Heat&Glo 8000TR-OAK Owner's Manual

Installation and operation
Table of Contents

Advertisement

Quick Links

Para obtener un ejemplar en Español de este
Manual del propietario, visite www.heatnglo.com.
Models:
8000TR-OAK
8000TR-OAK-IPI
8000TRLP-OAKIPI
• Important operating
a n d m a i n t e n a n c e
instructions included.
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.

• What to do if you smell gas

- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
This appliance may be installed as an OEM installation in
manufactured home (USA only) or mobile home and must be
installed in accordance with the manufacturer's instructions
and the manufactured home construction and safety standard,
Title 24 CFR, Part 3280 or Standard for Installation in Mobile
Homes, CAN/CSA Z240MH, in Canada.
This appliance is only for use with the type(s) of gas indicated
on the rating plate.
Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09
NOTICE
DO NOT DISCARD THIS MANUAL
• Read, understand and follow
these instructions for safe

installation and operation.

Pour demander un exemplaire en français de ce Manuel
du propriétaire, visitez www.heatnglo.com.
Owner's Manual
Installation and Operation
• Leave this manual with
party responsible for use
and operation.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down.
Hot glass will cause burns.
• DO NOT touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
fi replace.
• Alert children and adults to hazards of high temperatures.
High temperatures may ignite clothing or other fl ammable
materials.
• Keep clothing, furniture, draperies and other fl ammable
materials away.
This appliance has been supplied with an integral barrier
to prevent direct contact with the fi xed glass panel. DO
NOT operate the appliance with the barrier removed.
Contact your dealer or Hearth & Home Technologies if the
barrier is not present or help is needed to properly install one.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
Installation and service of this appliance should be
performed by qualifi ed personnel. Hearth & Home
Technologies suggests NFI certifi ed or factory trained
professionals, or technicians supervised by an NFI
certifi ed professional.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 8000TR-OAK and is the answer not in the manual?

Questions and answers

Summary of Contents for Heat&Glo 8000TR-OAK

  • Page 1: Installation And Operation

    Technologies suggests NFI certifi ed or factory trained This appliance is only for use with the type(s) of gas indicated professionals, or technicians supervised by an NFI on the rating plate. certifi ed professional. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 2: Congratulations

    Serial Number IN CANADA Model: XXXXXXXX ALTITUDE: 0-0000 FT. 0000-0000FT. (Modele): MAX. INPUT BTUH: 00,000 00,000 MIN. INPUT BTUH: 00,000 00,000 Serial XXXXXXXX ORIFICE SIZE: #XXXXX #XXXXX (Serie): Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 3: Table Of Contents

    D. Mantel and Wall Projections ..... . . 21 6 Termination Locations A. Vent Termination Minimum Clearances ....22 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 4 D. Contact Information ......69 = Contains updated information. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 5: Limited Lifetime Warranty

    B. Limited Lifetime Warranty Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 6 B. Limited Lifetime Warranty (continued) Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 7: Listing And Code Approvals

    • A 110-120 VAC circuit for this product must be pro- tected with ground-fault circuit-interrupter protection, in compliance with the applicable electrical codes, when it is installed in locations such as in bathrooms or near sinks. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 8: Requirements For The Commonwealth Of Massachusetts

    VENT DIRECTLY BELOW. KEEP CLEAR OF ALL OB- of the installation. STRUCTIONS”. See Gas Connection section for additional Common- wealth of Massachusetts requirements. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 9: User Guide

    DECORATIVE DOORS (NOT SHOWN) SECTION 2.E. FIXED GLASS ASSEMBLY (NOT SHOWN) SECTION 14.H. MANTEL FAN KIT SECTION 2.C HEARTH CLEAR SPACE SECTION 2.D. Figure 2.1 General Operating Parts Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 10: Fan Kit (Optional)

    For more information refer to the instructions supplied with your decorative door or front. Figure 2.3 Ignitor Button Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 11: Lighting Instructions (Ipi)

    For additional information on operating your Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. Final inspection by Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 12: Lighting Instructions (Standing Pilot)

    Hearth & Home Technologies fi replace, please refer to www.fi replaces.com. 4. Push in gas control knob slightly and turn clock- to OFF”. DO NOT force. wise 5. Close control access panel. Final inspection by 464-903H Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 13: After Fireplace Is Lit

