Summary of Contents for Kessler CINEDRIVE
- Page 1 Q U I C K S TA R T...
- Page 2 Each MCB has a single plug for connecting drive cables to motors. G) Battery Power the system with a 12V battery such as the Kessler Ion Battery or the included wall plug. H) Motor Mount Allows mounting of the slider motor to a Kessler slider.
- Page 3 *Keep kOS user interface closed until all connections have been made and Brain is powered up. Visit the Apple App Store and download the latest version of the kOS user interface https://itunes.apple.com/us/app/kessler-kos/id603755857 Mac OS & Windows Download desired kOS user interface to your computer or device from http://support.kesslercrane.com...
- Page 4 C I N E D R I V E ® Q U I C K S TA R T Pan/Tilt Head and Turntable Connections Step 1 For a pan/tilt head, connect the pan and tilt bricks together using an 8” Control cable.
-
Page 5: Camera Connections
C I N E D R I V E ® Q U I C K S TA R T Step 2 Connect any F.I.Z. MCB’s to the tilt brick control ports using 8” Control cable(s). Camera Connections All MCB’s and pan/tilt bricks have ports designed to connect a trigger cable to a camera. - Page 6 LED color. If connected via Ethernet, the Brain will briefly show green LEDs before pulsing blue. Step 5 For wireless devices - set your device’s Wi-Fi connection to be “CineDrive” (skip this step for wired applications).
- Page 7 C I N E D R I V E ® Q U I C K S TA R T Note- Both Windows and Mac require you to wait 60 seconds after the network connection is made before kOS can connect to the Brain. You can monitor this on Windows by hovering the mouse over the network icon in the task tray.
- Page 8 W W W . K E S S L E R C R A N E . C O M...
