  • Page 1 ELS User Manual...

  • Page 2: Table Of Contents

    Metra ELS User Manual Table of contents Metra ELS User Manual ........................... 4 Product description ..........................4 Basic parts ............................5 Display............................. 5 Coin acceptor (optional) ......................... 5 Fingerprint module (optional) ......................6 Euro deposit pad (optional) ......................6 Display as User interface ........................6 Display Combo ..........................
  • Page 3 Metra ELS User Manual Exceeded tenancy time ......................... 22 Expired tenancy time ........................22 Use as an information terminal ......................23 Use of Payment key .......................... 23 Use of Emergency open key ......................24 Master mode of operation ........................ 24 Entering the Master mode by typing-in the Master code ............

  • Page 4: Metra Els User Manual

    Metra inženiring d.o.o. can assume no responsibility for any errors in this manual.  Product description Metra Electronic Locking System (ELS) is primarily designed and used for locking lockers. Each ELS system has two basic components: Metra Locker Controller and Metra Display. Locker Controller drives and monitors up to 16 locks connected directly to the unit, with the possibility to add up to two Extension Modules for 8 additional Electronic Locks each.

  • Page 5: Basic Parts

    Locker Controller and manage master keys and master/setup codes also Metra software can be used.  Coin acceptor (optional) Locker Controller ELS can be configured to ask for payment when locking the locker door. In that case Coin Acceptor is mounted near the Display. Page 5...

  • Page 6: Fingerprint Module (Optional)

    It offers higher comfort for users as they don't need to remember PIN code or carry around the RFID media. When fingerprint module is connected to ELS Locker Controller each user can freely choose whether he/she will lock the locker using fingerprint/PIN code/RFID media.

  • Page 7: Display Rfid

    Metra ELS User Manual  Display RFID description 4 digit LED display antenna field 4 key system keypad  Display Keypad description 4 digit LED display 12 key keypad Page 7...

  • Page 8: Power - On

    Metra ELS User Manual  Power - on After the device is powered on, its network address is shown on display for a few seconds. This feature is intended for maintenance personnel. NOTE: If payment is turned ON, current Saldo is displayed after the network address.

  • Page 9: Display Keypad

    Metra ELS User Manual  Display Keypad When the device is running, blinking. a blue dot on the left side of display is  Indication of unoccupied locker Indication of unoccupied locker is slightly opened locker door. The Metra Electronic Lock has built-in door ejector.

  • Page 10: Locking Procedures

    Metra ELS User Manual By presenting RFID media or fingerprint again, or typing-in the PIN code the locker unlocks and is free for another user.  Locking procedures  Normal locking procedure with RFID media STEP 1: Close the locker door. Time countdown starts (vertical lines are displayed) on the Display and interrupted beep acoustic signal is activated.

  • Page 11: Normal Locking Procedure With Pin Code

    Metra ELS User Manual  NOTE  If procedure is rejected for any reason (RFID media not on the White List, etc.) the Display shows “no” accompanied long acoustic signal. Locker automatically opens. MULTI LOCKING: If procedure is rejected and “FULL” is displayed accompanied by interrupted acoustic signal, you have reached locker limit for your RFID media.

  • Page 12: Normal Locking Procedure With Fingerprint

    Metra ELS User Manual  NOTE  For PIN codes which are 3 or 4 digits long the following rules apply:  PIN codes with all the same digits (000, 0000, 111, 1111, 222 … 999, 9999) are rejected.  PIN codes are rejected if digits are 123 and 1234.

  • Page 13: Multiple Locking Procedure With Pin Code Or Fingerprint

    Multiple locking should be enabled in order to use that possibility! For more information on multiple locking parameters consult Locker Controller ELS & ELS SELECT Technical Manual. All the lockers closed that way can be later unlocked (all at once) using the Multiple unlocking procedure.

  • Page 14: Multiple Locking Procedure With Multi Key

    Metra ELS User Manual NOTE: If fingerprint is chosen than insert your finger in the Fingerprint module. STEP 3: Device enters MULTIPLE locking mode of operation indicated by time countdown on the Display. STEP 4: You can lock several lockers until time countdown completes.

  • Page 15: User Waiting Time Increment

    Metra ELS User Manual STEP 1: Approach the RFID media to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold the RFID media in the field for a few moments for device to read and process it.

  • Page 16: Locking Procedure - Payment Required

    Metra ELS User Manual  Locking procedure – payment required Steps 1 are the same as in all normal locking procedures. STEP 3: When the RFID media / PIN code / fingerprint is accepted as a locker key sign “Euro” / “Coin” / ”GbP” / ”PAY”...

  • Page 17: Unlocking Procedures

    Metra ELS User Manual  Unlocking procedures  Locker locked with RFID media STEP 1: Approach the RFID media to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold the RFID media in the antenna field for a few moments for device to read and process it.