    Some optional control systems available with IPI models may allow pilot fl ame to continually? remain lit. In a standing pilot system the pilot will always stay on. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 14: Maintenance And Service

    • Carefully set fi xed glass assembly in place on fi replace. Hold glass in place with one hand and secure glass latches with the other hand. • Reinstall door or decorative front. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 15: Maintenance Tasks-Qualifi Ed Service Technician

    • Verify that there is not a short in fl ame sense circuit by or perforation. Sand and repaint as necessary. checking continuity between pilot hood and fl ame sense rod. Replace pilot as necessary (IPI only). Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 16 (Either cobrahead or SIT) Figure 3.1 IPI Pilot Flame Patterns Figure 3.2 Standing Pilot Flame Patterns Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 17: Installer Guide

    FRAMING HEADED OFF IN CEILING JOISTS (SECTION 8.C) OPTIONAL WALL SWITCH MANTEL AND MANTEL LEG (SECTION 5.D) SURROUND HEARTH EXTENSION GAS LINE (SECTION 11) Figure 4.1 Typical System Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 18: Design And Installation Considerations

    Reciprocating saw Manometer Flat blade screwdriver Non-corrosive leak check solution 1/2 - 3/4 in. length, #6 or #8 Self-drilling screws One 1/4 in. female connection (for optional fan). Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 19: Framing And Clearances

    REAR VENT HORIZONTAL TERMINATION, ONE ELBOW TWO ELBOWS REAR VENT NO ELBOWS Inches 55-7/8 61-1/2 38-7/8 3-3/8 19-3/4 Millimeters 1419 1245 2007 1562 2210 Figure 5.1 Appliance Locations Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 20: Constructing The Appliance Chase

    Appliance Appliance Appliance (Vent Pipe) (Height) (Depth) (Width) 40-1/2 Inches 1029 1245 * Adjust framing dimensions for interior sheathing (such as sheetrock) Figure 5.2 Clearances to Combustibles Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 21: Mantel And Wall Projections

    Figure 5.4 Combustible Mantel Leg or Wall Projections (Acceptable on both sides of opening) 9 10 TOP OF HOOD Figure 5.3 Minimum Vertical and Maximum Horizontal Dimensions of Combustibles Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 22: Termination Locations

    Over 18/12 to 20/12 ..........7.5 Over 20/12 to 21/12 ..........8.0 * 3 foot minimum in snow regions Figure 6.1 Minimum Height From Roof To Lowest Discharge Opening Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 23: Heat & Glo • 8000Tr-Oak, 8000Tr-Oak-Ipi, 8000Trlp-Oakipi • 2057-900 Rev. Q

    Figure 6.3 Minimum Clearances for Termination CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS SUGGESTED THAT A VINYL PROTECTOR KIT BE INSTALLED. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 24: Vent Information And Diagrams

    DVP12A 3 to 12 76 to 305 DVP12MI 3 to 12 76 to 305 DVP24MI 3 to 24 76 to 610 Figure 7.2 DVP Pipe Effective Length Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 25: Vent Diagrams

    10 ft. 3.1 m 3 ft. 914 mm 15 ft. 4.6 m = 50 ft. (15.2 m) Maximum = 17 ft. (5.2 m) Maximum Figure 7.4 INSTALLED HORIZONTALLY Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 26 305 mm 5 ft. 1.5 m 3 ft. 914 mm 20 ft. 6.1 m = 20 ft. (6.1 m) Maximum = 50 ft. (15.2 m) Maximum Figure 7.5 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 27 2. Break the Flue Restrictor into two pieces. Do this by 5. Reinstall the Exhaust Shield. bending the part back and forth until it breaks (see Figure 7.8). Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 28 4 ft 1.2 m 17 ft 5.2 m 17 ft 5.2 m = 17 ft (5.2 m) Maximum = 50 ft (15.2 m) Maximum INSTALLED HORIZONTALLY Figure 7.12 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 29: Rear Vent - Horizontal Termination

