INSTALLATION INSTRUCTIONS

HB0113
!
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE INFORMATION ON PAGES 9
BEST; Hartford, Wisconsin www.BestRangeHoods.com 800-558-1711
BEST; Drummondville, QC, Canada www.BestRangeHoods.com 866-737-7770
To register your product online or for additional information
WPD38I SERIES
S
UITALE FOR USE IN DAMP LOCATIONS WHEN INSTALLED IN A
GFCI PROTECTED BRANCH-CIRCUIT.
I
NTENDED FOR OUTDOOR COVERED PATIO OR LANAI AREA
INTENDED FOR DOMESTIC COOKING ONLY
READ AND SAVE THESE INSTRUCTIONS
visit www.BestRangeHoods.com
.
!
10.
AND
SV20569 rev. 03
