Page 1: Operation Manual
SPLIT TYPE ROOM AIR CONDITION OPERATION MANUAL AS26NC1HRA AS35NC1HRA AS53HE1HRA AS71NE1HRE Please read this operation manual before using the air conditioner. Keep this operation manual for future reference. 0010582061... -
Page 3: Table Of Contents
Contents PARTS AND FUNCTIONS OPERATION MAINTENANCE CAUTIONS TROUBLE SHOOTING... -
Page 4: Parts And Functions
Parts and Functions Indoor Unit Outdoor Unit Air Purifying Filter (inside) Inlet Emergency Inlet grille Switch Outlet Anion generator Horizontal flap CONNECTING PIPING OUTLET (inside) (adjust up and down air flow AND ELECTRICAL WIRING Don't adjust it manually) Vertical blade INLET DRAIN HOSE (adjust left and... -
Page 5: Operation
Operation Inner side of the controller Load the batteries as illustrated. 2 R-03 batteries, resetting key (cylinder); Be sure that the loading is the panel display “01”, the in line with the “+”/“-”; operating power is 100W; SMART when the panel display SET TEMP. -
Page 6: Quiet Operation
For each press, SOFT is displayed Air conditioner starts Haier Peaksmart enabled air-conditioners have a Demand Response Mode display POWER function operation. In SOFT operation mode, fan on the indoor unit. The display could be labelled d1, d2, d3 (wording may differ model to model). - Page 7 Operation Press TEMP button. Every time the button is pressed, temp. setting increases 1 ºC. Every time the button is For each press of “ ” button, air pressed, temp. setting decreases 1 ºC. displays as follows according to different operation modes: QUIET QUIET COOL/DRY:...
-
Page 8: Health Operation
Operation HEALTH Operation HEALTH AIRFLOW Operation The setting of The water-ion generator in the airconditioner can generate a lot function of anion effectively balance the quantity of position and anion in the air and also to kill bacteria appears on the display. Avoid and speed up the dust sediment the body. -
Page 9: Timer Operation
Operation POWER Operation TIMER Operation Set Clock correctly before starting Timer operation. You can let unit start or stop automatically a following times: Before you wake up in the morning, or get back from outside or after you fall asleep at night. Select your desired operation POWER Operation mode. - Page 10 Operation Comfortable SLEEP 3 hours then stop. Temp is lower than temp setting so that room temperature won’t be too high for your Before going to bed, you can simply press the SLEEP sleep. button and unit will operate in SLEEP mode and bring you a sound sleep.
-
Page 11: Smart Operation
Operation SMART Operation ECO Operation Automatic adjusting with the environmental temperature, (This function is unavailable on running with power saving. some models) SMART One key can give you a comfortable room! The air conditioning unit can AUTO judge the indoor temperature and Press ECONOMY button “... -
Page 12: Test Operation
Operation FRESH Operation Emergency operation and test operation Exhaust the stale air from the room, and inhale fresh air . Emergency Operation: (This function is unavailable on some models.) Use this operation only when the remote controller is defective or lost, and with function of emergency running, air conditoner can run automatically for a while. -
Page 13: Maintenance
Maintenance For Smart Use of The Air Conditioner Remote Controller Indoor Body Setting of proper room Do not block the air inlet temperature or outlet Proper wipe the air conditioner by using a temperature soft and dry cloth.For serious stains, use a neutral detergent diluted with Do not usewater,wipe the controller water.Wring the water out of the... -
Page 14: Cautions
Cautions WARNING Please call Sales/Service Shop for the Installation. Do not attempt to install the air conditioner by yourself because improper works may cause electric shock, fire, water leakage. WARNING Check proper When abnormality such as burnt-small found, Use an exclusive immediately stop the operation button and power source installation of the... -
Page 15: Trouble Shooting
