1/4" air HYDraULiC riveter

Set Up anD Operating inStrUCtiOnS

Diagrams within this manual may not be drawn proportionally.
Due to continuing improvements, actual product may differ slightly from the product described herein.
Distributed exclusively by Harbor Freight tools
visit our website at: http://www.harborfreight.com
read this material before using this product.
Failure to do so can result in serious injury.
Save tHiS ManUaL.
Copyright
2008 by Harbor Freight Tools
©
manual or any artwork contained herein may be reproduced in any shape or form
without the express written consent of Harbor Freight Tools.
For technical questions or replacement parts, please call 1-800-444-3353.
Model
3491 Mission Oaks Blvd., Camarillo, CA 93011
98898
. All rights reserved. No portion of this
®
.
®
Manual revised 08i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 98898 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Central Pneumatic 98898

Summary of Contents for Central Pneumatic 98898

  • Page 1: Set Up And Operating Instructions

    1/4” air HYDraULiC riveter Model 98898 Set Up anD Operating inStrUCtiOnS Diagrams within this manual may not be drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Distributed exclusively by Harbor Freight tools ®...

  • Page 2: Specifications

    DO nOt OverreaCH. Keep proper footing and balance at all times. Do not reach over or across running machines. 10. Maintain tOOLS witH Care. Keep tools clean for better and safer perfor- mance. Follow instructions for lubricating and changing accessories. Inspect hoses SKU 98898 For technical questions, please call 1-800-444-3353. Page 2...
  • Page 3 22. warning: The brass components of this product contain lead, a chemical known to the State of California to cause birth defects (or other reproductive harm). (Cali- fornia Health & Safety code § 25249.5, et seq.) rev 08h SKU 98898 For technical questions, please call 1-800-444-3353. Page 3...
  • Page 4 Nosepiece as the spring action in the Outer Cylinder (2) will cause the Nosepiece to “pop out”. (See Figure B.) note: Nosepieces are stored underneath the Base Cover (34). REV 08j SKU 98898 For technical questions, please call 1-800-444-3353. Page 4...

  • Page 5: Operation

    When finished using the Riveter, turn off the air compressor. Squeeze the Trigger (25) again to release any compressed air in the Riveter. Then, disconnect the air hose from the tool. REV 08j SKU 98898 For technical questions, please call 1-800-444-3353. Page 5...

  • Page 6: Inspection, Maintenance, And Cleaning

    Frame Head threads, while the front of the gauge should rest on the front edge of the Jaw Carrier (3). If it does not, have a qualified service technician re- pair the Riveter. (See Figure C.) SKU 98898 For technical questions, please call 1-800-444-3353. Page 6...
  • Page 7 Insert the Piston Assembly back into the Air Cylinder (19). See Figure D. Use the Spanner to firmly screw the Air Cylinder Lid (24) back onto the Air Cylinder (19). See Figure D. SKU 98898 For technical questions, please call 1-800-444-3353. Page 7...

  • Page 8: Troubleshooting

    NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACE- MENT PARTS THERETO. SKU 98898 For technical questions, please call 1-800-444-3353. Page 8...

  • Page 9: Parts List

    B09 Spring Pin Frame Valve Spring B10 O-Ring Lead Axis Copper Washer B11 O-Ring Plastic Ring Valve B12 O-Ring Restore Spring Spring B13 O-Ring Steel Ring B14 O-Ring REV 08l SKU 98898 For technical questions, please call 1-800-444-3353. Page 9...

  • Page 10: Parts List And Assembly Diagram

    LiSt anD aSSeMBLY DiagraM (36) (37) REV 08l SKU 98898 For technical questions, please call 1-800-444-3353. Page 10...
  • Page 11 This warranty gives you specific legal rights and you may also have other rights which vary from state to state. 3491 Mission Oaks Blvd. • PO Box 6009 • Camarillo, CA 93011 • (800) 444-3353 SKU 98898 For technical questions, please call 1-800-444-3353. Page 11...
