INSTALLATION & MAINTENANCE MANUAL
Installation and service must be performed by a qualified service installer, service agency or the gas supplier.
IMPORTANT: THIS MANUAL CONTAINS INFORMATION REQUIRED FOR INSTALLATION, OPERATION AND
MAINTENANCE OF THIS EQUIPMENT. READ AND FOLLOW THE INFORMATION IN THIS MANUAL AND ALL
OTHER PROVIDED INSTRUCTIONS, LABELS AND MARKINGS BEFORE INSTALLING, OPERATING OR
SERVICING THIS UNIT.
FOR YOUR SAFETY
• Do not store or use gasoline or other flammable vapors or
liquids in the vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electric switch; do not use any phone in your
building.
• Immediately call your gas supplier from a neighbor's phone.
Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department
This product contains, or may come to contain materials identified
as carcinogenic, or possibly carcinogenic to humans.
installing, servicing or removing this product, read and follow the
supplied instructions.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause property damage,
personal injury, exposure to hazardous materials or loss of life. Refer to the information contained in this
manual.
A qualified installer, service agency or the gas supplier, who must read and follow the supplied
instructions before installing, servicing or removing this appliance, must perform installation and service. This
appliance contains, or may come to contain materials that have been identified as carcinogenic, or possibly
carcinogenic to humans.
WARNING: Do not use this appliance if any part has been under water. Immediately call a qualified service
technician to inspect the unit and to replace any part of the control system, any gas controls and any other items
affecting safe appliance operation and which has been under water. Failure to follow these instructions can
cause property damage, personal injury, exposure to hazardous materials or loss of life.
TO THE INSTALLER: After installation, these instructions must be given to the equipment user or left near the appliance.
SPECIAL INSTRUCTIONS TO THE OWNER:
important information that will help you in maintaining and operating this appliance.
EPV SERIES CONDENSING WATER BOILER
Riverside Hydronics
Before
Retain this manual for future reference. These instructions contain
®
, LLC - 990 Haltom Road - Fort Worth, Texas 76117 - Tel 1-800-990-5918
34-501 07/13
Advertisement
Table of Contents
Related Manuals for Riverside Hydronics EPV SERIES
Summary of Contents for Riverside Hydronics EPV SERIES
- Page 1 INSTALLATION & MAINTENANCE MANUAL EPV SERIES CONDENSING WATER BOILER Installation and service must be performed by a qualified service installer, service agency or the gas supplier. IMPORTANT: THIS MANUAL CONTAINS INFORMATION REQUIRED FOR INSTALLATION, OPERATION AND MAINTENANCE OF THIS EQUIPMENT. READ AND FOLLOW THE INFORMATION IN THIS MANUAL AND ALL OTHER PROVIDED INSTRUCTIONS, LABELS AND MARKINGS BEFORE INSTALLING, OPERATING OR SERVICING THIS UNIT.
-
Page 2: Table Of Contents
EPV SERIES CONDENSING WATER BOILER INTRODUCTION This manual covers installation, operation and maintenance on all Riverside Hydronics commercial boilers. Read all instructions thoroughly before attempting to start any unit. CONTENTS TOPIC PAGE General Safety Warnings and Codes Typical Construction Location and Installation... - Page 3 EPV SERIES CONDENSING WATER BOILER IMPORTANT SAFETY NOTE It takes only 5 seconds of skin contact with 140°F water to cause a second degree burn! You must protect against high water temperatures at all lavatories, tubs, showers and other points of hot water contact.
-
Page 4: Typical Construction
EPV SERIES CONDENSING WATER BOILER TYPICAL CONSTRUCTION 1. Boiler water return Handhole access 2. Boiler water supply Float LWCO (optional) 3. Blowdown Manual reset temperature limiting device 4. Condensate drain Operating control 5. I-beam skid Drip leg 6. Flue outlet Electronic LWCO control 7. -
Page 5: Location And Installation
EPV SERIES CONDENSING WATER BOILER CHECKING EQUIPMENT BEFORE YOU INSTALL Inspect the unit completely upon receipt from the freight carrier before signing the bill of lading. Inspect the appliance and all accompanying parts for signs of impact or mishandling. Verify the total number of pieces shown on packing slips with those actually received. -
Page 6: Clearances And Electrical Requirements
EPV SERIES CONDENSING WATER BOILER SERVICE CLEARANCES Allow sufficient space to provide adequate clearances on all sides for service and inspection. Recommended clearance is 24” at the top and front, 18” at left and right sides of the appliance. Optional equipment may increase the clearance requirements. -
Page 7: Venting Instructions
EPV SERIES CONDENSING WATER BOILER VENTING INSTRUCTIONS Vent this appliance in accordance with the latest edition of the National Fuel Gas Code and in accordance with the authority having jurisdiction. The EPV boiler is designed for operation with the 4", 5” or 6” positive pressure vent systems constructed of AL29-4C stainless steel. -
Page 8: Air Inlet Duct Option
When Ducting Vertically Through a Roof (Figure 501-4, Page 10) • The duct must terminate with the UL listed vent termination provided by Riverside Hydronics. When Ducting Horizontally Through a Wall (Figure 501-5, Page 10) •... -
Page 9: Vent Terminating
EPV SERIES CONDENSING WATER BOILER Typical Termination Locations for Vertical Vent Pipes Termination of less than 10 feet Figure 501-2 Termination of more than 10 feet Figure 501-3 34-501 07/13... - Page 10 EPV SERIES CONDENSING WATER BOILER Typical Locations for Vertical and Horizontal Vent Pipes Vertical Venting Figure 501-4 Horizontal Venting Figure 501-5 • Install flue outlet and fresh air inlet with adequate separation to prevent recirculation of combustion products. Although the National Fuel Gas Code provides minimum clearances, use sound engineering judgment, considering prevailing winds, obstructions and the type vent termination used, etc.
