- Page 1 MIU620L-IG001 MiFi 4G LTE Global USB Modem U620L Linux Integration Guide Version 1.0 July10, 2015...
- Page 2 NOVATEL WIRELESS COPYRIGHT STATEMENT ©2015 Novatel Wireless, Inc. All rights reserved. The information contained in this document is subject to change without notice and should not be construed as a commitment by Novatel Wireless, Inc. NOVATEL WIRELESS TRADEMARKS AND SERVICE MARKS Novatel Wireless is a trademark of Novatel Wireless, Inc., and the other trademarks, logos, and service marks (collectively the “Trademarks”) used in this user manual are the property of Novatel Wireless or their respective owners.
- Page 3 General Disclaimer TERMS OF USE OF NEW MATERIALS - PLEASE READ CAREFULLY From time to time, Novatel Wireless, in its sole discretion, may make available for download on its website (www.novatelwireless.com), or may transmit via mail or email, updates or upgrades to, or new releases of, the firmware, software, or documentation for its products (collectively, 'New Materials').
-
Page 4: Table Of Contents
Contents Introduction Overview Prerequisites Known Issues End User Mode Enumerating CDC-ECM Interface Enterprise Mode Enumerating CDC-ECM + Modem Interfaces... -
Page 5: Introduction
Introduction Overview Prerequisites Known Issues... -
Page 6: Overview
Microsoft RNDIS 6.0. Although this integration may not be supported in the Linux environment, the MiFi U620L does support Linux configurations. This guide outlines the basic information needed to successfully integrate the MiFi U620L into a Linux platform. The two main sections in the guide are:... -
Page 7: Prerequisites
An Internet connection is required for this installation. To install the utility: Enter the following command: # sudo apt-get install usb_modeswitch Linux Kernel source files—Files required to enable the MiFi U620L to enumerate the Modem https://www.kernel.org/ interface. Download the files from this site: U620L Linux Integration Guide... -
Page 8: Known Issues
Known Issues The usb_modeswitch utility has crashed on some Linux distributions presenting the following error message. Despite receiving this message, the Ethernet Interface gets enumerated correctly and the laptop gets an IP address from the device. This is a tool-related issue and you can safely ignore this error. U620L Linux Integration Guide... -
Page 9: End User Mode
End User Mode Enumerating CDC-ECM Interface... -
Page 10: Enumerating Cdc-Ecm Interface
Enumerating CDC-ECM Interface By default, the MiFi U620L device is in End-User Mode. This means that only the RNDIS configuration is exposed. For the device to get a WWAN IP Address assignment, you must switch the configuration to CDC-ECM. To switch the configuration and initiate the DHCP request:... -
Page 11: Enterprise Mode
Enterprise Mode Enumerating CDC-ECM + Modem Interfaces... -
Page 12: Enumerating Cdc-Ecm + Modem Interfaces
Enumerating CDC-ECM + Modem Interfaces To add support for the MiFi U620L, you must modify the kernel source on your Linux server by adding the Vendor ID (VID) and Product ID (PID) of the MiFi U620L. NOTE: The following instructions assume that your kernel version is 3.16.0-x-generic (To verify the kernel version, run the command uname –r.) - Page 13 e. Save the original Makefile and create a new Makefile that contains the only rule for option.o: obj-m += option.o Change the directory: # cd /lib/modules/3.16.0-x-generic/build g. Build the driver by issuing the following command: # sudo make -C /lib/modules/3.16.0-x-generic/build/ M=/usr/src/linux-headers-3.16.0-x-generic/drivers/usb/serial/ Add or replace option.ko in system modules directory: a.
- Page 14 If the option.ko driver is not loaded, follow these steps to load the driver: a. Load the USB serial driver module with the VID and PID parameters corresponding to the MiFi U620L by issuing the following command: # sudo modprobe usbserial vendor=0x1410 product=0x9022 b.
