BOSTITCH
®
MARK III
PNEUMATIC TOOLS
HERRAMIENTAS NEUMÁTICAS
CLOUEURS PNEUMATIQUES
OPERATION and MAINTENANCE MANUAL
MANUEL D'INSTRUCTIONS ET D'ENTRETIEN
MANUAL DE OPERACIÓN Y DE MANTENIMIENTO
BEFORE OPERATING THIS TOOL, ALL OPERATORS SHOULD STUDY THIS MANUAL TO
UNDERSTAND AND FOLLOW THE SAFETY WARNINGS AND INSTRUCTIONS. KEEP THESE
INSTRUCTIONS WITH THE TOOL FOR FUTURE REFERENCE. IF YOU HAVE ANY QUESTIONS,
CONTACT YOUR STANLEY-BOSTITCH REPRESENTATIVE OR DISTRIBUTOR.
ANTES DE OPERAR ESTA HERRAMIENTA, TODOS LOS OPERADORES DEBERÁN ESTUDIAR
ESTE MANUAL PARA PODER COMPRENDER Y SEGUIR LAS ADVERTENCIAS SOBRE SEGURI-
DAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA HERRAMIENTA
PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON SU REPRESEN-
TANTE DE STANLEY-BOSTITCH O CON SU DISTRIBUIDOR.
LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D'UTILISER L'APPAREIL. PRÉTER UNE
ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX AVERTISSE-
MENTS. GARDER CE MANUEL AVEC L'OUTIL POUR FUTUR RÉFÉRENCE. SI VOUS AVEZ DES
QUESTIONS, CONTACTEZ VOTRE REPRÉSENTANT OU VOTRE CONCESSION NAIRE
STANLEY-BOSTITCH.
BOSTITCH
®
103701REVD 5/99
Stanley Fastening Systems
Advertisement
Table of Contents
Related Manuals for Bostitch MARK III
Summary of Contents for Bostitch MARK III
- Page 1 DAD Y LAS INSTRUCCIONES. MANTENGA ESTAS INSTRUCCIONES CON LA HERRAMIENTA PARA FUTURA REFERENCIA, SI TIENE ALGUNA DUDA, COMUNÍQUESE CON SU REPRESEN- TANTE DE STANLEY-BOSTITCH O CON SU DISTRIBUIDOR. LIRE ATTENTIVEMENT LE PRÉSENT MANUEL AVANT D’UTILISER L’APPAREIL. PRÉTER UNE ATTENTION TOUTE PARTICULIÈRE AUX CONSIGNES DE SÉCURITÉ ET AUX AVERTISSE- MENTS.
-
Page 2: Table Of Contents
FASTENERS LIMITED WARRANTY Stanley-Bostitch, Inc., warrants to the original retail purchaser that this product is free from defects in material and workmanship, and agrees to repair or replace, at Stanley-Bostitch's option, any defective product within 1 year from the date of purchase. This warranty is not transferable. It only... -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS EYE PROTECTION which conforms to ANSI specifications and provides protection against flying particles both from the FRONT and SIDE should ALWAYS be worn by the operator and others in the work area when loading, operating or servicing this tool. Eye protection is required to guard against flying fasteners and debris, which could cause severe eye injury. - Page 4 50 fasteners per minute, you need 50% of the tool’s c.f.m. of free air which is required to operate the tool at 100 fasteners per minute. OPERATION STANLEY-BOSTITCH OFFERS TWO TYPES OF OPERATION FOR THIS SERIES TOOL. CONTACT TRIP The common operating procedure on “Contact Trip” tools is for the operator to contact the work to actuate the trip mechanism while keeping the trigger pulled, thus driving a fastener each time the work is contacted.
-
Page 5: Air Supply And Connections
Frequent, but not excessive, lubrication is required for best performance. Oil added through the air line connection will lubricate the internal parts. Use STANLEY-BOSTITCH Air Tool Lubricant, Mobil Velocite #10, or equivalent. Do not use detergent oil or additives as these lubricants will cause accel- erated wear to the seals and bumpers in the tool, resulting in poor tool performance and frequent tool maintenance. - Page 6 Push cover forward until cover latch pin snaps into place. The tool is now ready to operate. Load corrugat- ed fasteners with points down. Points are colored for identification - load colored side down. NOTE: Use only fasteners recommended for use in Bostitch MIII series models.
-
Page 7: Tool Operation
THIS MANUAL. II. REFER TO “TOOL SPECIFICATIONS” IN THIS MANUAL TO IDENTIFY THE OPERATING SYSTEM ON YOUR TOOL. There are three available systems on STANLEY-BOSTITCH pneumatic tools. They are: 1. TRIGGER OPERATION 2. CONTACT TRIP OPERATION 3. SEQUENTIAL TRIP OPERATION OPERATION 1. - Page 8 IN ADDITION TO THE OTHER WARNINGS CONTAINED IN THIS MANU- AL OBSERVE THE FOLLOWING FOR SAFE OPERATION • Use the STANLEY-BOSTITCH pneumatic tool only for the purpose for which it was designed. • Never use this tool in a manner that could cause a fastener to be directed toward the user or others in the work area.
-
Page 9: Maintaining The Pneumatic Tool
Care must also be taken to insure no permanent kinks are put in the spring as this will reduce the springs force. REPLACEMENT PARTS: STANLEY-BOSTITCH replacement parts are recommended. Do not use modified parts or parts which will not give equivalent performance to the original equipment. ASSEMBLY PROCEDURE FOR SEALS: When repairing a tool, make sure the internal parts are clean and lubricated. -
Page 10: Lubrication
COIL NAILERS Skipping fasteners; intermittent feed Feed piston dry ....Add STANLEY-BOSTITCH Air Tool Lubricant in hole in feed piston cover Feed piston O-rings cracked/worn ..Replace O-rings/check bumper and spring. -
Page 11: Maintaining The Miii Series Tools
MAINTAINING THE MIII SERIES TOOLS TO REPLACE PISTON: a. Insert the flats on the lower end of the driver piston stem carefully into the end of piston and plunger wrench, BC1009. b. Using another special wrench, BC1009, or another wrench of the proper size, unscrew the plunger from the upper end of the stem. -
Page 12: Accessories
ACCESSORIES AVAILABLE BC675A Stationary Filter-Regulator Lubricator Assembly BC744A Filter-Lube Carrier BC1320 Kit to convert MIII719-989, MIII886BCF and MIII1394-1370 to a contact trip. BC1467 Kit to convert MIII tools to remote control cycle BC855 Wrench - Poppet BC1009 Wrench - Poppet Piston -12-...