    This model is tested and approved to use 45º elbows in corner installations. However, 90º elbows will result in better performance. Note: LP units cannot be used with a 45º elbow. A 90º elbow must be used. Figure 7.14 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 30 4-1/2 ft 1.4 m 9 ft 2.7 m 17 ft 5.2 m INSTALLED HORIZONTALLY = 50 ft (15.2 m) Maximum = 8 ft (2.4 m) Maximum Figure 7.16 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 31 610 mm 4 ft 1.2 m 3 ft 914 mm 5 ft 1.5 m 3-1/2 ft 1.0 m = 50 ft (15.2 m) Maximum INSTALLED HORIZONTALLY Figure 7.18 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 32 16 ft 4.9 m 8 ft 2.4 m 4-1/2 ft 1.4 m 12 ft 3.6 m 20 ft 6.1 m = 50 ft (15.2 m) Maximum Figure 7.19 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 33: Vent Clearances And Framing

    3 to 4 inches between the pipe and shield. • Heat shield not required if distance is more than 4 inches. SCREW 3 in. (76 mm) Figure 8.4 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 34: Wall Penetration Framing

    Whenever a non-combustible wall is penetrated, the wall shield fi restop is only required on one side and no heat shield is necessary. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 35: Install The Ceiling Firestop

    BEFORE OR AFTER INSTALLATION OF VENT SYSTEM 3 FASTENERS PER SIDE CEILING FIRESTOP CEILING FIRESTOP INSTALLED BELOW CEILING INSTALLED ABOVE CEILING Figure 8.8 Installing the Attic Shield Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 36: Install Attic Insulation Shield

    • Bend all tabs inward 90º around the top of the shield. These tabs must be used to prevent blown insulation from getting between the shield and vent pipe, and to maintain air space clearance. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 37: Appliance Preparation

    Figure 9.2 Remove the center insulation plug. Proceed to Section 10. Figure 9.3 Cut the metal retaining band and fold the sides out. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 38: Rear Vent

    Slide the insulation gasket onto the vent section, up against the appliance and over the tabs. Figure 9.8 Fold the center parts of the retaining band out and use to remove the seal cap. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 39: Securing And Leveling The Appliance

    • Secure the appliance to the fl oor by inserting two screws through the pilot holes at the bottom of the appliance. NAILING TABS (BOTH SIDES) Figure 9.11 Proper positioning, leveling and securing of an appliance Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 40: Completing Grate Set-Up

    REMOVE GRATE BRACKET REMOVE TAB HOLDING DOWN Figure 9.14 BASE REFRACTORY (4 PLACES) Figure 9.12 Removing Grate RE-INSTALL INTO THE UNIT Figure 9.13 Re-install grate in unit Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 41: Installing Vent Pipe

    fl ue at the horizontal elbow joint to prevent the elbow from rotating. Use screws no longer than 1/2 in. (13 mm). If predrilling screw holes, DO NOT penetrate inner pipe. INCORRECT Figure 10.4 Seams Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 42: Assemble Slip Sections

    NOTICE: If slip section is too long, the inner and outer fl ues of the slip section can be cut to the desired length. Figure 10.8 Securing Horizontal Pipe Sections Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 43: Disassemble Vent Sections

    Figure 10.10. • Pull carefully to separate the pieces of pipe. Figure 10.9 Rotate Seams for Disassembly Figure 10.10 Align and Disassemble Vent Sections Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 44: Install Metal Roof Flashing

    • Caulk the perimeter of the fl ashing where it contacts the roof surface. See Figure 10.12. Figure 10.14 Assembling the Storm Collar Around the Pipe Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 45: Install Vertical Termination Cap

    • Rest the small leg on the extended heat shield on top of the pipe section to properly space it from the pipe section. Important Notice: Heat shields may not be fi eld constructed. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 46: Install Horizontal Termination Cap

    DVP-TRAP1 can adjust 1-1/2 in. (3-1/8 to 4-5/8) DVP-TRAP2 can adjust 4 in. (5-3/8 to 9-3/8) DVP-HPC1 can adjust 2-1/8 in. (4-1/4 to 6-3/8) DVP-HPC2 can adjust 4-1/8 in. (6-3/8 to 10-1/2) Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 47: Gas Information

    fl exible gas connector are connected to the 1/2 in. (13 mm) control valve inlet. • If substituting for these components, please consult local codes for compliance. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 48: Electrical Information

    Wiring for optional Hearth & Home Technologies approved accessories should be done now to avoid reconstruction. Follow instructions that come with those accessories. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 49: Electrical Service And Repair

