Brigade CFDBB5361 Installation Manual

Custom panel models all refrigerator/freezer/ side-by-side/bottom-mount

Advertisement

Quick Links

Installation Guide

BRIGADE
TM
Viking Range Corporation
111 Front Street
Greenwood, Mississippi 38930 USA
(662) 455-1200
For product information,
call 1-888-845-4641
or visit our web site at
Custom Panel Models
www.brigade.ca
All Refrigerator/Freezer/
U L
U L
C
Side-by-Side/Bottom-Mount
F21126 EN
(030113)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CFDBB5361 and is the answer not in the manual?

Questions and answers

Summary of Contents for Brigade CFDBB5361

  • Page 1: Installation Guide

    Installation Guide BRIGADE Viking Range Corporation 111 Front Street Greenwood, Mississippi 38930 USA (662) 455-1200 For product information, call 1-888-845-4641 or visit our web site at Custom Panel Models www.brigade.ca All Refrigerator/Freezer/ Side-by-Side/Bottom-Mount F21126 EN (030113)
  • Page 2: Table Of Contents

    Table of Contents IMPORTANT – Please Read and Follow Warnings & Important Information ____________________________________________________________________3 • Make sure that incoming voltage is the same as Your safety and the safety of others is Bottom-Mount unit rating. An electric rating plate specifying Dimensions and Specifications (36”) __________________________________________________________6 very important.
  • Page 3 IMPORTANT– Please Read and Follow! A GFI shall be used if required by NFPA-70 (National Electric Code), federal/state/local WARNING WARNING laws, or local ordinances. • The required use of a GFI is normally related to the location of a receptacle with respect to ELECTRICAL SHOCK TIP OVER HAZARD any significant sources of water or moisture.
  • Page 4: Bottom-Mount

    Specifications (Bottom-Mount) (Bottom-Mount) 36” Bottom-Mount 36” Bottom-Mount Description CFDBB5361 Overall width 36” (91.5 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-13/16” (60.5 cm) ”...
  • Page 5: Cutout Dimensions (36")

    Cutout Dimensions Anti-Tip Dimensions (Bottom-Mount) (Bottom-Mount) 36” Bottom-Mount 36” Bottom-Mount Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 ”...
  • Page 6: Overlay Dimensions (36")

    Overlay Dimensions Custom Grille Dimensions (Bottom-Mount) (Bottom-Mount) 36” Custom Panels 36” Custom Grille 1 / 2 ” ( 1 . 2 3 / 4 ” ( 1 . 9 ” 2 - 3 d i u d i u d i u ( 6 .
  • Page 7: Dimensions (42")

    Custom Grille Dimensions Dimensions (Bottom-Mount) (Side-By-Side) Dual 36” Custom Grille 42” Side-By-Side 4 - 1 1 / 2 1 / 6 ” ( 1 . 2 ( 1 1 4 ” 3/4” 1/8” 1/2” . 2 7 3 / 4 ”...
  • Page 8: Dimensions (48") Specifications (42" And 48")

    Dimensions Specifications (Side-By-Side) (Side-By-Side) 48” Side-By-Side 42” Side-By-Side Description CFDSB5421 CFDSB5421D Overall width 42” (106.7 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-13/16” (60.5 cm) To front of top grille: 24-3/4”...
  • Page 9: Cutout Dimensions (42")

    Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 42” Side-By-Side 42” Side-By-Side Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 8 2 - 7 / 8 ”...
  • Page 10: Cutout Dimensions (48")

    Cutout Dimensions Anti-Tip Dimensions (Side-By-Side) (Side-By-Side) 48” Side-By-Side 48” Side-By-Side Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 8 2 –...
  • Page 11: Overlay Dimensions (42")

    Overlay Dimensions Overlay Dimensions (Side-By-Side) (Side-By-Side) 48” Custom Panels 42” Custom Panels 42” Custom Panels 48” Custom Panels ” 3 / 4 with Dispenser with Dispenser - 1 1 - 3 / ” 3 / 4 / 1 6 ( 1 . 9 ( 4 6 ”...
  • Page 12: Custom Grille Dimensions (42")

    Custom Grille Dimensions Custom Grille Dimensions (Side-By-Side) (Side-By-Side) 42” Custom Grille 48” Custom Grille 1 / 2 1 / 2 ” ( 1 . 2 ( 1 . 2 ” 3 / 4 3 / 4 d i u d i u d i u ”...
  • Page 13: All Refrigerator/Freezer

