NetFPGA-1G-CML™ Board Reference Manual

PCI Express

Port Name IO Location
NET pcie-rx0_p LOC = H2;
NET pcie-tx0_p LOC = J4;
NET pcie-rx0_n LOC = H1;
NET pcie-tx0_n LOC = J3;
NET pcie-rx1_p LOC = K2;
NET pcie-tx1_p LOC = L4;
NET pcie-rx1_n LOC = K1;
NET pcie-tx1_n LOC = L3;
NET pcie-rx2_p LOC = M2;
NET pcie-tx2_p LOC = N4;
NET pcie-rx2_n LOC = M1;
NET pcie-tx2_n LOC = N3;
NET pcie-rx3_p LOC = P2;
NET pcie-tx3_p LOC = R4;
NET pcie-rx3_n LOC = P1;
NET pcie-tx3_n LOC = R3;
NET pcie-clk_p LOC = H6;
NET pcie-clk_n LOC = H5;
NET pcie-perstn LOC = L17
NET pcie-wake LOC = K18
NET pcie-prsnt LOC = AA7
Ethernet PHYS
Port Name
NET mdc
NET mdio
NET phy_rstn_1
NET phy_rstn_2
NET phy_rstn_3
NET phy_rstn_4
NET phy_intrn_1
NET phy_intrn_2
NET phy_intrn_3
NET phy_intrn_4
NET rgmii_rxd_1[0]
NET rgmii_rxd_1[1]
NET rgmii_rxd_1[2]
Copyright Digilent, Inc. All rights reserved.
Other product and company names mentioned may be trademarks of their respective owners.
IO Standard Type
IOSTANDARD = LVCMOS33
IOSTANDARD = LVCMOS33;
IOSTANDARD = LVCMOS18;
IO Location IO Standard Type
LOC = V13 IOSTANDARD = LVCMOS18;
LOC = W13 IOSTANDARD = LVCMOS18;
LOC = K21 IOSTANDARD = LVCMOS33;
LOC = L23 IOSTANDARD = LVCMOS33;
LOC = E25 IOSTANDARD = LVCMOS33;
LOC = D18 IOSTANDARD = LVCMOS33;
LOC = J8 IOSTANDARD = LVCMOS18
LOC = J14 IOSTANDARD = LVCMOS18
LOC = K15 IOSTANDARD = LVCMOS18
LOC = M16 IOSTANDARD = LVCMOS18
LOC = A14 IOSTANDARD = LVCMOS18;
LOC = B14 IOSTANDARD = LVCMOS18;
LOC = E12 IOSTANDARD = LVCMOS18;
PULLUP NODELAY;
PULLUP;
PULLUP;
PULLUP;
PULLUP;
