Deutscher XE560 Owner's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
www.deutschermowers.com.au
DEUTSCHER MOWERS
DEUTSCHER
XE560
OWNER'S MANUAL

Advertisement

loading
Need help?

Need help?

Do you have a question about the XE560 and is the answer not in the manual?

Questions and answers

Related Manuals for Deutscher XE560

Summary of Contents for Deutscher XE560

  • Page 1 DEUTSCHER MOWERS DEUTSCHER XE560 OWNER’S MANUAL...
  • Page 2 INDEX Initial Assembly Safety Instructions Maintenance & Storage Specifications & Controls Mowing & Transporting Maintenance Mower Decals 11-15 Exploded Views & Parts Lists Warranty INITIAL ASSEMBLY Tools Required: Two 13mm open-ended spanners) 1. Remove the mower from the packaging and visually check for damage. 2.

  • Page 3: Safety Instructions

    SAFETY INSTRUCTIONS 1. Know your controls. Read the owners manuals thoroughly. Learn how to stop the engine quickly in an emergency. 2. Inspect the area to be mown, remove all debris and obstacles that may be in the path of the mower. Do not attempt to shift obstacles while engine is running.
  • Page 4 SAFETY INSTRUCTIONS 21. SLOPES • Do not mow excessively steep slopes. • Exercise extreme caution when on slopes. • Mow across the face of slopes, never up and down and exercise extreme caution when changing direction on slopes. • Never leave the mower unattended on a slope. 22.

  • Page 5: Specifications & Controls

    SPECIFICATIONS & CONTROLS SPECIFICATIONS MODEL No: 36214 XE560 with 850 series Briggs and Stratton engine. 36215 XE560 with a GSV190 Honda engine. Consult engine owners manual for engine specifications. TRANSAXLE: High and Low gear plus a differential is incorporated in the transaxle. A clutch lever to engage and disengage the drive belt is positioned on the right hand handle.

  • Page 6: Starting And Stopping

    MOWING AND TRANSPORTING PRE-START CHECK: Ensure engine oil is at the correct level before starting. See engine manual for instructions. Your Deutscher Mower comes to you with the transmission filled with oil. • Use fresh unleaded petrol. Do not mix oil with petrol.

  • Page 7: Mowing On Slopes

    The XE560 mower will fit in the back of a family sized station wagon, with the handle folded down. Never attempt to lift the mower on your own, and always secure the mower from moving once it is in place.
  • Page 8 MAINTENANCE Frequency Part Task 8 hrs 20 hrs 100 hrs Engine Refer to Engine Manual Transaxle Check oil level Cutter spindle Check sealed bearings King pins Raise & lower frame slides Grease Blades and drive belts Check, replace if necessary Clutch control linkages Height control linkages Throttle cable...
  • Page 9 • From behind the mower, roll the drive belt off the engine pulley. Then withdraw the belt from the front pulleys. • Replace the belt with a new belt (Deutscher part No. 1579), and ensure the belt is inside the guide pins.

  • Page 10: Mower Decals

    MOWER DECALS 3346 3349 3348 HIGH NEUTRAL 3351 3347 THROTTLE DRIVE DEUTSCHER XE560 STOP Raise lever to drive TWO SPEED forward. Release to Read operating dis-engage. instructions before use. FAST 3352 3350...
  • Page 11 EXPLODED VIEWS AND PARTS LISTS XE560 CHASSIS AND COMPONENTS Item No Part No Part Description ( Qty ) Item No Part No Part Description ( Qty ) 1017 Bolt M8 x 20 1854 Connecting rod, deck lift 1018 Spring washer 8mm...
  • Page 12 EXPLODED VIEWS AND PARTS LISTS XE560 DECK and COMPONENTS Item No Part No Part Description ( Qty ) Item No Part No Part Description ( Qty ) 1,3,4,7 H650 Blade, nut, bolt, washer x 2 set 2092 Blade brake disc (4)
  • Page 13 EXPLODED VIEWS AND PARTS LISTS XE560 HANDLE & CONTROLS Item No Part No. Part Description Item No Part No. Part Description 3261 Handle assembly 1584 Throttle control 1017 Bolt M8 x 20 1153 Screw, self threading 1072 M8 plain nut...
  • Page 14 EXPLODED VIEWS AND PARTS LISTS XE560 GEARBOX COMPONENTS 16 17 18 25 26 27...
  • Page 15 EXPLODED VIEWS AND PARTS LISTS XE560 GEARBOX COMPONENTS Item No. Part No. Part Description Item No. Part No. Part Description 3260 Gearbox complete 1637 Washer 1680 Gear selector arm 1663 Screw 1691 Selector tappet 1659 Seal, axle 7/8”x1,3/8”x1/4” 1690 O- Ring...

  • Page 16: Warranty

    • DEUTSCHER MOWERS PTY. LTD. will repair or replace, free of charge, any mower or part of a mower that is defective in materials or workmanship (or both) for a period of 24 months from the date of purchase. If parts or units are replaced, the replacement period will be no longer than 3 months.
