2.4kW
(1000740#)
Ecoboiler UC10L 2.8kW
(1000741#)
Ecoboiler UC10L 5.6kW
(1000742#)
Ecosmart UC4L 2.4kW
(1000750#)
Ecosmart UC10L 2.8kW
(1000751#)
Ecosmart UC10L 5.6kW
(1000752#)
NSF/ANSI 4
Marco Beverage Systems Limited.
Shire House, Strixton Manor,
Strixton, Wellingborough, Northants,
NN29 7PA
UK Tel: +44 (0)2072 744 577
UK Fax: +44 (0)2079 788 141
Email: sales@marco-bev.co.uk
www.marco-bev.co.uk
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Marco Ecoboiler UC4L 2.4kW
Summary of Contents for Marco Ecoboiler UC4L 2.4kW
- Page 1 Marco Beverage Systems Ltd. INSTRUCTIONS FOR MODELS Ecoboiler UC4L 2.4kW (1000740#) Ecoboiler UC10L 2.8kW (1000741#) Ecoboiler UC10L 5.6kW (1000742#) Ecosmart UC4L 2.4kW (1000750#) Ecosmart UC10L 2.8kW (1000751#) Ecosmart UC10L 5.6kW (1000752#) (where # is either blank or a suffix of one or more alphanumeric characters)
-
Page 2: Installation Details
SAFETY: This appliance must be earthed. If the moulded plug supplied is not used then ensure that the green/yellow cable is connected to a suitable earth. Risk of flooding. The hose supplied with this unit is non-toxic food quality tested to 190psi. However, a hose is not a permanent connection. - Page 3 The “power on” light will glow green and the machine will fill to a safe level, above the elements, before heating. The “Ready/Status” light will cycle two red flashes while the machine is filling to the safe level. ...
- Page 4 EcoSmart Features (ECOSMART MACHINES ONLY) : The EcoSmart Ecoboiler has many settable features which gives the operator great flexibil ity in choosing how the unit will operate. The following explains how the various features may be changed and their function. There are two Menus in the EcoSmart Boiler One is to set the USER SETUP and One is to set the SERVICE SETUP parameter.
-
Page 5: User Set Up Options
USER SET UP OPTIONS: User Setup Default Screen view Description value Sets new tank temperature. 95.0 NOTE: Temperature should never be set for more than 97°C because it may cause steam to be generated during the low pressure days. Range: 60 – 98.5 °C Range can be limited in Service Settings, see Service Setup below. -
Page 6: Service Setup Options
SERVICE SETUP OPTIONS: Default Screen view Description value No. 1 Sets and shows remaining weeks before de-scaling is needed (“DESCALE TANK” message on the screen). Setting it to OFF will disable the function. Range: 1 – 60 weeks No. 2 Sets and shows remaining litres of water before filter change is needed (“CHANGE FILTER”... - Page 7 No. 7 Sets the mode the machine works in: HEAT HEAT FILL (default – minimises FILL temperature fluctuations), CONT FILL (continuous fill – makes sure the tank is always full but temperature may vary), COOL FILL (allows cooling but reduces tank size by using ECO mode), ...
- Page 8 Machine can not take more cold water to cool the tank DISPENSE WATER because it is full. Water needs to be dispensed to allow TO COOL THE TANK room for more cold water to come in and finish cooling process. Descale timer elapsed.
-
Page 9: Troubleshooting
Note in the Cool Mode will cause the 10L boiler to operate as a 5L boiler and cause the 4L boiler to operate at 2L. MANUAL FILL – if the boiler is not plumbed into a water sup ply the operator must select Manual Fill mode for best operation of the boiler. -
Page 10: Access To Internal Components
Remove as much scale as possible by hand, paying particular attention to level probes (White plastic with steel tab). Be very careful not to damage any attachments. Use ScaleKleen, Marco part No. 8000270 or similar. Follow instructions carefully. Thoroughly clean and flush the machine before re-use. - Page 11 UC4L Disconnect the machine from the electrical supply. Allow to cool sufficiently. On the 10L machine insert a flat headed screwdriver at the four locations indicated on the picture above and rotate. Note: - There is no need to ‘lever’ the screwdriver – a small rotation is all that is required. ...
- Page 12 Font connection with ball valve 2- wire Electrical Connection Font to Boiler Vent may be plumbed to a drain – however there must be an air gap to prevent the Controls possibility of a blocked drain flowing into the boiler. Service Panel UC 10L 1900052...
- Page 13 *Font will vary. Depending on font the type the drip tray will either have to be manually emptied Connected to a drain via drip tray outlet. Font connection with ball valve 2- Wire Electrical Connection Font to Boiler Vent may be plumbed to a drain –...
- Page 14 NSF Approved Font Connection In order to comply with NSF 4 requirements, when installing an NSF listed undercounter boiler with an NSF listed Uber Font, The Vent pipe on the boiler MUST be connected to the Font Vent hose (grey coloured hose). Font connection 2- wire Electrical...
- Page 15 CLEANING: The exterior of these machines may be cleaned with a damp cloth and a light detergent. Do not use abrasive cloths or creams, as this will spoil the finish of the machine. Do not use a water jet or spray. NB: Beware of accidentally operating the draw off tap or push button when cleaning the front of the machine.
