Page 1: Installation Guide
Installation Guide BRIGADE Viking Range, LLC 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-(845-4641) Custom Panel or visit our web site at brigade.ca Built-in Bottom-Freezer and Side-By-Side Refrigerator/Freezer (08013) F21259 EN... -
Page 2: Table Of Contents
Table of Contents IMPORTANT — Please Read and Follow Warnings & Important Information ____________________________________________________________________3 • Make sure that incoming voltage is the same as Your safety and the safety of others is Bottom-Freezer unit rating. An electric rating plate specifying Dimensions and Specifications (36”) __________________________________________________________6 very important. - Page 3 IMPORTANT— Please Read and Follow! A GFI shall be used if required by NFPA-70 (National Electric Code), federal/state/local WARNING WARNING laws, or local ordinances. • The required use of a GFI is normally related to the location of a receptacle with respect to ELECTRICAL SHOCK TIP OVER HAZARD any significant sources of water or moisture.
-
Page 4: Bottom-Freezer
Dimensions Specifications (Bottom-Freezer) (Bottom-Freezer) 36” Bottom-Freezer 36” Bottom-Freezer Description CFDBB Overall width 36” (91.5 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-13/16” (60.5 cm) 3 5 ”... -
Page 5: Cutout Dimensions (36")
Cutout Dimensions Anti-Tip Dimensions (Bottom-Freezer) (Bottom-Freezer) 36” Bottom-Freezer 36” Bottom-Freezer Electric Outlet Location 6 ” (1 5 .2 c m ) 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) Anti-Tip Location 8 2 - 7 / 8 ”... -
Page 6: Overlay Dimensions (36")
Overlay Dimensions Custom Grille Dimensions (Bottom-Freezer) (Bottom-Freezer) 36” Custom Panels 36” Custom Grille 1 / 2 ( 1 . 2 ” 3 / 4 ” ( 1 . 9 ” 2 - 3 d i u d i u d i u ( 6 . -
Page 7: Dimensions (42")
Custom Grille Dimensions Dimensions (Bottom-Freezer) (Side-By-Side) Dual 36” Custom Grille 42” Side-By-Side 4 - 1 1 / 2 1 / 6 ” ( 1 . 2 ( 1 1 4 ” 3/4” 1/8” 1/2” . 2 7 3 / 4 ”... -
Page 8: Dimensions (48") Specifications (42" And 48")
(Side-By-Side) (Side-By-Side) 48” Side-By-Side 42” Side-By-Side Description CFDSB CFDSB “D” Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-13/16” (60.5 cm) To front of top grille: 24-3/4”... -
Page 9: Cutout Dimensions (42")
Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By-Side Electric Outlet Location 6 ” (1 5 .2 c m ) 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) Anti-Tip Location 8 2 - 7 (2 1 0 / 8 ”... -
Page 10: Cutout Dimensions (48")
Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 48” Side-By-Side 48” Side-By-Side Electric Outlet Location Anti-Tip Location 6 ” (1 5 .2 c m ) 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 / 8 ”... -
Page 11: Overlay Dimensions (42")
Overlay Dimensions Overlay Dimensions (Side-By-Side) (Side-By-Side) 42” Custom Panels 48” Custom Panels 42” Custom Panels 48” Custom Panels ” 3 / 4 with Dispenser - 1 1 - 3 / ” with Dispenser 3 / 4 ( 1 . 9 / 1 6 ( 4 6 ( 4 7... -
Page 12: Custom Grille Dimensions (42")
Custom Grille Dimensions Custom Grille Dimensions (Side-By-Side) (Side-By-Side) 42” Custom Grille 48” Custom Grille 1 / 2 ( 1 . 2 ” 1 / 2 ” ( 1 . 2 3 / 4 d i u d i u d i u ”... -
Page 13: Cabinet Information
Cabinet Information Cabinet Information Custom panel models, (with 3/4” [1.9 cm], thick panels and custom handles locally supplied), Custom panel models can be installed in standard 24” (61.0 cm) deep openings. However, fit flush in 25” (63.5 cm) deep (countertop depth) cabinet openings with no protrusion into the door faces and top ventilation grille will protrude 3/4”... -
Page 14: Custom Side Panel Dimensions
Custom Side Panel Dimensions Custom Panel General Information Custom finishing options • Panel thickness must not exceed 1” (2.5 cm) • All installations must allow for the refrigerator on hinge side. Thicker panels will interfere with 1” and freezer door to open a minimum of 90˚. door swing and clearance. -
