Summary of Contents for Brigade CVCFB5301
-
Page 1: Installation Guide
Installation Guide BRIGADE Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our web site at www.brigade.ca All Refrigerator/Freezer (030113) F21128 EN... -
Page 2: Table Of Contents
Table of Contents IMPORTANT– Please Read and Follow! Warnings & Important Information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 •... - Page 3 IMPORTANT– IMPORTANT– Please Read and Follow! Please Read and Follow! A GFI shall be used if required by NFPA-70 (National Electric Code), federal/state/local It is your responsibility to: laws, or local ordinances. • comply with installation specifications and dimensions. • properly install unit. •...
-
Page 4: Dimensions & Specifications (30" & 36" Professional)
Dimensions Specifications 30” All Refrigerator/All Freezer 30” All Refrigerator/All Freezer Description CVCFB5301 CVCRB5301 Overall width 30” (76.2 cm) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall height from bottom Overall depth from rear To front edge of side trim: 22-3/16”... - Page 5 Specifications 30” All Refrigerator/All Freezer 30” All Refrigerator/All Freezer with Flush Mount Trim with Flush Mount Trim Description CVCFB5301/Flush Mount CVCRB5301/Flush Mount Overall width 30” (76.2 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
-
Page 6: Cutout Dimensions (30" Professional & Professional With Flush Mount Trim)
Cutout Dimensions Anti-Tip Dimensions 30” All Refrigerator/All Freezer 30” All Refrigerator/All Freezer Anti-Tip Location Electric Outlet Location 6 ” (1 5 .2 c m ) Two 2”x 4” mounting boards 9 ” 3” (7.6 cm) x 3-1/2” (8.9 cm) (2 2 .9 c m ) 9 ”... -
Page 7: Cutout Dimensions (36" Professional & Professional With Flush Mount Trim)
Cutout Dimensions Anti-Tip Dimensions 36” All Refrigerator/All Freezer 36” All Refrigerator/All Freezer Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) Two 2”x 4” mounting boards 9 ” 3” (7.6 cm) x 3-1/2” (8.9 cm) (2 2 .9 c m ) 9 ”... - Page 8 Dimensions Dimensions Dual 30” & 36” All Refrigerator/All Freezer Dual 30” All Refrigerator/All Freezer 3 – 1 9 / 3 2 ” (9 .1 c m 3 – 1 9 / 3 2 ” (9 .1 c m 4 ” –...
- Page 9 Dimensions Specifications Dual All Refrigerator/All Freezer* Dual 36” All Refrigerator/All Freezer Description (2) 30” Units (1) 36” & (1) 30” Unit (2) 36” Units Overall width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth from rear To front edge of side trim: 22-3/16”...
- Page 10 Dimensions Dimensions Dual 30” All Refrigerator/All Freezer Dual 30” & 36” All Refrigerator/All Freezer with Flush Mount Trim with Flush Mount Trim 3 – 1 9 / 3 – 1 9 / 3 2 ” 3 2 ” (9 .1 c m (9 .1 c m 4 ”...
- Page 11 Dimensions Specifications Dual 36” All Refrigerator/All Freezer Dual All Refrigerator/All Freezer w/Flush Mount Trim* with Flush Mount Trim Description (2) 30” Units (1) 36” & (1) 30” Unit (2) 36” Units Overall width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm) Overall height from bottom 82-3/4”...
-
Page 12: Cutout Dimensions (Dual 30" Professional & Professional With Flush Mount Trim)
Cutout Dimensions Anti-Tip Dimensions Dual 30” All Refrigerator/All Freezer Dual 30” All Refrigerator/All Freezer Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) Two 2”x 4” mounting boards per unit 9 ” 3” (7.6 cm) x 3–1/2” (8.9 cm) 9 ”... -
Page 13: Anti-Tip Dimensions (Dual 30" & 36" Professional & Professional With Flush Mount Trim)
Cutout Dimensions Anti-Tip Dimensions Dual 30” & 36” All Refrigerator/All Freezer Dual 30” & 36” All Refrigerator/All Freezer Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) 9 ” 9 ” Two 2”x 4” mounting boards per unit (2 2 .9 (2 2 .9 c m ) -
Page 14: Anti-Tip Dimensions (Dual 36" Professional & Professional With Flush Mount Trim)
Cutout Dimensions Anti-Tip Dimensions Dual 36” All Refrigerator/All Freezer Dual 36” All Refrigerator/All Freezer Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) Two 2”x 4” mounting boards per unit 3” (7.6 cm) x 3–1/2” (8.9 cm) 9 ”... -
Page 15: Cabinet Information (Professional)
Cabinet Information Cabinet Information (Professional) (Professional) Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door face protrudes 1-3/4” (4.4 cm) from the cabinet face. The handle protrudes an additional face protrudes 1-3/4”... - Page 16 Cabinet Information Cabinet Information (Professional with Flush Mount Trim) (Professional with Flush Mount Trim) Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings with no protrusion into the room except the handle protrudes 2-1/2”...
-
Page 17: Custom Side Panel Dimensions (Professional)
Custom Side Panel Dimensions Custom Side Panel Dimensions (Professional) (Professional with Flush Mount Trim) 3/16” 3/4” (0.5 cm) 1” (1.9 cm) Z-Bracket Back filler (2.5 cm) 1/4” panel End panel (0.6 cm) 4 ” - 3 / 6 ” ” - 7 / ( 5 5 ( 1 5... -
Page 18: General Information
General Information General Information Area Requirements It is required that a separate circuit serving only this appliance be provided. This Water Supply Requirements • Do not use plastic water lines from the Verify the following: appliance is equipped with a power supply household plumbing to the water inlet •... -
Page 19: Flush Mount Side Trim Installation
General Information Flush Mount Side Trim Installation • Most of the unit’s weight is at the top. TIP OVER HAZARD Note: If the unit is to be installed flush with the cabinets, the flush mount side trim must be Extra care is needed when moving the unit installed. -
Page 20: Hinge Adjustment
Hinge Adjustment Front of unit Remove 4 side screws and remove unit top. Plug in power cord to verify operation. Place unit within 3” of being flush with cabinets. Loosen the 4 hinge screws. Adjust door. Note: Make sure power switch and showroom switch Note: To avoid cabinet damage, place cardboard Retighten 4 hinge screws. -
Page 21: Kickplate Installation
Door Stop Adjustment 90˚ 110˚ 120˚ Open refrigerator door so door stop and shoulder Remove shoulder screw and place in 90˚ or Turn on water supply and check for leaks. Lift unit off rollers to desired height and level unit using screw are accessible. -
Page 22: Performance Checklist
Performance Checklist Press “ACTIVATE CONTROLS” button pad and close door. Note: There is a 6 minute delay before the unit starts. h Align/square door(s). h Verify cabinet size. h Verify drain pan is properly installed and h Verify electrical supply and water supply (if applicable). -
Page 23: Control Panels
Verify Operations Service & Registration Control Panels Only authorized replacement parts may be used in performing service on the appliance. All Refrigerator Do not repair or replace any part of the appliance unless specifically recommended in FREEZER REFRIGERATOR the manual. All other servicing should be MAX FRZ MAX REF DOOR OPEN ACTIVATE...
