Medeli SP201 Owner's Manual

SLIM PIANO
SP201
SP201 PLUS
OWNER'S MANUAL
THE FCC REGULATION WARNING (for the USA)
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pur-
suant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can radiate radio frequency ener-
gy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of
the following measures:
‹
Reorient or relocate the receiving antenna.
‹
Increase the separation between the equipment and receiver.
‹
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
‹
Consult the dealer or an experienced radio/TV technician for help.
If items such as cables are included with this equipment, you must use those included items.
Unauthorized changes or modification to this system can void the user's authority to operate this equipment.
CAUTION
The normal function of the product may be disturbed by Strong Electro Magnetic Interference.
If so, simply reset the product to resume normal operation by following the owner's manual. In
case the function could not resume, please use the product in other location.
Keep this manual
After reading this manual, please keep it for later reference.
Turning the Power On or Off
1. Make sure the instrument is properly con-
nected to the power supply.
2. Press the [POWER] switch. The panel
LED's light up. The power is turned on.
3. Rotate the [VOLUME] knob to set the
volume to a desired level.
4. When you are ready to turn off the power,
press the [POWER] switch for a second. The
panel LED's will turn off.
Note:
In order to save energy, the instrument will
automatically shut down after 30 minutes of
not being used. You can turn off the power
protection by using a keyboard command,
holding SHIFT and press C1, C#1 at the same
time. Please unplug the instrument when it is
not in use or during a thunderstorm.
Specifications
Connectivity
2 Headphones,
Keyboard
Sustain Pedal, Unit Pedal,
88 Weighted,
MIDI Out, USB MIDI,
graded hammer action
Aux In, Line Out
Touch Response
Power
5 types, Off
DC 12V / 2A
Amplifier
Polyphony
192 notes (max)
20W x 2
Sound
Speaker
30
(16 x 7) cm Oval x 2,
3 cm x 2
Layer
Left, Right 1, Right 2
Dimension (LWH)
136.5. x 36.6 x 13.4 cm
Split
Yes
Weight
12.5 kg
Twinova
Yes
Metronome / Rhythm
50
Metronome / Rhythm Control
Start / Stop
Metronome / Rhythm volume
Tempo
20 - 280
Effect
D.A.S.
Reverb (2 types)
Chorus (1 type)
Song
100
Sequencer
1 User song
(1 melody track)
SP201-SP201Plus_OM02EN
Connecting the APP "Piano
Toolbox" via Bluetooth MIDI
SP201 PLUS only
1. Turn on the instrument. Make sure the
instrument and the smart device are in range
of each other.
2. On the smart device, open "Settings", then
turn on Bluetooth.
3. Open Bluetooth MIDI function within the
app and select the device name "Piano BT
MIDI xxxx" to establish Bluetooth connection.
When the connection is established, the LED
light of power button will turn to blue.
Now, you can control the instrument from the
app remotely.
Note:
You can use a keyboard command to disconnect Bluetooth
MIDI, holding SHIFT and press A#0 and B0 at the same time.
Bluetooth MIDI only applies to the Bluetooth-equipped
instruments.
But you can also connect the app through camera connec-
tion kit on iOS and through USB on Android devices.
Sound List
1 German Grand
2 Bright German Grand
3 Japanese Grand
4 Warm Grand
5 Electric Grand
6 Honky Tonk
7 Vintage EP
8 Warm EP
9 Reed EP
10 Dark EP
11 FM EP
12 Crystal EP
13 Clavinet
14 Harpsichord
15 Tonewheel Organ
16 Classic Organ
17 Church Organ
18 Accordion
19 Synth Pad
20 Strings
21 Choir
22 Square Lead
23 Saw Lead
24 FM Pad
25 Bell
26 Celesta
27 Nylon Guitar
28 Electric Bass
29 Acoustic Bass
30 Synth Bass
Metronome /
Rhythm List
1 Simple Count
2 4/4 Beat
3 2/4 Beat
4 3/4 Beat
5 3/8 Beat
6 6/8 Beat
7 5/4 Beat
8 5/8 Beat
9 7/8 Beat
10 10/8 Beat
11 8Beat 1
12 8Beat 2
13 16Beat 1
14 16Beat 2
PRECAUTIONS
Location
Using the unit in the following locations can result in a malfunction.
‹
In direct sunlight
‹
Locations of extreme temperature or humidity
‹
Excessively dusty or dirty locations
‹
Locations of excessive vibration
‹ Close to magnetic fields
Power Supply
Please connect the designated AC adapter to an AC outlet of the correct voltage.
Do not connect it to an AC outlet of voltage other than that for which your unit is intended.
Interference with other electrical devices
Radios and televisions placed nearby may experience reception interference.
Operate this unit at a suitable distance from radios and televisions.