  • Page 18: Locker Locked With Fingerprint

    Metra ELS User Manual STEP 2: Sign “Pin” is flashing and beep acoustic signal is heard. Enter the PIN code that was used to lock  corresponding locker and confirm it with key.  NOTE: key cancels the procedure. STEP...

  • Page 19: Multiple Unlocking Procedure (Pin Code Or Fingerprint)

    Metra ELS User Manual STEP 3: If the same finger is presented correctly corresponding locker is unlocked and opened. Short acoustic signal is also activated.  NOTE   If sign “Euro” / “Coin” / ”GbP” / ”PAY” / “USd / “CHF”...

  • Page 20: Multiple Unlocking Procedure (User Key And Multi Key)

    Metra ELS User Manual NOTE: If fingerprint was chosen sign “FP” is flashing and beep acoustic signal is heard. Insert your finger in the Fingerprint module. STEP 3: If correct PIN code is entered / fingerprint presented, sign “ALL” is displayed.
  • Page 21 Metra ELS User Manual STEP 1: Approach the User / Multi key to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold the RFID media in the antenna field for a few moments for device to read and process it.

  • Page 22: Exceeded Tenancy Time

    When tenancy time is exceeded additional payment is required (depends of set payment parameters). See also “Metra ELS & ELS SELECT – Technical Manual” for more information. Procedure described in this paragraph is an addition to unlocking procedures described in previous paragraphs.

  • Page 23: Use As An Information Terminal

    Metra ELS User Manual If “bLOC” is displayed when unlocking, tenancy time is expired. Go to the cashier’s/information desk.  Use as an information terminal If the RFID media is presented and recognized as a locker key on different device the locker number is flashing on the display and interrupted acoustic signal is activated.

  • Page 24: Use Of Emergency Open Key

    Metra ELS User Manual  Use of Emergency open key  NOTE  USE FOR EMERGENCIES ONLY! If the RFID media is presented and recognized as a special Emergency open key, all lockers connected to the Locker Controller start to unlock and open one after...

  • Page 25: Entering The Master Mode By Presenting The Master Card

    Metra ELS User Manual STEP 2: Sign “CodE” starts flashing beep acoustic signal is heard. STEP 3: Type-in a Master code (up to 16 digits). Signs “I” are displayed for each entered digit. Confirm the Master  code with the key.

  • Page 26: Opening Locker With 4 Key Keypad

    Metra ELS User Manual STEP 2: When the Master card is recognized Locker Controller turns to Master mode of operation. It is indicated by flashing 3 dots on the display. Remove the Master card form the antenna filed.  NOTE ...

  • Page 27: Closing Back The Locker Opened In Master Mode

    Metra ELS User Manual NOTE: If you want to open all lockers enter “0” and  confirm it with key. All the lockers connected to that Locker Controller start to unlock and open one after another and corresponding locker numbers are displayed.
  • Page 28 Controller turns to Basic Setup mode of operation. Sign “CodE” (if “Special Keys Mode” is set to “On-line” in Metra ELS/LCC NET software) or “Aud” (if “Special Keys Mode” is set to “Off-line” in Metra ELS/LCC NET software) as first parameter is displayed.

  • Page 29: Actions And Parameters

     Actions and Parameters PARAMETER MASTER CODE Not avaliable if “Special Keys Mode” is set to “On-line” in Metra ELS/LCC NET software.  While sign “CodE” is displayed press the key. Sign “nbr” is displayed. Type in the number from 1 to 5 (Up to 5 different Master Codes can be stored).
  • Page 30 ERASE ALL SPECIAL KEYS ACTION AND PIN CODES Not avaliable if “Special Keys Mode” is set to “On-line” in Metra ELS/LCC NET software. This erases all current parameter values and sets them back to factory default values.  While sign “ErAS” is displayed press the key.
  • Page 31 Metra ELS User Manual PARAMETER MINIMAL PIN LENGTH Minimal PIN code length is set to 1 by default. This means that someone can close the locker with minimal 1 digit or maximal 4 digits PIN code. This parameter can be also set up to 2, 3, 4 or 5. If set to 4, only 4 digit PIN codes are accepted.

  • Page 32: Warning Signalization

    Metra ELS User Manual  Warning signalization If locker was unlocked but not opened (door is jammed) blue dot lights up on the right side of the 4 digit LED display.  Alarm signalization If any of the lockers gets broken in, the alarm notice is displayed. The interrupted acoustic signal is turned on.

  • Page 33: Emergency Opening Of All Lockers

    Metra ELS User Manual  Emergency opening of all lockers If emergency opening of all Lockers is initiated remotely by the network the system signals this by acoustic signal and displaying “EOPn” message for few seconds! All the lockers connected to that Locker Controller start to unlock and open one after another and corresponding locker numbers are displayed.
