Aiwa HS-JS555 Service Manual

ALIA =
SERVICE
HS-JS555 =
STEREO RADIO
CASSETTE RECORDER
3 = =
MA
SPECIFICATIONS
Frequency range Reception mode "EU"
AM 531-1,602 kHz (9 kHz steps)
FM1, FM2 87.5-108 MHz (50 kHz steps)
Reception mode "US"
AM 530-1,710 kHz (10kHz steps)
FM1, FM2 87.5-108.1 MHz (200 kHz steps)
Output 15 mW + 15 mW (EIAJ 16 Q)
Power supply DC 2.4V using two supplied rechargeable batteries
NB-3A
DC 3V using two Ré6 (size AA) batteries
AC house current using an optional AC adaptor AC-620
or AC-300
Battery life EIAJ 1 mW output playback
Using fully recharged rechargeable batteries (NB-3A)
3.5 hours
Using manganese (R6P) batteries 5 hours
Using alkaline batteries (LR6) 13 hours
EIAJ recording
Using fully recharged rechargeable batteries
(NB-3A) 2 hours
Using manganese (R6P) batteries 3 hours
Using alkaline batteries (LR6) 10 hours
Maximum dimensions (W x H x D)
119 x 88.2 x 37.8 mm (43/4 x 31/2 x 11/2 inches)
Weight Approx. 216g, 7.56 oz (including rechargeable batteries)
aa
Cc)
pared
—
re
a2
Cf)
@ Design and specifications are subject to change without notice.
@ Dolby noise reduction manutactured under license from Dolby
Laboratories Licensing Corporation.
@ "DOLBY" and the doubleD symbol Df are trademarks of Dolby
Laboratories Licensing Corporation.
S/M Code No. 09-963-129-50I
