ARRI CONPACT 12000 W Brochure

ARRI COMPACT 12,000 W

Technical Data

Dimensions:

27.9" (L) x 27.2" (W) x 30.2" (H)

Weight:

approx. 108lbs. (49kg)

Lens Diameter:

19.7"

Barndoor Insert Size:

20.9

Filter Insert Size:

20.9"

Lamp Holder:

ARRI G 38 Fast Lock

Lamp:

12 kW Single Ended
New design principles and consistent use of
newest materials technology make it possible
to reduce weight without compromising per-
formance and reliability. The ARRI COMPACT
12,000 W Fresnel satisfies location require-
ments for an easily managed lamphead
without sacrificing ARRI's traditional perfor-
mance and durability.
High light output, a very even field and low
weight are the main advantages of the new ARRI
COMPACT 12,000 W single ended daylight
luminaire. The complete COMPACT series now
comprises eight lampheads from 125 W up
to 12,000 W.
The 500 mm lens gives an enormous punch
of light, delivering over 80,000 lux/6°
halfbeam angle at 10 meters in full spot.
Flood is a full 5,500 lux/50° halfbeam
angle.
A single stirrup lock is easy and safe to oper-
ate and the moveable stirrup points perfectly
balance any accessory combination. The
lamp holder is spring-loaded and an additio-
nal secondary bulb-shaft lock prevents bulb
breakage in operation.
The new COMPACT 12,000 W replaces the
double ended ARRI AD 12 kW Daylight
lamphead. Existing Electronic Ballasts
12/18 kW EB or 6/12 kW EB can be used.