Page 15: Ice And Water Dispenser Bezel Removal
Ice and Water Dispenser Bezel Removal Custom Door Panel Installation (if required cont.) (Refrigerator or Freezer) Remove 2 additional screws under Remove mounting support. Remove handle side cabinet screws Remove all screws from handle side door trim. top section of bezel. and trim with a phillips screwdriver. -
Page 16: Custom Door Panel Installation - (Refrigerator Or Freezer)
Custom Door Panel Installation Custom Freezer Door Panel Installation (Refrigerator or Freezer cont.) (Bottom-Freezer Only cont.) Slide custom wood panel to the hinge side, ensuring Reinstall handle side door trim Open freezer door. Remove door trim screws Remove bracket. “Z” bracket engages the door bracket. and door trim screws. -
Page 17: Ice And Water Dispenser Bezel Installation
Ice and Water Dispenser Bezel Installation Ice and Water Dispenser Bezel Installation (if required) (if required cont.) Install custom wood panels per product’s Locate opening in door and position bezel. Adjust and reposition bezel Replace spill tray in lower part of bezel. installation instructions. -
Page 18: Custom Grille Installation
Custom Grille Installation Bottom-Freezer Custom Panel Hinge Cutout (if required) (cont.) 5 / 8 ” ( 1 . 6 3 ” ( 7 . 6 For a left hinge door, cut 5/8” x 3” in lower left corner. Measure and cut 2-1/16” diagonal in Pull air grille assembly forward. -
Page 19: General Information
General Information General Information Area Requirements Water Supply Requirements A 115 volt, 60-Hz, 15 amp, fused, electrical • Copper tubing route must be above 35˚ F Verify the following: supply is required. It is required that a separate (1.7˚ C) to prevent water line from freezing. •... -
Page 20: Installation
Installation General Information • Most of the unit’s weight is at the top. Extra Tip Over Hazard care is needed when moving the unit to Appliance is top heavy and tips easily when not prevent tipping. completely installed. Keep doors closed until appliance is completely installed and secured per •... -
Page 21: Hinge Adjustment
Hinge Adjustment Installation (cont.) Front of unit Carefully move unit until semi flush with cabinet Remove four side screws and remove unit top. Loosen the four hinge screws. Adjust door. Place unit within 3” of being flush with cabinets. (depending on unit). Retighten four hinge screws. -
Page 22: Kickplate Installation
Hinge Adjustment Door Stop Adjustment (cont.) (Side-by-Side) 120˚ Screw 110˚ Wall 90˚ 2 x 4 Refrigerator Attach positive secure self-tapping bolts Open refrigerator door so door stop and Remove shoulder screw and place in 90˚ Lift unit off rollers to desired height to 2 x 4 using a 22”... -
Page 23: Water Filter Installation
Water Filter Installation (Side-by-Side with Dispenser) Water Filter System Specification and Performance Data Sheet This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration of less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.* (100% safety factors built- in for unmetered usage for health claims only.) NSF Specified... -
Page 24: Final Installation
Final Installation Performance Checklist Replace top air grille. Using an 8” magnetic nut driver, replace the two 1/4” screws. Replace the center grille louver. Open door. The display should flash. □ Align/square door(s). □ Verify cabinet size. □ Verify drain pan is properly installed and □... -
Page 25: Control Panels
Verify Operations Service & Registration Control Panels If service is required, call your dealer or authorized service agency. The name of the authorized service agency can be obtained from the dealer or distributor in your area. Bottom-Freezer Have the following information readily available. FREEZER FREEZER REFRIGERATOR... - Page 26 Notes Notes ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________ ________________________________________________________________________________________________________________________________________________________...
