Page 1: Replacement Parts List
SYNC-RP-Rev. A Replacement Parts List PARTS & SERVICE DEPARTMENT Nashville, Tennessee ® SYNC 615-889-8900 • Fax: 615-547-1000 Condensing Boilers www.Lochinvar.com SB 1000 - 1500... - Page 2 CONTROL PANEL ASSEMBLY 19 20 HEAT EXCHANGER ASSEMBLY 42 43 GAS TRAIN SB 1300, 1500 GAS TRAIN SB 1000 SYNC-RP-Rev. A 2 of 4...
- Page 3 ITEM PART NO. HEX30000 HEAT EXCHANGER HEX30001 HEAT EXCHANGER HEX30002 HEAT EXCHANGER RLY20023 LOW VOLTAGE CONNECTION BOARD RLY20027 INTEGRATED CONTROL RLY20022 INTEGRATED CONTROL RLY30008 INTEGRATED CONTROL HIGH ALTITUDE RLY30007 INTEGRATED CONTROL HIGH ALTITUDE RLY20006 USER INTERFACE CONTROL (LCD) RLY2085 PUMP RELAY BOARD RLY2222 1.5HP PUMP RELAY RLY20020...
- Page 4 ITEM PART NO. WTR20001 FLAP VALVE ASSEMBLY W/ GASKET GKT2034 GASKET, FAN GKT2438 GASKET, FAN WTR3068 HEAT EXCHANGER ACCESS DOOR KIT GKT2063 GASKET DOOR RUBBER MSC3180 SIGHT GLASS GKT2453 GASKET, SIGHT GLASS FIB2167 DIVIDER PLATE, INSULATION BAFFLE FIB2168 BURNER PLATE, INSULATION, DOOR MSC2242 DISPLAY BEZEL RLV2003...
