IT- 8000 Series Installation Guide
----------------------------------------------------- ----------------------------------------------------------------------------------------
A.
Attaching the Armrests
A1.
Remove the main body of the massage chair from its packaging.
Locate the two armrests and remove all plastic covering.
Armrest
A2.
Locate the three holes (circled in red in the picture) at the base of the left armrest, attached to
the chair.
A3.
Look in the carton to locate the three identical screws depicted here:
(top view)
A4.
Fit the three screws mentioned in step A3 into the three holes mentioned in step A2.
MASSAGE CHAIR ASSEMBLY
Main body
(side view)
* Although there is a hole, please
disregard the one circled in black.
(inverse view)
USJ-9000
Advertisement
Table of Contents
Related Manuals for Infinity IT- 8000 Series
Summary of Contents for Infinity IT- 8000 Series
- Page 1 USJ-9000 IT- 8000 Series Installation Guide ----------------------------------------------------- ---------------------------------------------------------------------------------------- MASSAGE CHAIR ASSEMBLY Attaching the Armrests Remove the main body of the massage chair from its packaging. Locate the two armrests and remove all plastic covering. Armrest Main body Locate the three holes (circled in red in the picture) at the base of the left armrest, attached to the chair.
- Page 2 USJ-9000 IT- 8000 Series Installation Guide --------------------------------------------------------------------------------------------------------------------------------------------- Locate the three bolts already partially inserted along the top of the left armrest. Align these three bolts to the three holes on the base of the left armrest. Tighten these screws, working from the back first, then progressing up to the front.
- Page 3 USJ-9000 IT - 8000 Series Installation Guide --------------------------------------------------------------------------------------------------------------------------------------------- Upon completing of assembling the left armrest, repeat the same process to assemble the right armrest. Base of Left Armrest Left Armrest B. Assembling the Legrest B1. Locate the Legrest and remove it from its packing box. Open the Legrest. Legrest Position the Legrest in front of the main body of the massage chair.
- Page 4 USJ-9000 IT - 8000 Series Installation Guide --------------------------------------------------------------------------------------------------------------------------------------------- On the top of each legrest, insert a screw into the hole to fasten that legrest to the body of the massage chair. Repeat this procedure for the other leg rest. Place the other parts of the massage chair (seat cushion, back cushion, head cushion, etc.) onto the main body of the chair.
- Page 5 USJ-9000 IT - 8000 Series Installation Guide --------------------------------------------------------------------------------------------------------------------------------------------- Locate the connection slots for the speakers, near the top of the backrest, on both sides. RED: Connection for speakers GREEN: Connection for wire Locate the wiring extending from each speaker. Connect each speaker into the corresponding connection slots on the right and left sides of the backrest.
- Page 6 USJ-9000 IT - 8000 Series Installation Guide --------------------------------------------------------------------------------------------------------------------------------------------- Fasten a plastic cover onto each speaker. Assemble the controller and its stand. Insert the power plug into a power outlet. Turn on the power switch. Your massage chair is ready for use.
