Infinity Aura Pro User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IT-9810
User Manual
MASSAGE CHAIR

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aura Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Infinity Aura Pro

Summary of Contents for Infinity Aura Pro

  • Page 1 IT-9810 User Manual MASSAGE CHAIR...
  • Page 2 SCAN CODE @infinitymassagechairs @infinity_chairs @infinitymassagechairs We know you can’t wait to sit in your new Infinity Massage chair! Take a picture of you enjoying the ultimate massage experience and make sure to tag us on social media with the hashtag #infinitymassagechairs...

  • Page 3: Table Of Contents

    Table of Contents Your Chair Move Methods Grounding instructions Taking Control Function Description 9-12 Footrest Extention Staying Safe 14-16 Fixing Issues 17-18 Troubleshooting and Safety Product Specifications...

  • Page 4: Your Chair

    Your Chair External Structure Front View Pillow Back Pad Seat Armrest Air Footrest Side View Back Cover Caster...
  • Page 5 Prior to assembly, carefully unpack all box contents. Check box contents to the detail below. Make sure all contents are accounted for. If anything is missing, please contact INFINITY at 603-910-5000. Do not return to the place of purchase. Box 1: Chair Body &...
  • Page 6 Your Chair External Structure Step 2 : Setting up the Massage Chair · Remove the chair from carton box. · 2 or more persons are needed to lift up the chair, according to the holding areas shown in the diagram below. Hold Place Hold Place (Each side of the armrest)
  • Page 7 Your Chair External Structure Step 3 : Setting up the Massage Chair · When the massage chair is removed from the carton box, raise the backrest. · Raise the backrest to approx. 120 , until a “CLICK” Sound is heard, to fix the backrest into position ·...
  • Page 8 Your Chair External Structure Step 5: Set Up Completed · Connect the cords and turn on the power, then you are ready to experience a relaxed and healthy massage. ※If the chair does not response after plugging in the power cord, please make sure the power switch is on , located at the left rear bottom of the chair.

  • Page 9: Move Methods

    Move Methods Step 1 · Step on the caster, and handle the chair with two hands on top of the Backrest. Step 2 · Tilt the chair backwards so that it is resting on the two caster wheels, and then push the chair forward. Please handle with care when putting the chair back onto the floor, dropping the chair could cause damage.

  • Page 10: Grounding Instructions

    Grounding instructions This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.

  • Page 11: Taking Control

    Taking Control Remote Control Layout Pause Press the button to stop operation (Motor and Pump, Air bag); for you to leave your seat temporarily. Color Display Screen Time Press the button to set timer from 5 to 30 Power (Start / Stop) minutes.

  • Page 12: Function Description

    Function Description Basic Function Power (Start / Stop) Press this button to turn on/off the chair. The LCD screen shows “ 15 ” with six flashing lights when activated.Press the button during operation will deactivate the chair and the POWER chair will return to upright position.
  • Page 13 Function Description Auto Programs The chair features 3 built-in Auto Programs, while using the auto program the chip will switch automatically and activate combinations of massage functions. Auto Program: HEALTH CARE / WELL BEING/ RELAX Press the button to turn on/off the Auto Program. The chair activates shoulder detection to locate the acupuncture of the users.
  • Page 14 Function Description Back Massage KNEADING Press the button to turn on/off the function. KNEADING Press “ZONE” button to massage selected areas. Timer is adjustable from 5 min to 30 min. SHIATSU Press the button to turn on/off the function. SHIATSU Press “ZONE”...
  • Page 15 Function Description Massage Function Adjustment ZONE Press UP/DOWN button can choose “Shoulder”, “Back”, “Waist”, “Point”, “Partial” “Full”. Press “UP”, selection order is anticlockwise: Shoulder → Back → Waist → Point → Partial → Full。 Press “DOWN”, selection order is clockwise: Full →...

  • Page 16: Footrest Extention

    Footrest Extention INSTRUCTION 1. Apply gentle pressure to the footrest for a maximum of 4 in of flexibility. Users can adjust according to individual height for best effect. 2. DO NOT put hands in between Seat Pad and Footrest or underneath.

  • Page 17: Staying Safe

    Staying Safe SAFETY INFORMATION To ensure safe use of the massage chair and avoid injury or unsafe conditions, please read and follow all instructions before using product. WARNING USE NOT RECOMMENDED FOR CERTAIN PERSONS Use of massage chair may not be safe or suitable for persons with certain medical conditions and could cause serious injury or death in some circumstances.
  • Page 18 CAUTION To avoid the risk of minor injury or discomfort, or damage to the massage chair or other property, please read and follow these instructions for safe use of massage chair: CAUTION - Do not stand or stack heavy objects on footrest. - Do not operate heating features of chair while under a blanket or pillow.
  • Page 19 Staying Safe WARNING Read and follow these instructions concerning safe use of the power cord and power unit to avoid possible electric shock, fire hazard, use of chair by and injury to unattended children, or damage to chair or other property. WARNING - To avoid risk of electric shock, connect this unit to a properly grounded outlet only.

  • Page 20: Fixing Issues

    The air hose is blocked clearout the blockage If problem remains, please contact Infinity for maintenance. Tip: Do not attempt to repair this product yourself, our company shall not be liable for the injury or damage caused by any servicing without authorizations. Thank you for you cooperation...
  • Page 21 5 minutes then plug back in and power back up to see if it self-healed. If you are still having an issue, give Infinity a call at 603-910-5000. Q: I can never seem to get in my Infinity Massage chair, someone is always in it.

  • Page 22: Troubleshooting And Safety

    Troubleshooting and Safety If the chair is performing abnormal, making noise or can’t be operated, please unplug first and call our service department. STATUS POSSIBLE REASON · Unable to adjust Roller Width · The Width can’t be adjusted when Roller reaches above shoulder, due to the Shoulder Detection feature.

  • Page 23: Product Specifications

    Product Specifications Product Name : IT-9810 Model Number : 19810111 Voltage : 110~120Vac,60Hz Max. Consuption : 150W Timer Range : 5-30 minutes Product size : Almost 120X90X112 /cm Weight : About 70Kgs...
  • Page 24 Warranty This Infinity Massage Chairs is protected by Infinity’s 5 Year U.S Residential Limited Warranty. For more information, scan the QR code below and click on the Infinity Care Residential Warranty tab. SCAN CODE...
  • Page 25 72 Stard Road, Seabrook, NH 03874 (603) 910-5000 www.infinitymassagechairs.com Version 2.1 Version 1.1...
