  • Page 1 Manual SW28 Subwoofer...

  • Page 2: Table Of Contents

    • Operating Modes [1] SW28........
  • Page 3 flying rails and the tripod flange. Replace them if necessary. Make sure that during operation on spacer tubes, no persons will stand close to the loudspeakers. Use only accessory parts specified by ProAudio Technology or original accessory parts from ProAudio Technology. Loudspeakers always produce a magnetic field. Make sure...

  • Page 4: Operation On System Amplifiers

    Description: The SW28 is a compact 2 x 18“ bassreflex subwoofer for sound systems with an active frequency crossover. Note: It can be used for all kinds of sound reinforcement, from stand- Use the SW28 subwoofer only alone applications to massive cardioid subwoofer arrays. Large, on system amplifiers with the...

  • Page 5: Operating Modes

    Two amplifier channels will be assigned. Front Front DELTA 8.4-DSP / 14.4-DSP – 4 x 1-pc Sub Array [SW28 – 4 CH] Two SW28 subwoofers on either side are wired using 4-pole speaker cables. Each subwoofer is driven by one dedicated amplifier channel.
  • Page 6 Front 14.4-DSP – 1 x 3-pc Cardioid Sub Array [SW28-CSA] All three SW28 subwoofers are wired using 4-pole speaker cables. The two front-firing subwoofers and the single back-firing subwoofer are each driven by one dedicated amplifier channel. Two amplifier channels will be assigned.

  • Page 7: Mixed Operation Sw28 And Sw18

    SW18 subwoofer. Both subwoofers may be combined in any desired configurations and setup variants. Likewise cardioid sub arrays (CSA) are possible in a mix mode with SW28 / SW18. The minimum impedance is 2 ohms on the DELTA14.4-DSP system amplifier and 4 ohms on the DELTA8.4-DSP system amplifier.

  • Page 8: Mixed Operation Sw28 And Sw18 Csa

    Rear Front DELTA14.4-DSP SW28-CSA All five subwoofers are wired using 4-pole speaker cables. The four front-firing SW18 subwoofers and the single back-firing SW28 subwoofer are each driven by one dedicated amplifier channel. Two amplifier channels will be assigned. Front Rear With ground coupling DELTA14.4-DSP SW28-CSA...
  • Page 9 Without ground coupling DELTA14.4-DSP SW28-CSA All four subwoofers are wired using 4-pole speaker cables. The front-firing SW18 and SW28 subwoofers and the single back-firing SW28 subwoofer are each driven by one dedicated amplifier channel. Two amplifier channels will be assigned.

  • Page 10: Drawings / Dimensions

    1165 DELTA 14.4-DSP – 2 x 3 Cardioid sub array [SW28-CSA] All six SW28 subwoofers are connected via a 4-pole loudspeaker cable. The four front-firing subwoofers and the two back-firing sub are each driven by one amplifier channel. Two amplifier channels are assigned.

  • Page 11: Technical Specifications

    The relevant regulations must be observed and adhered to. EU Conformity Declaration: This declaration is valid for the SW28 loudspeaker of the manufacturing company ProAudio Technology GmbH. Included herein are all production items of the same type, as long as they have not been modified subsequently in structural or...
  • Page 12 Manual SW28 Subwoofer – 2012-11 ENG ProAudio Technology GmbH Hermann-Schwer-Strasse 3 78048 Villingen-Schwenningen Germany Phone: +49 (0) 77 21 / 99 81 96 - 0 Fax: +49 (0) 77 21 / 99 81 96 - 9 info@proaudio-technology.de www.proaudio-technology.de...
