Summary of Contents for Brigade CVCSB
-
Page 1: Installation Guide
Installation Guide BRIGADE Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) Professional or visit our web site at brigade.ca Built-in Bottom-Freezer and Side-by-Side Refrigerator/Freezer F21258 EN (080113) -
Page 2: Table Of Contents
Table of Contents IMPORTANT—Please Read and Follow! Warnings & Important Information _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ _ 3 Professional Side-by-Side •... - Page 3 IMPORTANT—Please Read and Follow! IMPORTANT—Please Read and Follow! A GFI shall be used if required by NFPA-70 (National Electric Code), federal/state/local It is your responsibility to: • comply with installation specifications and dimensions. laws, or local ordinances. • properly install unit. •...
-
Page 4: Specifications
Specifications (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By Side Description CVCSB CVCSB “D” Overall width 42” (106.7 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth from rear To front edge of side trim: 22-3/16”... - Page 5 (Side-By-Side with flush mount trim) 42” Side-By-Side with Flush Mount Trim 42” Side-By-Side with Description CVCSB/Flush Mount CVCSB “D”/Flush Mount Flush Mount Trim Overall width 42” (106.7 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max.
-
Page 6: Cutout Dimensions (42")
Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By-Side Anti-Tip Location Electric Outlet Location 6 ” (1 5 .2 c m ) Two 2”x 4” Mounting Boards 9 ” 3” (7.6 cm) x 3-1/2” (8.9 cm) (2 2 .9 c m ) 9 ”... -
Page 7: Cutout Dimensions (48")
Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 48” Side-By-Side 48” Side-By-Side Anti-Tip Location Electric Outlet Location 6 ” (1 5 .2 c m ) Two 2”x 4” Mounting Boards 3” (7.6 cm) x 3-1/2” (8.9 cm) 9 ” (2 2 .9 c m ) 3 ”... -
Page 8: Dimensions & Specifications (36")
Dimensions Specifications (Bottom-Freezer) (Bottom-Freezer) 36” Bottom-Freezer 36” Bottom-Freezer Description CVCBB Overall width 36” (91.5 cm) Overall height from bottom 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth from rear To front edge of side trim: 22-3/16” (56.4 cm) 36”... -
Page 9: Cutout Dimensions (36")
Cutout Dimensions Anti-Tip Dimensions (Bottom-Freezer) (Bottom-Freezer) 36” Bottom-Freezer 36” Bottom-Freezer Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) Two 2”x 4” Mounting Boards 9 ” 3” (7.6 cm) x 3-1/2” (8.9 cm) (2 2 .9 c m ) 9 ”... -
Page 10: Cabinet Information (Professional)
Cabinet Information Cabinet Information (Professional) (Professional) Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door Professional models fit “semi-flush” in standard 24” (61.0 cm) deep cabinet openings. The door face protrudes 1-3/4” (4.4 cm) from the cabinet face. The handle protrudes an additional face protrudes 1-3/4”... - Page 11 Cabinet Information Cabinet Information (Professional with Flush Mount Trim) (Professional with Flush Mount Trim) Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings with Professional models with flush mount trim fit flush in standard 24” (61.0 cm) deep cabinet openings with no protrusion into the room except the handle protrudes 2-1/2”...
-
Page 12: Custom Side Panel Dimensions (Professional)
Custom Side Panel Dimensions Custom Side Panel Dimensions (Professional) (Professional with Flush Mount Trim ) 3/16” 3/4” (0.5 cm) (1.9 cm) Back filler Z-Bracket 1” End panel panel (2.5 cm) 1/4” 3/4” (1.9 cm) (0.6 cm) End panel 4 ” - 3 / 6 ”... -
Page 13: General Information
General Information General Information Area Requirements It is required that a separate circuit serving • Do not use plastic water lines from the only this appliance be provided. This C A U T I O N Verify the following: household plumbing to the water inlet appliance is equipped with a power supply •... -
Page 14: Flush Mount Side Trim Installation
General Information Flush Mount Side Trim Installation (sold separately) • Most of the unit’s weight is at the top. TIP OVER HAZARD Note: If the unit is to be installed flush with the cabinets, the flush mount side trim must be Extra care is needed when moving the Appliance is top heavy and tips easily installed first. -
Page 15: Hinge Adjustment
Hinge Adjustment Front of unit Remove four side screws and remove unit top. Loosen the four hinge screws. Adjust door. Carefully move unit until semi flush with cabinet Place unit within 3” of being flush with cabinets. Retighten four hinge screws. (depending on unit). -
Page 16: Kickplate Installation
Door Stop Adjustment (Side-by-Side) 90˚ Screw 110˚ Wall 120˚ 2 x 4 Refrigerator Lift unit off rollers to desired height and level unit Attach positive secure self-tapping bolts to 2x4 Open refrigerator door so door stop and shoulder Remove shoulder screw and place in 90° or using a 5/16”... -
Page 17: Water Filter Installation
Water Filter Installation (Side-by-Side with Dispenser) Water Filter System Specification and Performance Data Sheet This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration of less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.* (100% safety factors built-in for unmetered usage for health claims only.) NSF Specified... -
Page 18: Final Installation
Final Installation Performance Checklist Replace top air grille. Using an 8” magnetic nut driver, replace the two 1/4” screws. Replace the center grille louver. Open door. Display should flash. □ Verify cabinet size. □ Align/square door(s). □ Verify drain pan is properly installed and □... -
Page 19: Control Panels
Service & Registration Verify Operations Control Panels If service is required, call your dealer or authorized service agency. The name of the authorized service agency can be obtained from the dealer or distributor in your area. Bottom-Freezer Have the following information readily available. FREEZER FREEZER REFRIGERATOR...