    Dimensions Specifications (All Refrigerator/Freezer) (All Refrigerator/Freezer) 30” All Refrigerator/Freezer 30” All Refrigerator/Freezer Description CFDFB5301 CFDRB5301 Overall width 30” (76.2 cm) Overall height (from bottom) 82-3/4” (210.2 cm) min. to 84-1/16” (213.5 cm) max. Overall depth (from rear) To front edge of side trim: 23-13/16” (60.5 cm) To front of top grille: 24-3/4”...
  • Page 14: Cutout Dimensions (30")

    Cutout Dimensions Anti-Tip Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) 30” All Refrigerator/Freezer 30” All Refrigerator/Freezer Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 ”...
  • Page 15: Cutout Dimensions (36")

    Cutout Dimensions Anti-Tip Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) 36” All Refrigerator/Freezer 36” All Refrigerator/Freezer Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” (2 2 .9 c m ) 9 ” (2 2 .9 c m ) 7 9 - 3 ”...
  • Page 16: Dimensions (Dual 30")

    Dimensions Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 30” All Refrigerator/Freezer Dual 30” & 36” All Refrigerator/Freezer ” ” ( 7 3 ( 7 3 . 7 c . 7 c 3 - 1 3 - 1 / 2 ” / 2 ” ( 8 .
  • Page 17: Specifications (Dual)

    Dimensions Specifications (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 36” All Refrigerator/Freezer Dual All Refrigerator/Freezer* Description (2) 30” Units (1) 36” & (1) 30” Unit (2) 36” Units Overall width 60” (152.4 cm) 66” (167.6 cm) 72” (182.9 cm) Overall height (from bottom) 82-3/4”...
  • Page 18: Cutout Dimensions (Dual 30")

    Cutout Dimensions Anti-Tip Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 30” All Refrigerator/Freezer Dual 30” All Refrigerator/Freezer Electric outlet location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” 9 ” (2 2 .9 (2 2 .9 c m ) c m ) 7 9 - 3 8 2 - 7...
  • Page 19: Anti-Tip Dimensions (Dual 30" And 36")

    Cutout Dimensions Anti-Tip Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 30” & 36” All Refrigerator/Freezer Dual 30” & 36” All Refrigerator/Freezer Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” 9 ” (2 2 .9 (2 2 .9 c m ) c m )
  • Page 20: Anti-Tip Dimensions (Dual 36")

    Cutout Dimensions Anti-Tip Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 36” All Refrigerator/Freezer Dual 36” All Refrigerator/Freezer Electric Outlet Location 6 ” (1 5 .2 c m ) Anti-Tip Location 9 ” 9 ” (2 2 .9 (2 2 .9 c m ) c m ) 8 2 - 7 7 9 - 3...
  • Page 21: Overlay Dimensions (30" & 36")

    Overlay Dimensions Custom Grille Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) 30” Custom Panels 30” Custom Grille 1 / 2 ( 1 . 2 ” 3 / 4 ” ” ( 1 . 9 2 - 3 d i u d i u d i u 36”...
  • Page 22: Custom Grille Dimensions (36")

    Custom Grille Dimensions Custom Grille Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) 36” Custom Grille Dual 30” Custom Grille 4 - 1 1 / 2 1 / 6 1 / 2 ” ( 1 . 2 ( 1 1 4 ” 3/4” 1/8”...
  • Page 23: Custom Grille Dimensions (Dual 30" And 36")

    Custom Grille Dimensions Custom Grille Dimensions (All Refrigerator/Freezer) (All Refrigerator/Freezer) Dual 30” & 36” Custom Grille Dual 36” Custom Grille 4 - 1 1 / 2 4 - 1 1 / 2 1 / 6 1 / 6 ” 3/4” 1/8”...
  • Page 24: Cabinet Information

    Cabinet Information Cabinet Information Custom panel models, (with 3/4” [1.9 cm], thick panels and custom handles locally supplied), Custom panel models can be installed in standard 24” (61.0 cm) deep openings. However, fit flush in 25” (63.5 cm) deep (countertop depth) cabinet openings with no protrusion into the door faces and top ventilation grille will protrude 3/4”...
  • Page 25: Custom Side Panel Dimensions

    Custom Side Panel Dimensions Custom Panel General Information Custom finishing options • Panel thickness must not exceed 1” (2.5 cm) • All installations must allow for the refrigerator on hinge side. Thicker panels will interfere with 1” and freezer door to open a minimum of 90˚. door swing and clearance.
  • Page 26: Ice And Water Dispenser Bezel Removal

