HS-JS790
D
SERVICE MANUAL
STEREO RADIO
BASIC TAPE MECHANISM : 6ZM–2 R3NF
CASSETTE RECORDER
MODEL CODE : 8ZHJ8-0134<S>
S/M Code No. 09-99B-418-5R2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-JS790 and is the answer not in the manual?

Questions and answers

Related Manuals for Aiwa HS-JS790

Summary of Contents for Aiwa HS-JS790

  • Page 1 HS-JS790 SERVICE MANUAL STEREO RADIO BASIC TAPE MECHANISM : 6ZM–2 R3NF CASSETTE RECORDER MODEL CODE : 8ZHJ8-0134<S> S/M Code No. 09-99B-418-5R2...

  • Page 2: Specifications

    SPECIFICATIONS...

  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-010-502-040 0E CAP ELECT GAS 100/4 87-A11-056-080 0E C-CAP,U 1-10 Z F 87-002-677-080 1E IC,TA2002F 87-A11-056-080 0E C-CAP,U 1-10 Z F 8Z-HJ8-610-010 2M C-IC,TC9327AF-501 87-010-503-040 0E CAP,E 220-4 GAS 87-A20-638-080 1A C-IC,PST9120 87-A10-025-080 0E C-CAP,U 0.22-16Z F...
  • Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C459 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM C105 87-A10-263-080 0E C-CAP,U 0.1-16ZF C460 87-A10-952-080 0E C-CAP,TN 22-4 M A MCM C106 87-A10-025-080 0E C-CAP,U 0.22-16Z F C461 87-012-286-080 0E CAP, U 0.01-25 C107 87-012-176-080 0E CAP 15P...

  • Page 5: Lcd Diagram

    LCD DIAGRAM CHIP RESISTOR PART CODE LCD, AIW4188 GRID ASSIGNMENT Chip Resistor Part Coding Figure Resistor Code Value of resistor Chip resistor Dimensions (mm) Wattage Type Tolerance Symbol Resistor Code Form 1/16W 1005 0.35 1/16W 1608 0.45 1/10W 2125 1.25 0.45 1/8W 3216...

  • Page 6: Wiring-1 (Main)

    WIRING-1 (MAIN)
  • Page 7 SCHEMATIC DIAGRAM–1 (MAIN)
  • Page 8 WIRING-2 (FRONT)
  • Page 10 SCHEMATIC DIAGRAM–2 (FRONT)

  • Page 11: Ic Block Diagram

    IC BLOCK DIAGRAM IC, PST9120 IC,TA2104BFN...
  • Page 12 IC,TK11823MTL IC, BA3641FV...
  • Page 13 IC, LB1977M...
  • Page 14 IC DESCRIPTION IC, TC9327AF-501...
  • Page 16 ADJUSTMENT MAIN C.B J001 TP1(VT) PHONES IC801 IFT201 L202 L203 TC201 VOLUME L201 (BAR ANT) SFR801 3015 /108.0MHz...

  • Page 17: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HJ8-005-010 1B WINDOW,LCD J 21 87-HRA-603-010 0E BAR-ANT,MW 2 8Z-HJ8-021-010 1B LID,CASS JS790 S 22 8Z-HJ8-203-010 0E HLDR,ANTENNA J...

  • Page 18: Tape Mechanism Exploded View

    TAPE MECHANISM EXPLODED VIEW 1 / 1 TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 86-ZM2-255-010 0E SPR-T,PIN BACK L 36 86-ZM2-222-410 0E LEVER,PIN UP R 2 86-ZM2-286-310 0E GUIDE,TAPE REC 37 86-ZM2-218-310 0E LEVER,HEAD UP...

  • Page 19: Accessories / Package List

    ACCESSORIES / PACKAGE LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 1 8Z-HJ8-901-010 -- IB,D 2 87-B30-251-010 2A HEADPHONE,HP-M042 (F) 3 84-447-019-310 0E CLIP,BELT 4 8Z-HJ8-951-010 -- RC UNIT, RC704 5 87-041-083-110 1H CM-S40A...
  • Page 20 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2-11, IKENOHATA 1-CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 9630469 0251431 Printed in Singapore...