    Verify proper operation after servicing. STANDING PILOT REMOTE SWITCH PIGTAIL ON/OFF VALVE SWITCH OPTIONAL WALL SWITCH, THERMOSTAT OR REMOTE Figure 12.3 Standing Pilot Ignition Wiring Diagram Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 50: Junction Box Installation

    Figure 12.5 Junction Box Wired to Wall Switch or BC10 (1/4 in. male) as shown. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 51: Finishing

    3-1/2 in. MIN. 3 ft. MAX. Note: Clearance from fi replace opening to perpendicular wall. Figure 13.2 Combustible Mantel Leg or Wall Projections (Acceptable on both sides of opening) Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 52: Appliance Setup

    Use this material to give the appliance a realistic ash bed. • Save the remaining ember materials for use during appliance servicing. The embers provided should be enough for 3 to 5 applications. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 53: Install The Log Assembly

    B is located at the back/right corner of burner. NOTE: There should be a 1/2 inch gap between the bottom of log 3 and the top edge of the burner. The underside of log #3 must not cover ANY burner ports. 2057-935C Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 54 6 should rest on the grate bar, centered between tine 4 and 5. NOTE: The front faces (C) of log 6 and 2 should be on the same plane. This is key in avoiding fl ame impingement. NOTE: Finished top view. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 55: Fixed Glass Assembly

    • Install optional trim kits and/or surrounds using the instructions included with the accessory. • Use non-combustible materials to cover the gap between the sheet rock and the appliance (when applicable to the model). Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 56: Troubleshooting

    Take a reading at the thermopile leads. The reading should be 350 millivolts minimum. Replace the thermopile if the read- ing is below the minimum. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 57 Ensure that the glass is tightened properly on the unit, particularly on top corners. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 58: Intellifi Re Ignition System

    Verify module is securely grounded to metal chassis of appliance. D. Module voltage output / Valve/Pilot Verify battery voltage is at least 2.7 volts. Replace batteries if volt- solenoid ohms readings. age is below 2.7. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 59 ON position. If there is no spark at “I” terminal module must be replaced. If there is a spark at “I” terminal, module is fi ne. Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 60: Reference Materials

    Millimeters Location Inches Millimeters 35-1/2 1091 17-3/4 1221 21-1/2 11-5/8 1-1/8 38-3/4 1019 2-1/4 9-1/8 5-1/4 2-1/4 28-7/8 33-7/8 44-1/4 1124 23-1/2 39-1/4 Figure 16.1 Appliance Dimensions Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 61: Vent Components Diagrams

    14 in. (356 mm) 5 in. 12 in. (127 mm) (305 mm) 6 in. (152 mm) DVP-HVS (Vent Support) DVP-WS (Wall Shield Firestop) Figure 16.2 DVP vent components Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 62 117 mm Length DVP-TRAP 5-3/8 in. 9-3/8 in. Trap2 Horizontal Termination Cap 137 mm 238 mm DVP-TRAP2 DVP-TRAP1 DVP-TRAPK2 DVP-TRAPK1 DVP-HPC2 DVP-HPC1 Figure 16.3 DVP vent components Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 63 13-7/8 in. 9-1/2 in. 26 in. (352 mm) (241 mm) 660 mm 14 in. (356 mm) DVP-HSM-B Extended Heat Shield DRC-RADIUS Figure 16.4 DVP vent components Cap Shield Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 64 (314 mm) 8-3/4 in. (222 mm) PVK-80 (For use with IPI and DSI appliances only.) 1-5/8 in. (41 mm) DVP-HPC High Performance Cap Figure 16.5 DVP vent components Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
  • Page 65: Service Parts

    6748942, 6769426, 6774802, 6796302, 6840261, 6848441, 6863064, 6866205, 6869278, 6875012, 6880275, 6908039, 6919884, D320652, D445174, D462436; (Canada) 1297749, 2195264, 2225408, 2313972; (Australia) 780250, 780403, 1418504 or other U.S. and foreign patents pending. Printed in U.S.A. - Copyright 2009 Heat & Glo • 8000TR-OAK, 8000TR-OAK-IPI, 8000TRLP-OAKIPI • 2057-900 Rev. Q • 6/09...
