- Page 1 Control Unit ELS RFID User Manual...
-
Page 2: Table Of Contents
Control Unit ELS RFID User Manual Table of contents Control Unit ELS RFID User Manual ....................... 2 Product description..........................2 User interface ............................3 Display Unit ............................. 3 Coin acceptor (optional) ........................3 Euro deposit pad (optional) ......................4 Operation indication ..........................4 Indication of unoccupied locker ...................... -
Page 3: Control Unit Els Rfid User Manual
However, should any errors be detected, Metra inženiring would greatly appreciate being informed of them. Metra inženiring d.o.o. can assume no responsibility for any errors in this manual. Product description Control unit ELS RFID is used in Metra Electronic Locking System (ELS) which is primarily designed and used for locking lockers. -
Page 4: User Interface
Control Unit ELS RFID User Manual User interface Display Unit description 4 digit LED display with decimal points. Antenna field or TechnoGym reader. Standard models are supplied with front mask in gray colour and LED display in blue colour. For additional colours contact Metra sales. -
Page 5: Euro Deposit Pad (Optional)
Control Unit ELS RFID User Manual Euro deposit pad (optional) Euro deposit pad is mounted under the door strike. The locker can be locked only if a coin is inserted. The coin is used as a deposit while the locker is closed/locked. -
Page 6: Basic Operation
Control Unit ELS RFID User Manual Basic operation User can choose any unoccupeid locker. User locks the locker by using RFID media (card, wristband, tag…). Only one locker at the same level can be locked by the same RFID media. -
Page 7: Presenting Rfid Media As A Locker Key
Control Unit ELS RFID User Manual Presenting RFID media as a locker key Approach the RFID media to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold it in the antenna field for a few moments for Control Unit to read and process the RFID media. -
Page 8: Locking Procedure
Control Unit ELS RFID User Manual Locker number is flashing and the interrupted beep acoustic signal is activated. The locker was already locked at different Control Unit by this RFID media. Only one locker can be locked with the same RFID media. -
Page 9: User Waiting Time Increment
Control Unit ELS RFID User Manual STEP 2: Approach the RFID media to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold the RFID media in the field for a few moments for Control Unit to read and process it. -
Page 10: Multiple Locking Procedure
Control Unit ELS RFID User Manual STEP 3: Sign ”Euro”/“Coin”/”GbP”/”PAY”/”USd” is displayed on Display unit. User is asked for payment to finalize the locking procedure. STEP 4: Insert a coin in the coin acceptor. Coin value is displayed after the insertion. -
Page 11: Locking Procedure - Deposit Required
Control Unit ELS RFID User Manual STEP 3: When the RFID media is accepted as a Multi key the corresponding locker is locked and its number is displayed. You can now repeat the locking procedure on multiple lockers. Locking procedure – deposit required STEP 1: Insert coin in coin deposit pad. -
Page 12: Multiple Unlocking Procedure
Control Unit ELS RFID User Manual Multiple unlocking procedure Step 1 is the same as in normal unlocking procedure. STEP 2: Display shows sign “ALL” following by locker numbers of previously locked lockers by this Multi key. Each number is displayed for 1.5 second. -
Page 13: Opening Single Locker
Control Unit ELS RFID User Manual Opening single locker STEP 1: Approach the Master card to the antenna field. Reading distance is 3 – 5 centimetres from the device surface. Hold the Master card in the field for a few moments. -
Page 14: Opening All Lockers
Control Unit ELS RFID User Manual STEP 5: While the locker number is flashing, present the Master card again to the antenna field to confirm unlocking. When the Master card is recognized, a short beep acoustic signal is activated and locker is unlocked. -
Page 15: Closing Back The Locker Opened With Master Card
Control Unit ELS RFID User Manual STEP 5: While “ALL” is flashing, present the Master card again to the antenna field to confirm unlocking all the lockers connected to that Control Unit. Remove the Master card. STEP 6: All the lockers connected to that Control Unit start to open one after another and corresponding locker number is displayed. -
Page 16: Warning Signalization
Control Unit ELS RFID User Manual STEP 2: Approach the Master card to the antenna field. Reading distance is 2 – 5 centimetres from the device surface. Hold the card in the field for a few moments for Control Unit to read and process the card. -
Page 17: Alarm Signalization
Control Unit ELS RFID User Manual Alarm signalization Locker brake-in Alarm If locker brake-in is detected the alarm notice is displayed. The interrupted acoustic signal is turned on. Display alternately shows '-AL-' notice and the locker number. Control Unit box brake-in Alarm If Control Unit box brake-in is detected, the alarm notice is displayed. -
Page 18: Emergency Opening Of All Lockers
Control Unit ELS RFID User Manual Emergency opening of all lockers If emergency opening of all Lockers is initiated remotely by the network the system signals this by acoustic signal and displaying “EOPn” message for few seconds! Error mode of operation If display shows »Err1«... -
Page 19: Warnings For User
Control Unit ELS RFID User Manual Warnings for User Locker manufacturer should place on the final product relevant warnings (stickers) about locker usage: Be sure the Locker is properly locked. If not sure try lock/unlock procedure again. Use locker at your own risk. -
Page 20: Appendix
Control Unit ELS RFID User Manual While locking watch your fingers and clothes. Caution: door ejects automatically when unlocking. Caution! Slippery floor. Do not spray or splash water on Locker! Appendix User instructions sticker Locking/unlocking sticker Left arrow sticker Right arrow sticker... - Page 25 WARNING - WARNUNG - OPOZORILO ENG: Be sure the Locker is properly locked. If not sure try lock/unlock procedure again. GER: Vergewissern Sie sich, daß Ihr Garderobenfach richtig verriegelt ist. Sind Sie nicht sicher, wiederholen Sie zuerst das Entriegeln und danach das Verriegeln. SLO: Preprièajte se, èe je omarica pravilno zaklenjena.
