SERVICE MANUAL
STEREO RADIO CASSETTE
BASIC TAPE MECHANISM : 3ZM-1 R2N
RECORDER
• This Service Manual is the "Revision Publishing" and replaces "Simple Manual"
of HS-JS389 (YH,YJ,YHT), S/M Code No. 09-012-442-5T1.
S/M Code No. 09-013-442-5R1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HS-JS389 YH and is the answer not in the manual?

Questions and answers

Summary of Contents for Aiwa HS-JS389 YH

  • Page 1 HS-JS389 YH,YJ,YHT SERVICE MANUAL STEREO RADIO CASSETTE BASIC TAPE MECHANISM : 3ZM-1 R2N RECORDER • This Service Manual is the “Revision Publishing” and replaces “Simple Manual” of HS-JS389 (YH,YJ,YHT), S/M Code No. 09-012-442-5T1. S/M Code No. 09-013-442-5R1...
  • Page 2: Specifications

    Speaker: 250 mW (EIAJ/ 8 ohms) Headphones: 12 mW + 12 mW (EIAJ/ 32 ohms) Power source: Battery DC 3V, R6 (size AA) X 2 Domestic AC power (using optional AC adaptor: AIWA AC-620/AC-302) Speakers: Diameter 50 mm, 8 ohms Recording speed: Approx.
  • Page 3: Electrical Main Parts List

    ELECTRICAL MAIN PARTS LIST REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION C104 87-012-188-080 C-CAP,U 47P-50 J CH C105 87-012-271-080 C-CAP,U 560P-50 K B 87-001-943-080 IC,TA8155F C106 87-012-193-080 C-CAP,U 82P-50 J CH 87-017-370-080 IC,MM1038AFF C108 87-012-193-080 C-CAP,U 82P-50 J CH 87-A20-851-040 C-IC,TA2111F...
  • Page 4 REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 87-A50-691-010 COIL,47UH TROID C206 87-012-164-080 C-CAP,U 2P-50 CH L101 8B-HJ8-603-010 BAR-ANT,MW C207 87-A11-056-080 C-CAP,U 1-10 Z F L102 8B-HJ8-606-010 COIL,FMRF C208 87-A11-056-080 C-CAP,U 1-10 Z F L103 8B-HJ8-605-010 COIL,FMOSC C209 87-012-286-080...
  • Page 5: Transistor Illustration

    TRANSISTOR ILLUSTRATION REF. NO. PART NO. KANRI DESCRIPTION REF. NO. PART NO. KANRI DESCRIPTION 2SA1362GR DTC144EKA 2SC2712GR KTA1504GR 2SC2714O RN1410 2SC3326B RN2411 CSA1362GR – 5 –...
  • Page 6 WIRING – 1 (MAIN) <1 / 2> – 6 –...
  • Page 7 WIRING – 2 (MAIN) <2 / 2> – 7 –...
  • Page 8 SCHEMATIC DIAGRAM – 1 (MAIN) – 8 –...
  • Page 9 WIRING – 3 (FRONT) <1 / 2> – 9 –...
  • Page 10 WIRING – 4 (FRONT) <2 / 2> – 10 –...
  • Page 11 SCHEMATIC DIAGRAM – 2 (FRONT) – 11 –...
  • Page 12: Lcd Display

    LCD DISPLAY LCD, ASSY (BAND/TU) 17P – 12 –...
  • Page 13: Ic Block Diagram

    IC BLOCK DIAGRAM – 13 –...
  • Page 14 IC DESCRIPTION IC, LC72349G-9944 Pin No. Pin Name Description XOUT Crystal 75kHz oscillator pin. TEST2 Connected to ground. 3 ~ 4 PA3 ~ PA2 Key matrix input (Not used). 5 ~ 6 PA1 ~ PA0 Key matrix input. 7 ~10 PB3 ~PB0 Key return timing output.
  • Page 15 ADJUSTMENT <TAPE PLAYER SECTION> < TUNER SECTION > 1. Tape Speed (4.8cm/sec) Adjustment 1. AM VT Check Settings : • Test tape : TTA - 100 (TAPE CENTER) Settings : • Test point : TP1 (VT) • Test point : PHONES JACK (J2) Method : Set to AM 530 kHz and check that the test point is •...
  • Page 16: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW 1 / 1 – 16 – – 16 –...
  • Page 17: Mechanical Parts List

    MECHANICAL PARTS LIST 1 / 1 REF. NO. PART NO. KANRI DESCRIPTION 1 8B-HJ8-004-010 WINDOW,LCD 2 8B-HJ8-007-010 NET,MIC 3 8B-HJ8-202-010 HLDR,MIC 4 8B-HJ8-011-010 KNOB,SL HOLD 5 8B-HJ8-012-010 CAP, HOLD 6 8B-HJ8-009-010 BTN,FUNCTION 7 8B-HJ8-003-010 PANEL,SPEAKER 8 8B-HJ8-010-010 BTN,RESET 9 8B-HJ8-008-010 KEY,RADIO PRESET 10 8B-HJ8-203-010 HLDR,SPEAKER...
  • Page 18 TAPE MECHANISM EXPLODED VIEW 1 / 1 HEAD FLEX. C.B – 18 –...
  • Page 19: Tape Mechanism Parts List

    TAPE MECHANISM PARTS LIST 1 / 1 REF. NO. REF. NO. PART NO. KANRI DESCRIPTION PART NO. KANRI DESCRIPTION 1 83-ZM1-201-910 CHAS,MAIN 31 83-ZM1-216-410 LVR,LOCK 2 83-ZM1-272-110 LVR ASSY,EH 32 83-ZM1-214-410 LVR,DIR 3 83-ZM1-253-010 SPR-T,EH 33 83-ZM1-245-210 SPR-T,DIR 4 83-ZM1-242-010 SPR-T,PLAY 34 83-ZM1-268-010 LVR,REC AUTO...
  • Page 20 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2000068 9630472 0251431 Printed in Singapore...
  • Page 21 HS-JS389 YH,YJ,YHT SERVICE MANUAL STEREO RADIO CASSETTE RECORDER BASIC TAPE MECHANISM: 3ZM-1 • Replace this Service manual with “Revision Publishing” when it is issued. S/M Code No. 09-012-442-5T1...
  • Page 22 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 23 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 24 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 25 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 26 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 27 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 28 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 29 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 30 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 31 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 32 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 33 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 34 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 35 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 36 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 37 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 38 PARTS LIST = ! SAFTY PARTS = Components marked All components used on this model at the production line are shown in this service manual. However, please note that not all components will be available as spare parts for after-sales service. Components marked S and O are designated as spare parts for service and will be stocked at the spare parts centers.
  • Page 39 SCHEMATIC DIAGRAM – 1 (MAIN) – 19 –...
  • Page 40 SCHEMATIC DIAGRAM – 2 (FRONT) – 20 –...
  • Page 41 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110, JAPAN TEL:03 (3827) 3111 2000068 Printed in Singapore...
