Linear AM-RGR Installation Instructions page 2

5. CONNECT AM-RGR TO AM/II
AM/II
READER IN
INDICATOR
WIRING
VIEWING
STRAIN
WINDOW
RELIEF
ROUTE WIRE THROUGH
STRAIN RELIEF BEFORE
USE CABLE FORMULA
WIRING TO TERMINALS
TO DETERMINE CABLE
(TIGHTEN LATER)
TYPE AND MAXIMUM
LENGTH
8. TRANSMITTER BUTTON DESIGNATIONS
REFER TO THE FOLLOWING BUTTON DESIGNATIONS
WHEN SETTING THE AM/II BUTTON SCHEDULE.
LEFT
BUTTON
TO SEND "TOP BUTTON"
RIGHT
SIGNAL, PRESS LEFT
BUTTON
AND BOTTOM-LEFT
BUTTONS TOGETHER.
BOTTOM-LEFT
TO SEND "BOTTOM-RIGHT"
BUTTON
SIGNAL, PRESS LEFT
AND RIGHT BUTTONS
TOGETHER.
GT-30
LEFT
BUTTON
RIGHT
BUTTON
BOTTOM-LEFT
BUTTON
GT-31
6. CLOSE CASE AND MOUNT UNIT
AM-RGR
TIGHTEN
AFTER
INSTALLATION
SLIDE BOARD INTO
3RD SLOT UP
AM/II
TERMINALS
ATTACH CASE TO
MOUNTING SURFACE
USE SCREW ANCHORS
AM-RGR
TERMINALS
OR APPROPRIATE HARDWARE
FOR MOUNTING
9. PROGRAM AND TEST SYSTEM
REFER TO THE AM/II PROGRAMMING
INSTRUCTIONS FOR DETAILS TO
PROGRAM RECEIVER
TEST TRANSMITTERS FROM VARIOUS
LOCATIONS TO DETERMINE RADIO RANGE
ADJUST THE INTERNAL RADIO RANGE
KNOB TO LIMIT RADIO RECEPTION
IF REQUIRED
RECEPTION PATTERN WILL VARY
DEPENDING ON ANTENNA USED
AND SUROUNDING STRUCTURES
NOTE: TRANSMITTER BLOOCK MUST
BE PROGRAMMED INTO CONTROLLER
BEFORE ACCESS CAN BE GRANTED
7. INSTALL ANTENNA
SECURE CASE
WITH FOUR
SCREWS AND
WASHERS
FOLLOW EXA ANTENNA
INSTRUCTIONS WHEN
CONSTRUCTING ANTENNA
This Linear product is warranted against defects in material and workmanship for twelve
(12) months. The Warranty Expiration Date is labeled on the product. This warranty
extends only to wholesale customers who buy direct from Linear or through Linear's
normal distribution channels. Linear does not warrant this product to consumers.
Consumers should inquire from their selling dealer as to the nature of the dealer's
warranty, if any. There are no obligations or liabilities on the part of Linear
Corporation for consequential damages arising out of or in connection with use
or performance of this product or other indirect damages with respect to loss of
property, revenue, or profit, or cost of removal, installation, or reinstallation. All
implied warranties, including implied warranties for merchantability and implied
warranties for fitness, are valid only until Warranty Expiration Date as labeled on the
product. This Linear Corporation Warranty is in lieu of all other warranties express
or implied.
Linear radio controls provide a reliable communications link and fill an important need
in portable wireless signalling. However, there are some limitations which must be
observed.
RADIO INDICATOR WILL
✶
FLICKER AS SIGNAL IS
For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part
15 devices. As such, they have limited transmitter power and therefore limited range.
RECEIVED
✶
A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio
signals that occur on or near their operating frequencies, regardless of code settings.
✶
Changes or modifications to the device may void FCC compliance.
STATUS INDICATOR WILL
✶
Infrequently used radio links should be tested regularly to protect against undetected interference or
LIGHT RED WHEN POWER
fault.
IS APPLIED AND GREEN WHEN
✶
A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale
ACCESS IS GRANTED
distributor or dealer, and these facts should be communicated to the ultimate users.
Copyright © 2000 Linear Corporation
CHOOSE AN ANTENNA TO FIT THE INSTALLATION REQUIREMENTS
OMNI-DIRECTIONAL
EXA-1000 ANTENNA
MOUNTED ON POLE
DIRECTIONAL
EXA-2000 ANTENNA
MOUNTED ON POST
LOCAL WHIP
ANTENNA
(SUPPLIED)
CONNECTED
DIRECTLY TO
RECEIVER
LINEAR LIMITED WARRANTY
All products returned for warranty service require a Return Product Authorization
Number (RPA#). Contact Linear Technical Services at 1-800-421-1587 for an
RPA# and other important details.
IMPORTANT !!!
SCREW CONNECTOR
ONTO RECEIVER
217229 A