-
Page 11: Gas Burner Construction
EPV SERIES CONDENSING WATER BOILER CARBON MONOXIDE WARNING: An annual or seasonal combustion checkout must be performed by a qualified service agency to ensure safe operation. Failure to maintain proper combustion can result in injury or death. Typical Gas Burner Construction... -
Page 12: Start-Up Procedures
EPV SERIES CONDENSING WATER BOILER START-UP PROCEDURES WARNING: Start-up should only be performed by a qualified technician. CAUTION: Do not relight pilot or start burner with combustion chamber full of gas or oil vapor, or with very hot combustion chamber. - Page 13 EPV SERIES CONDENSING WATER BOILER 8. Check all connections within the control cabinet. A loose connection could cause intermittent shutdowns. 9. Some burners will use direct spark ignition. They may use a single gas pressure regulator and gas valve or multiple valves and regulators.
- Page 14 EPV SERIES CONDENSING WATER BOILER This section is for two-stage firing only: After adjusting the high fire manifold gas pressure, it is now important to check the operation of the first stage (low fire). There is a toggle switch on the control cabinet labeled “Auto/Low Fire”. Switch from the auto position to low fire and the main valve will de-energize shutting off the high fire gas supply and the air damper will close reducing the airflow to a minimum.
- Page 15 EPV SERIES CONDENSING WATER BOILER Record the following information for future use: Manifold gas pressure: " W.C. Vent pressure: " W.C. reading: % (5-7%) reading: % (8-9%) CO reading: ppm (less than 300 ppm) reading: Vent temperature: Gross °F. Less ambient °F.
-
Page 16: Maintenance
The makeup of the water, just as the blowdown, will vary with each application. Rely on the recommendation of the water consultant. SINCE RIVERSIDE HYDRONICS CANNOT CONTROL THE USE OF THE BOILER, WATER CONDITIONS OR MAINTENANCE, THE WARRANTY ON THE BOILER DOES NOT COVER POOR PERFORMANCE, STRUCTURAL FAILURE OR LEAKING DUE TO AN EXCESSIVE ACCUMULATION OF SCALE. - Page 17 EPV SERIES CONDENSING WATER BOILER MAINTENANCE (con't) The need to periodically check water level controls and waterside of the pressure vessel cannot be over emphasized. Most instances of major boiler damage are the result of operating with low water or the use of untreated (or incorrectly treated) water.
-
Page 18: Burner & Control Maintenance
EPV SERIES CONDENSING WATER BOILER BURNER AND CONTROL MAINTENANCE Remove the flame safeguard control from its base. Check the connections in control mounting base; loose connections can cause nuisance shutdowns. NOTE: Always secure gas lines and tag "Out of Service" before servicing burner nozzle or electrodes. - Page 19 EPV SERIES CONDENSING WATER BOILER MAINTENANCE & SAFETY INSPECTION REPORT THERMOST BURNER COMBUSTION TANK TANK FLUSH TANK FITTING VENT GAS TRAIN DATE INSPECTION ANALYSIS INSPECTION & CLEANOUT INSPECTION INSPECTION LEAK TEST INPSECTION Recommended YEARLY 6 MONTHS 6 MONTHS 3 MONTHS...
-
Page 20: Troubleshooting
EPV SERIES CONDENSING WATER BOILER TROUBLESHOOTING SUGGESTIONS GAS BURNER BURNER FAILS TO START: a) Defective on/off switch. Replace switch. b) Control circuit has open control contact. Check limits, low water cutoff, and others as applicable. c) Bad fuse or switch opens on incoming power source. Correct as required. - Page 21 EPV SERIES CONDENSING WATER BOILER 3. BURNER MOTOR RUNS, BUT PILOT DOES NOT LIGHT: a) Gas supply to burner shut off. Make sure all manual gas supply valves are open. Automatic high-pressure valve at meter such as "Sentry" type tripped shut due to high gas pressure. Reset valve and correct cause for trip out.
- Page 22 EPV SERIES CONDENSING WATER BOILER GAS HIGH FIRE INPUT CANNOT BE ACHIEVED: a) Gas Company pressure regulator or meter operating incorrectly, not allowing required gas pressure at burner train inlet. Contact Gas Company to correct. b) Gas cock upstream of train inlet not fully open. Check and correct.