    Ice and Water Dispenser Bezel Removal Custom Door Panel Installation (if required cont.) (Refrigerator or Freezer) Remove handle side cabinet screws Remove 2 additional screws under Remove mounting support. Remove all screws from handle side door trim. top section of bezel. and trim with a phillips screwdriver.
  • Page 27: Custom Door Panel Installation - (Refrigerator Or Freezer)

    Custom Door Panel Installation Custom Freezer Door Panel Installation (Refrigerator or Freezer cont.) (Bottom-Mount Only cont.) Open freezer door. Remove door trim screws Remove bracket. Slide custom wood panel to the hinge side, ensuring Reinstall handle side door trim “Z” bracket engages the door bracket. and door trim screws.
  • Page 28: Ice And Water Dispenser Bezel Installation

    Ice and Water Dispenser Bezel Installation Ice and Water Dispenser Bezel Installation (if required) (if required cont.) Install custom wood panels per product’s Locate opening in door and position bezel. Adjust and reposition bezel Replace spill tray in lower part of bezel. installation instructions.
  • Page 29: Custom Panel Hinge Cutout

    Custom Grille Installation Bottom-Mount Custom Panel Hinge Cutout (cont.) (if required) 5 / 8 ” ( 1 . 6 3 ” ( 7 . 6 For a left hinge door, cut 5/8” x 3” in lower left corner. Measure and cut 2-1/16” diagonal in Pull air grille assembly forward.
  • Page 30: General Information

    General Information General Information Area Requirements Water Supply Requirements A 115 volt, 60-Hz, 15 amp, fused, electrical • Copper tubing route must be above 35˚ F Verify the following: supply is required. It is required that a separate (1.7˚ C) to prevent water line from freezing. •...
  • Page 31: Installation

    Installation General Information Tip Over Hazard • Most of the unit’s weight is at the top. Extra care is needed when moving the unit to Appliance is top heavy and tips easily when not prevent tipping. completely installed. Keep doors closed until appliance is completely installed and secured per •...
  • Page 32: Hinge Adjustment

    Hinge Adjustment Installation (cont.) Front of unit Carefully move unit until semi flush with cabinet Remove four side screws and remove unit top. Loosen the four hinge screws. Adjust door. Place unit within 3” (7.6 cm) of being flush with cabinets. (depending on unit).
  • Page 33: Kickplate Installation

    Hinge Adjustment Door Stop Adjustment (cont.) (Side-by-Side/All Refrigerator/All Freezer) 120˚ 110˚ Screw Wall 90˚ 2 x 4 Refrigerator Attach positive secure self-tapping bolts Open refrigerator door so door stop and Remove shoulder screw and place in 90˚ Lift unit off rollers to desired height to 2 x 4 using a 22”...
  • Page 34: Water Filter Installation

    Water Filter Installation (Side-by-Side with Dispenser) Water Filter System Specification and Performance Data Sheet This system has been tested according to NSF/ANSI 42/53 for reduction of the substances listed below. The concentration of the indicated substances in water entering the system was reduced to a concentration of less than or equal to the permissible limit for water leaving the system, as specified in NSF/ANSI 42/53.* (100% safety factors built- in for unmetered usage for health claims only.) NSF Specified...
  • Page 35: Final Installation

    Final Installation Performance Checklist Replace top air grille. Using an 8” magnetic nut driver, replace the two 1/4” screws. Replace the center grille louver. Open door. The display should flash. h Align/square door(s). h Verify cabinet size. h Verify drain pan is properly installed and h Verify electrical supply and water supply there are no leaks on water connection.
  • Page 36: Control Panels

    Verify Operations Verify Operations Control Panels Control Panels All Refrigerator Bottom-Mount FREEZER REFRIGERATOR FREEZER REFRIGERATOR MAX FRZ MAX REF DOOR OPEN ACTIVATE FAST ALARM DISPLAY DOOR OPEN MAX FRZ MAX REF HIGHER LOWER ACTIVATE FAST ALARM DISPLAY CONTROLS TEMP TEMP FAST COOL POWER COOL...
  • Page 37: Service & Registration

    Service & Registration Notes ________________________________________________________________________________________________________________________________________________________ Only authorized replacement parts may be used in performing service on the appliance. DO NOT repair or replace any part of the appliance unless ________________________________________________________________________________________________________________________________________________________ specifically recommended in the manual. All other servicing should be referred to a qualified ________________________________________________________________________________________________________________________________________________________ technician.
