- Page 1 Quick start Little Six ENGLISH...
-
Page 2: Table Of Contents
TABLE OF CONTENTS INTRODUCTION. SAFETY ADVICE GENERAL INSTRUCTIONS AND GUIDELINES FOR USE PARTS CHECKLIST IDENTIFYING THE SCREWS, BOLTS & WASHERS TOOLS REQUIRED FOR ASSEMBLY ADDITIONAL EQUIPMENT THAT YOU WILL NEED (TO FLY AIRCRAFT) PLANNING YOUR INSTALLATION ASSEMBLING THE TOP FRAME INSTALLING THE MOTORS CONNECTING THE ESCS TO THE MOTORS CHECKING THE DIRECTION OF ROTATION FOR YOUR MOTORS... -
Page 3: Introduction
Ensure that you fully review all of the information in this instruction manual and familiarise yourself with t he characteristics of this SKY-HERO aircraft before attemp- safety in mind and is provided to help you assemble ting to fly it.This instruction manual has been designed with... -
Page 4: General Instructions And Guidelines For Use
GENERAL INSTRUCTIONS AND GUIDELINES FOR USE • The aircraft should not be flown by children and definitely not anyone under the age of 14 • Failure to follow and comply with the safety advice and recommendations in this manual, can result in serious injury to you, others or property. -
Page 5: Parts Checklist
PARTS CHECKLIST N° DESCRIPTION PART NUMBER BUTTON HEAD PLASTIC SCREW M3 X 10MM SKH07-111 MAIN FRAME LITTLE 6 UP SKH03-011-U HALF FRAME SPACER SKH01-102 MOTOR (SKY HERO X2806 950KV*) SKH04-007 (*) MOTOR FRAME BLACK SKH01-005-BK WASHER M3 SKH07-111 BUTTON HEAD SCREW M3 X 6MM SKH07-111 ESC (40 AMP 6S SimonK Opto*) SKH04-003 (*) -
Page 6: Identifying The Screws, Bolts & Washers
IDENTIFYING THE SCREWS, BOLTS & WASHERS BUTTON HEAD SCREW M4 X 40MM BUTTON HEAD SCREW M4 X 12MM BUTTON HEAD SCREW M3 X 6MM BUTTON HEAD PLASTIC SCREW M3 X 10MM SOCKET HEAD SCREW M3 X 8MM HEX NUT NYSLTOP M3 HEX NUT NYSLTOP M4 WASHER M3 WASHER M4... -
Page 7: Tools Required For Assembly
PLANNING YOUR INSTALLATION Before starting to assemble your SKY-HERO aircraft, it is important to plan your build. You should check that you have all of the parts and components that you will need. You should also think about what accessories you might want to add to the aircraft and also where on the frame you will locate them. -
Page 8: Assembling The Top Frame
ASSEMBLING THE TOP FRAME Attach the half frame spacers (3) to the upper frame (2) using the M3 x 10 mm Button Head Plastic screws (1). Also attach the canopy bracket using M3 x 6 mm button head screws (7). Use a small drop of Blue thread-lock on the screws. -
Page 9: Installing The Motors
– with dangerous consequences if the aircraft is in flight. Note: For more information on mounting motors, you can visit the SKY-HERO channel on YouTube and watch the video “Sky Hero How to Mount Your Motors”: https:/ /www.youtube.com/watch?v=1-xQFuDLJi0... -
Page 10: Connecting The Escs To The Motors
If you have not already done so, you should calibrate your ESC to your transmitter (refer to the manual of your ESC for the method to follow) If you are using a SKY-HERO supplied ESC, see Appendix 1 in this manual for the ESC instructions. -
Page 11: Overview Of Aircraft Arms Direction Of Rotation
ESC signal cable with the same number (between 1 - 6) will make things easier when you come to connect the motors to your Flight Controller. Further help can be found by watching the Video «SKY-HERO HOW TO ASSEMBLE YOUR MOTOR MOUNTS» on the Sky-HERO YouTube channel: https:/ /www.youtube.com/watch?v=bvkSoewk7Mw... -
Page 12: Assembly Of The Complete Arm With Motor & Esc
ASSEMBLY OF THE COMPLETE ARM WITH MOTOR & ESC The carbon tube has 2 pairs of holes. One pair has a smaller gap between them; (Part No. 13/14/15) this end of the tube should be fixed in the motor mount. On the inside of each motor mount there are two small studs, these must be orientated to coincide with the holes that are in the carbon arms. -
Page 13: Aircraft Motor Rotation And Identification
AIRCRAFT MOTOR ROTATION AND IDENTIFICATION... -
Page 14: Mounting The Arms Onto The Frame
MOUNTING THE ARMS ONTO THE FRAME Returning to the upper chassis that you partly assembled in the section «Assembling the Top Frame» , attach all arms in accordance with the direction of rotation of the motors displayed on the diagram in section «Aircraft Motor rotation and Identification»... -
Page 15: Cables Positioning
CABLES POSITIONING... -
Page 16: Cog Location & Naza Flight Controller Installation
CoG LOCATION & NAZA FLIGHT CONTROLLER INSTALLATION If you are using the NAZA Flight Controller with GPS, the diagram below provides some guidance on where to locate the standard components NAZA V2 LED position on the lower framer Center of gravity Suitable location GPS position... -
