Lochinvar EBS-SUB-02 Submittal Sheet

JOB NAME ______________________________________________________________________
LOCATION ______________________________________________________________________
ARCH./ENGR.____________________________________________________________________
WHOLESALER __________________________________________________________________
MECH. CONTRACTOR ___________________________________________________________
MODEL NO. _____________________________________________________________________
GALLON CAPACITY_____________________________________________________________
VOLTAGE PHASE________________________________________________________________
KW _____________________________________________________________________________
NOTES

Standard Features

• ASME National Board Registered Pressure Vessel
• Heavy Duty Steel Boiler Vessel Housing
• 3" Fiberglass Insulation
• ASME Pressure Relief Valve
• Pressure Gauge with Gauge Cock
• Feedwater Stop & Check Valves
• Full-Port Bottom Blowdown Valve
• Combination Float-Type Level Control /
Low Water Cut-Off with Blowdown Valve
• Water Level Sight Gauge with Blowdown Valve
• Surface Blowoff Provision
• Low Water Cut-Off with Manual Reset & Pilot Light
• Adjustable High Limit with Automatic Reset
• Adjustable High Limit with Manual Reset
• Incoloy-Sheathed Elements
• Internal Branch Circuit Fusing
• Magnetic Contactors
• Main Supply Circuit Lugs
• 120 Volt Fused Control Transformer
• On/Off Switch with Pilot Light
• Preheat Switch with Pilot Light (above 240 kW)
• Key Locked Door
• Electric Control Panel
• Staged On/Off Pressure Switches (1, 2 & 3 Step Models)
• Proportional Solid State Step Control
(models with more than 3 Steps)
• Status Pilot Light for each Stage/Step
• Listed by the Underwriters Laboratories
• 3 Year Limited Tank Warranty / 1 Year Parts Warranty
(See warranty for details)
COMMERCIAL ELECTRIC STEAM BOILERS
COMMERCIAL ELECTRIC
STEAM BOILER
Submittal Sheet
EBS-Sub-02

Optional Features

Place an X in the box by all options that apply
Alarm Bell
Automatic Breaker
Automatic Feed Water Solenoid Valve
Fused Disconnect
Ground Fault Detector
Kilowatt/Hour Meter
Main Power Disconnect
Manual Limit Toggle Switches (1 per Step)
Automatic Timed Surface Blowoff System

OPTIONAL CONTROLS

Modulating Step Control (Progressive)
5-Step
10-Step
15-Step
20-Step
