5. CONNECT WIRING
REFER TO THE AM/II INSTALLATION & PROGRAMMING
INSTRUCTIONS FOR DETAILS ON WIRING POWER, EARTH
GROUND, REMOTE DEVICES, ANTENNA, CONTROL INPUTS AND
RELAY OUTPUTS TO THE AM/II
RELAY OUTPUT
TO ACCESS
EARTH
DEVICE
GROUND
POWER INPUT
CONNECTION
TO TRANSFORMER
8. PROGRAM SYSTEM
INSTALLERS OF AE-1 SYSTEMS SHOULD
FAMILIARIZE THEMSELVES WITH THE
AM/II SYSTEM BY READING THE ENTIRE
AM/II INSTALLATION & PROGRAMMING
INSTRUCTIONS. PROGRAM AREAS
SPECIFIC TO THE AE-1 ARE AREAS 07 &
27. AREA 21 HAS TWO OPTIONS FOR THE
AE-1. PROGRAMMING WITH A PERSONAL
COMPUTER IS RECOMMENDED,
ESPECIALLY FOR ENTERING THE TENANT
NAMES.
AREA 21
RELAY SETUP
Which Relay to Program.
CH-A CH-B CH-C CH-D
Select Operation:
Control Shunt Alarm Obstacle CCTV
Select Timing Mode:
Time Pulse Toggle Latch
Enter Activation Time:
Time in seconds: 00000
Assign Time Zone [1]:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Assign Time Zone [2]:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Assign Time Zone [3]:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Assign Time Zone [4]:
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
Enter Channel Name
Assign Telephone Digit
None 1 2 3 4 5 6 7 8 9
Channel Control
Normal Activate LockOpen LockClosed
6. OPTIONAL MODEM INSTALLATION
CONNECT UNITS
WITH THE MODEL
USE LOWER
A2M MODEM CABLE
WIRING HOLE
IF MODEM IS
GOING TO BE
INSTALLED
CONNECT
INCOMING
TELEPHONE
LINE TO THE
MODEM'S
"LINE" JACK
TELEPHONE
LINE (USE
MODULAR
JACK OR
TERMINALS)
NOTE: SEPARATE PHONE LINES ARE
RECOMMENDED FOR THE MODEM AND AE-1.
ONE PHONE LINE CAN BE USED AS SHOWN
ALTHOUGH THE ENTRY SYSTEM IS
UNAVAILABLE WHILE MODEM IS ON-LINE.
9. ADJUST SPEAKER VOLUME & TESTING
AREA 07
1
TELEPHONE ENTRY NUMBERS
Enter Directory Code
Directory Code: 0000
Enter Tenant Name
Enter Telephone Number
Telephone#: ************
Extended Talk Time
Yes No
REMOVE
Delete Directory Entry
Directory Code: 0000
TEST JUMPER
AREA 27
TELEPHONE ENTRY SETUP
Directory Code Length
3
1 2 3 4
ADJUST THE
Directory Begins At
Beginning(A) Middle(M)
SPEAKER VOLUME
PBX Dialing Digit
AND DISPLAY
Off 9 8 7 6 5 4 3 2 1 0
CONTRAST TO SUIT
Set Talk Time
THE ENVRONMENT
Talk Time Seconds: 060
THE UNIT IS
Assign Postal Key Door
MOUNTED IN
CH-A CH-B CH-C CH-D
Sort Directory Names
Yes No
Edit Display Messages
Message Number: 00
Edit Display Message
5
Max Directory Entries
Maximum Entries: 00000
VERIFY THAT THE
PROPER RELAY
Delete All Tlph. Entries
Yes No
ACTIVATES AND
THAT THE ACCESS
Adjust Hybrid Level
Press OK To Start/Stop
DOOR STRIKE OR
GATE CONTROL
Display Briteness
Dim Low Med High
ACTIVATES
Priority Access ABCD
0 = No 1 = Yes 0000
ATTACH MODEM
WITH VELCRO ® STRIPS
CONNECT MODEM
TRANSFORMER
POWER CABLE
AND SLIDE MODEM
POWER SWITCH TO "1"
USE THE TELEPHONE CABLE
SUPPLIED WITH THE MODEM TO
CONNECT BETWEEN THE
MODEM'S "PHONE" JACK AND THE
AE-1 TELEPHONE LINE JACK
PRESS # TO VIEW
DIRECTORY AND
ENTER CODE TO
DIAL A TEST
PHONE NUMBER
4
HAVE TESTING
PARTY PRESS
ASSIGNED
TELEPHONE
DIGIT (DEFAULT
IS 9) TO GRANT
ACCESS
6
REPLACE THE TEST JUMPER,
LOCK THE CABINET AND
INSTRUCT FACILITY MANAGER
ON SYSTEM USE
7. OPTIONAL POSTAL LOCK INSTALLATION
1
BARRIER PLATE
BEND UP TABS ON
THE HOLE PLUG AND
REMOVE THE PLUG
3
LINEAR LIMITED WARRANTY
This Linear product is warranted against defects in material and workmanship for twelve
(12) months. The Warranty Expiration Date is labeled on the product. This warranty
extends only to wholesale customers who buy direct from Linear or through Linear's
2
normal distribution channels. Linear does not warrant this product to consumers.
Consumers should inquire from their selling dealer as to the nature of the dealer's
warranty, if any. There are no obligations or liabilities on the part of Linear
Corporation for consequential damages arising out of or in connection with use
or performance of this product or other indirect damages with respect to loss of
property, revenue, or profit, or cost of removal, installation, or reinstallation. All
implied warranties, including implied warranties for merchantability and implied
warranties for fitness, are valid only until Warranty Expiration Date as labeled on the
product. This Linear Corporation Warranty is in lieu of all other warranties express
or implied.
All products returned for warranty service require a Return Product Authorization
Number (RPA#). Contact Linear Technical Services at 1-800-421-1587 for an RPA# and
other important details.
Linear radio controls provide a reliable communications link and fill an important need
in portable wireless signaling. However, there are some limitations which must be
observed.
For U.S. installations only: The radios are required to comply with FCC Rules and Regulations as Part 15
devices. As such, they have limited transmitter power and therefore limited range.
A receiver cannot respond to more than one transmitted signal at a time and may be blocked by radio signals
that occur on or near their operating frequencies, regardless of code settings.
Changes or modifications to the device may void FCC compliance.
Infrequently used radio links should be tested regularly to protect against undetected interference or fault.
A general knowledge of radio and its vagaries should be gained prior to acting as a wholesale distributor or
dealer, and these facts should be communicated to the ultimate users.
Copyright © 1999 Linear Corporation
REMOVE THE TWO NUTS
AND THE POSTAL LOCK
BARRIER PLATE
2
INSTALL THE POSTAL
LOCK USING FOUR
10-32 NUTS
VERIFY THAT THE LOCK
STRIKE ACTIVATES THE
MICRO SWITCH
IMPORTANT !!!
213071 B
