Section 1 - Product Overview
ADSL Port
Use the ADSL cable to
connect to the your
telephone line (RJ-11 port)
Antenna
Reset Button
On the bottom of the
device，push it to reset
to factory confugration

Hardware Overview

Connections

Ethernet Port
Use the Ethernet port to connect
the Router to a computer or an
Ethernet LAN
USB Port
Use the USB port to
connect to the computer
Wireless ON/OFF Button
Push the button to on/off wireless
function
WPS Button
Push the button to on/off
WPS function
Power Button
Push in to power-on the
Router. Push again to power-
off the Router.
Power Insert
Use the adapter shipped with the
Router to connect to power
source.