Care
If the exterior becomes dirty, wipe it with a clean, dry cloth. Do not use liquid cleaners
such as benzene or thinner, or cleaning compounds or flammable polishes.
Handling
To avoid breakage, do not apply excessive force to the switches or controls.
Keeping foreign matter out of your equipment
Never set any container with liquid in it near this equipment. If liquid gets into the equipment,
it could cause a breakdown, fire, or electrical shock.
Be careful not to let metal objects get into the equipment.
1. PHONE Jacks 3. MIDI OUT Jack
For connecting to head- For connecting to an exter-
phones. When headphones nal MIDI device.
are connected, the internal
speakers will be muted. The 4. SUSTAIN Jack
sound can only be heard For connecting to a sustain
from the headphones. pedal.
2. USB Jack
5. LINE OUT Jack
For connecting to a com-
For connecting to the INPUT
puter or a mobile device via
jack of external audio equip-
cable. An additional adapter
ment such as a stereo sound
may be needed to connect
system.
to mobile devices.
15 Rock 10 Italian Polka
16 Ska 11 The Rag-Time Dance
17 Slow Rock 12 Piano Sonata
18 70's Rock
In C Major, K.330. III
19 Texas Rock 13 Piano Sonata
20 Sweet Ballad In A Major, K.331. I
21 6/8 Soul 14 Waltz For Piano
22 Fusion Shuffle
In G-Sharp Minor
15 L' Arabesque
23 Adult Ballad
24 Organic Ballad 16 Austria Variation
17 Schos Doll's Dance
25 Tango
26 Slow Waltz No. 7
27 Cha Cha 18 To A Wild Rose
28 Rumba 19 Innocence
29 Samba 20 Tchaikovsky Waltz
30 Techno 1 21 Barcarolle
31 Hip Hop 22 Robot Doll
32 Techno 2 23 Consolation
33 Classic Disco 24 Invention A 2 Voix
34 Funk 1 25 Minuet In G Major
35 Funk 2 (BWV Anh. 114)
36 Swing 1 26 Barcarolle
37 Swing 2 27 Norwegian Dance No.2
38 Funky Jazz 28 Moseta Dance
39 Bernard Shuffle
29 The Small Gathering
40 Bluegrass 30 The Return
41 Country Step 31 The Wagtail
42 Country Folk 32 Bulie Dance
43 Bossa Nova 33 Tender Blossom
44 Latin 34 Grace
45 Mambo 35 Cherish The Memories
46 Waltz 36 Chopsticks
47 Vienna Waltz 37 Progress
48 Polka 38 Eclogue
49 March 39 The Limpid Stream
50 6/8 March 40 Brave Cavalier
41 The Chatterbox
42 Tarantella
43 Frankness
Song List
44 Tender Grieving
45 The Farewell
1 Prelude In
46 The Chase
C-Sharp Major
47 Sonata K.545
2 Lyrical Rondo
48 Maple Leaves Ragtime
3 Rialto Ripples (Rag)
49 The Nightingale
4 Neapolitan Song
Was Singing
5 Waltzes
50 Gipsy Rondo
6 Turkish March
7 Schos Doll's
Dance No. 2
8 Minuet In D Major
9 Inquietude
6. AUX IN Jack
For connecting to the OUT-
PUT jack of external audio
source such as an MP3
12V
player.
7. DC IN Jack
For connecting the specifed
power adapter.
8. Unit Pedal Jack
(Optional)
For connecting an option-
al unit pedal (Soft Pedal,
Sostenuto Pedal and Sustain
Pedal) to the pedal jack
located on the bottom of the
instrument.
51 Fountain
52 Fur Elise
53 Dove
54 Knight
55 Ave Maria
56 Prelude in G BWV902a
57 The Angels Singing
58 The Entertainer
59 Swallow
60 Minute Waltz
61 Danse Des Mirlitons
62 Wedding March
63 The Hip Hop's Night
64 Prelude And Fugue
No. 30 In D Minor
65 Minuets In F
66 Red River Valley
67 Troika
68 Oh Susanna
69 Wave Of Danube
70 Long Long Ago
71 Old Folks At Home
72 Jambalaya
73 Ding! Dong!
74 Battle Hymn
75 The Old Gray Mare
76 American Patrol
77 Christmas Coming
78 Sipping Cider
79 Christmas Sound
80 On London Bridge
81 House Of Rising
82 The Blue Bells
83 Beautiful Dreamer
84 Been A Long Time
85 O Sole Mio
86 Der Deitcher's Dog
87 Joy To The World
88 Silent Night
89 Ave Maria
90 Five Hundred Miles
91 Happy New Year
92 Like Christmas
93 Jeanie With
The Light Brown Hair
94 Music Box Dancer
95 Tell It On Mountain
96 Entertainer
97 Annie Laurie
98 Rumba Romance
99 The Last Rose
Of Summer
100 The Old King Cole