Page 17: Attaching The Lower Frame
ATTACHING THE LOWER FRAME If you want to install additional electronics between the upper and lower frame you should install them securely now, before proceeding to the next step If you previously attached the M4 knurl button long nuts (17), remove them in order to attach the lower frame and then secure the lower frame using the M3 x 10 mm Button Head screws (1) to secure the frame onto the Half Frame Spacers (3). -
Page 18: Attaching The Canopy Supports
ATTACHING THE CANOPY SUPPORTS... -
Page 19: Attaching The Landing Skids To The Lower Frame
ATTACHING THE LANDING SKIDS TO THE LOWER FRAME If you plan to use a Camera or install a Gimbal, below the aircraft, you will need to install the landing skids. Otherwise if you prefer a sleeker look, you can leave the landing skids off. Secure the landing skids using 4 x Button Head Screws M4 x 12MM and 4 x Knurl Button Long M4. -
Page 20: Attaching A Camera To The Frame Using The Cam Plate
ATTACHING A CAMERA TO THE FRAME USING THE CAM PLATE The Little 6 comes with a vibration isolating camera mount (27) that allows you to attach a Go Pro Hero type camera to the underside of the aircraft. To use the mount insert the isolation dampers (28) into their holes in the lower frame, then attach the camera mount (27) to the other end of the isolation dampers. -
Page 21: Attaching The H3-3D Gimbal Using The Zenmuse Mounting Plate
ATTACHING THE H3-3D GIMBAL USING THE ZENMUSE MOUNTING PLATE The Little 6 is supplied with a mounting plate (20) to assist in mounting the Zenmuse H3-3D Gimbal onto the aircraft. (Refer to the diagram below ). ZENMUSE H3-3D Screws supplied with gimbal Assemble your Gimbal and attach it to the lower plate using the Zenmuse mounting plate (20) using the screws provided with the Zenmuse and the nuts M3 (11). -
Page 22: Identifying The Propeller's Direction Of Rotation
IDENTIFYING THE PROPELLER’S DIRECTION OF ROTATION Always place the convex side of the propeller to the top Leading edge (front of the propeller) Trailing edge (back of the propeller) -
Page 23: Attaching The Prop Adapter And Propeller On The Motor
ATTACHING THE PROP ADAPTER AND PROPEL- LER ON THE MOTOR Install the prop shafts (supplied with your motors) on each motor. Depending on the diameter of the prop shaft, you might need to use an insert or washer that comes with your propellers to ensure a tight fit to the shaft and proper alignment. Depending on the diameter of the prop shaft, you might need to use an insert or washer that comes with your propellers to ensure a tight fit to the shaft and proper alignment. -
Page 24: Attaching The Canopy
ATTACHING THE CANOPY Insert the grommets (30) into the two canopy holes and attach the canopy to the frame, securing it using the clips (29). -
Page 25: Installing The Battery
INSTALLING THE BATTERY Insert your battery as shown, securing it with the battery strap (38). Ensure that the aircraft is reasonably well around it’s CoG point Insert battery here... -
Page 26: Checks Before The First Flight
CHECKS BEFORE THE FIRST FLIGHT OPERATE YOUR AIRCRAFT SAFELY Refer to and follow all safety precautions mentioned in the “General Instructions and Guidelines for use” section of this manual. Ensure that you always turn on your transmitter before connecting the aircraft battery power. After flying, make sure that you always disconnect the aircraft battery before turning off the transmitter. -
Page 27: Regular Maintenance
REGULAR MAINTENANCE • Lubricate the motor bearings every 10 flights with specific oil for bearings. • Replace your motors after 100 flights or in case of any unusual noises. • Check the condition of your propellers and ensure that they are securely mounted. •... -
Page 28: Limited Warranty
Warranty. The Warranty applies only to products purchased from an authorized dealer of SKY-HERO products. Sales via third parties are not covered by this Warranty. Your “Little 6” is covered by this Warranty under the specified Warranty period starting from the original purchase date. Proof of the original purchase date is requi- red for Warranty service. - Page 29 In addition, SKY-HERO shall also not be responsible for failure or any third party equipment, even if SKY-HERO has been advised of the possibility. SKY-HERO shall not be liable for any personal injury or death or any loss or damages to property arising from the product used in a situation in which personal injury or deaths is likely occur.
-
Page 30: Appendix 1 - Esc Manual
APPENDIX 1 - ESC MANUAL... - Page 31 SKY-HERO 42, rue des Vétérinaires, 1070 Anderlecht. Belgique. SAV@sky-hero.com +32(0)23301845...
