Lochinvar SB-1300 Specification Sheet

WATER
GALLON CAPACITY
HEATING SURFACE (SQ. FT.)
INLET WATER CONNECTION
OUTLET WATER CONNECTION
DRAIN
20°F ΔT WATER FLOW (GPM) *
HEAD LOSS (FT. OF HD.) *
35°F ΔT WATER FLOW (GPM) *
HEAD LOSS (FT. OF HD.) *
MAX. WORKING PRESSURE (PSI)
# OF RELIEF VALVES
RELIEF VALVE SIZE
RELIEF VALVE RATING (MBH)
RELIEF VALVE PRESSURE RATING (PSI)
GAS
INLET CONNECTION
MAX. INLET PRESSURE, NAT
MIN. INLET PRESSURE, NAT
MAX. INLET PRESSURE, LP
MIN. INLET PRESSURE, LP
BTU/HR INPUT
BTU/HR OUTPUT (HIGH FIRE)
BTU/HR OUTPUT (LOW FIRE)
ELECTRICAL
VOLTAGE/HEATER
VOLTAGE/CONTROL
TOTAL AMPS
# OF ELECTRICAL CONNECTIONS
DIMENSIONS
HEIGHT
WIDTH
DEPTH
SERVICE CLEARANCES
FRONT
BACK (PIPING)
RIGHT SIDE
LEFT SIDE
TOP
DIRECT VENTING
SIZE
VENT CATEGORY
VENT MATERIAL
* The flow rate and head loss values listed here are for each of the boiler's heating modules.
Lochinvar Corporation • 300 Maddox Simpson Pkwy • Lebanon, TN 37090 • 615-889-8900 / Fax: 615-547-1000
SYNC-PS-01
SYNC BOILER PRODUCT SUMMARY
(SB) 1,000,000-1,500,000 BTU/HR
SB-1000
8.4
101.6
2" x 2"
2-1/2"
3/4"
55
31
32
13
160
1
1"
1,954
50
1-1/2"
14" w.c.
5" w.c.
14" w.c.
8" w.c.
1,000,000
940,000
94,000
120
24
5.5
1
58-3/4"
31"
48"
31"
24"
0
0
13"
6"
IV
PVC/CPVC/SS PVC/CPVC/SS
www.Lochinvar.com
SB-1300 SB-1500
10.0 11.4
115.6 130.6
2" x 2" 2" x 2"
2-1/2" 2-1/2"
3/4" 3/4"
65 74
30 33
37 42
11 12
160 160
1 1
1" 1"
1,954 1,954
50 50
1-1/2" 1-1/2"
14" w.c. 14" w.c.
4" w.c. 4" w.c.
14" w.c. 14" w.c.
8" w.c. 8" w.c.
1,300,000 1,500,000
1,222,000 1,410,000
122,200 141,000
120 120
24 24
5.5 5.5
1 1
58-3/4" 58-3/4"
31" 31"
52-1/4" 55-1/2"
31" 31"
24" 24"
0 0
0 0
13" 13"
6" / 7" 6" / 7"
IV IV
PVC/CPVC/SS
