TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT : AE2MI40AH
DC INVERTER MULTI-SYSTEM AIR CONDITIONER
Capacity
AE2MI40AH
AE4MI80AH
RoHS
This product does not contain any hazardous substances prohibited by the RoHS Directive.
•
WARNING
• You are requested to use RoHS compliant parts for maintenance or repair.
• You are requested to use lead-free solder.
AE2MI56AHB
AE3MI68AH
AE4MI80AH
Outdoor Model No.
4.0kW
AE2MI40AH
5.6kW
AE2MI56AHB
6.8kW
AE3MI68AH
8.0kW
AE4MI80AH
F-GAS REGULATION (EC) No 842 / 2006
Do not vent R410A into atmosphere : R410A is a fluorinated greenhouse gas,
covered by Kyoto Protocol, with a Global Warming Potential (GWP) = 1975.
Product Code No.
3 870 310 85
(1 852 349 45)
3 870 310 86
(1 852 349 46)
3 870 310 87
(1 852 349 47)
3 870 310 88
(1 852 349 48)
AE2MI56AHB
AE3MI68AH
< Applicable Indoor Units >
Wall mounted type
AWMI22AHL
AWMI27AHL
AWMI35AHL
AWI52AHL
AWI68AHL
NOTE
For details about the combination, refer to
"Unit Combination Table" in the Appendix of
this manual.
REFERENCE NO.
FILE NO.
Destination: Europe
SM
700738
