OPERATION AND PARTS MANUAL
MODEL MQ41TDH
DIESEL POWERED TRASH PUMP
(HATZ 1D81Z DIESEL ENGINE)
Revision #3 (04/02/07)
To find the latest revision of this
publication, visit our website at:
www.multiquip.com
THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MQ41TDH and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MULTIQUIP MQ41TDH

Summary of Contents for MULTIQUIP MQ41TDH

  • Page 1 OPERATION AND PARTS MANUAL MODEL MQ41TDH DIESEL POWERED TRASH PUMP (HATZ 1D81Z DIESEL ENGINE) Revision #3 (04/02/07) To find the latest revision of this publication, visit our website at: www.multiquip.com THIS MANUAL MUST ACCOMPANY THE EQUIPMENT AT ALL TIMES.
  • Page 3 NOTE PAGE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. 3 (04/02/07) — PAGE 3...

  • Page 4: Training Checklist

    TRAINING CHECKLIST TRAINING CHECKLIST This checklist will lists some of the minimum requirements for machine maintenance and operation. Please detach it and make copies. Use this checklist whenever a new operator is to be trained or it can be used as a review for more experienced operator’s. s ’...

  • Page 5: Daily Pre-Operation Checklist

    . e r a r t e l i i l r . s t COMMENTS: MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 5...

  • Page 6: Table Of Contents

    Trailer-1 Kit Assy..........40-41 Whl-2 Kit Assy............ 42-43 TNKZZ Assy. (Optional Fuel Tank) ..... 44-45 NOTE Specification and part number are subject to change without notice PAGE 6 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 7: Rules For Safe Operation

    ■ Topping-off to filler port is dangerous, as it tends to spill fuel. safety decals when they become difficult read. ■ Always check the machine for loosened threads or bolts before starting. PAGE 8 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 8 Failure to maintain water inside the pump housing will cause severe damage to the pump. ■ In winter drain water from pump housing to prevent freezing. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 9...

  • Page 9: Operation And Safety Decals

    Machine Safety Decals The MQ41TDH Centrifugal Trash pump is equipped with a number of safety decals. These decals are provided for operator safety and maintenance information. The illustration below shows these decals as they appear on the machine. If any of these decals become unreadable, replacements can be obtained from your dealer.

  • Page 10: Specifications

    6081 for the sound pressure level (L) at the operator's location. The sound measurements were obtained with the unit operation on pavement at nominal speed. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 11...

  • Page 11: Components

    MQ41TDH — COMPONENTS Figure 1. Pump Components PAGE 12 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 12: General Information

    For example, in Flagstaff, Arizona where the elevation is approximately 7,000 feet, the pump would have a suction lift of only 18 feet rather than the 25 feet at sea level. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 13...

  • Page 13: Application

    2 inches (50 mm) in diameter. DO NOT set strainer on bottom of water bed. Placing the strainer above the water bed will prevent the pump from drawing in excessive amounts of sand and foreign debris. Figure 2. Pump Application PAGE 14 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 14: Pre-Setup (Pump)

    Place hose so that it lays as straight as it is possible on the ground. Remove any twists or sharp bends from hose which may block the flow of water. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 15...

  • Page 15: Initial Start-Up (Engine)

    HOLDER Figure 3. Dipstick Location 3. Verify that oil level (Figure 4) is maintained between the two notches on the dipstick. Figure 4. Engine Oil Dipstick PAGE 16 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 16 Refer to the fuel tank capacity listed on page 11, Specification Table1. 4. Tighten fuel tank cap securely after filling. Figure 5. Speed Control Lever MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 17...

  • Page 17: Troubleshooting (Pump)

    (See Fig. 5) When pump is not in use, keep ignition starting key in a safe place, out of the reach of unauthorized persons. PAGE 18 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 18 Replace the drain plug NOTE tightly. Add oil through the filler hole. When re-installing fuel filter, please note the arrows indicating the direction of fuel flow. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 19...
  • Page 19 DO NOT blow high pressure, high velocity compressed air thru the air filter cartridge. The high velocity air will damage the filter, which will then allow contaminates to pass into the engine. PAGE 20 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 20 NOTE 25 in. Hg (inches of mecury) translates into 25 feet of lift at sea level . MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 21...
  • Page 21 MQ41TDH — MAINTENANCE Figure 12. Pump Vacuum Tester PAGE 22 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 22 Cover suction and discharge ports with duct tape to prevent any foreign matter from falling into pump. Cover pump and engine with plastic covering or equivalent and store in a clean, dry place. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 23...
  • Page 23 . t r r e l l l e . r e i t c s ' r . l a PAGE 24 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 24: Troubleshooting (Engine)

    . l i l i o f i r ? l i . y r MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 25...
  • Page 25 . l a PAGE 26 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 26 NOTE PAGE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 27...
  • Page 27 A blank entry generally indicates that the item is not sold separately or is not sold by Multiquip. Other entries will be clarified in the “Remarks” Column. PAGE 28 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 28: Suggested Spare Parts

    50268600 TEMPERATURE SWITCH NOTE Part numbers on this Suggested Spare Parts List may supercede/ replace the P/N shown in the text pages of this book. MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 29...

  • Page 29: Nameplate And Decals

    MQ41TDH — NAME PLATE AND DECALS NAMEPLATE AND DECALS PUMP SKID PAGE 30 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 30 PLATE, SERIAL NO ....1 ....CONTACT MQ SERVICE DEPT. W/MODEL & S/N 920203290 DECAL: CAUTION ..... 1 ....REPLACES 920202510 DCLMQ41THD KIT, DECAL ........ 1 ....INCLUDES ITEMS W/ SEE DECAL ILLUSTRATIONS ON PAGE 10 MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 31...

  • Page 31: Pump Assy

    MQ41TDH — PUMP ASSY. PUMP ASSY. PAGE 32 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 32 NUT, M12 ............14 ..REPLACES 1501201 0131151060 SCREW CASING COVER 0451250100 LOCK WASHER 0105051225 BOLT (IMPELLER) 014208025 ALLENHEAD BOLT, 8 X 25 - 1.25MM 030208200 LOCK WASHER, 8MM MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 33...
  • Page 33 MQ41TDH — PUMP ASSY. (CONTINUED) PUMP ASSY. (CONTINUED) PAGE 34 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 34 0105051065 BOLT (CASING COVER) 0451250100 LOCK WASHER ..........12 ..REPLACE S2001002 0105091025 BOLT (VOLUTE CASING) ......2 ..REPLACES 4111025 0105091020 BOLT (VOLUTE CASING) MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 35...

  • Page 35: Skid Assy

    MQ41TDH — SKID ASSY. SKID ASSY. PAGE 36 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 36 BOLT BATTERY HOLD DOWN 4419200580 SPACER 6109100 HOLD DOWN BATTERY 0723302546 SHOCK MOUNT ..........6 ..REPLACES 030216400 6119102 LIFTING BAIL 6119101A PUMP & ENGINE BASE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 37...

  • Page 37: Trailer-10 Assy

    MQ41TDH — TRAILER -10 ASSY. TRAILER-10 ASSY. PAGE 38 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 38 9509 SCREW, TEK 12 x 3/4 SELF TAP 9510 KIT, LIGHT - TRAILER 9512 PLUG, WIRING 9514 LIGHT ASSY., LICENSE PLATE 1U1304 WHEEL LUG NUT MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 39...

  • Page 39: Trailer-1 Kit Assy

    MQ41TDH — TRAILER -1 KIT ASSY. TRAILER -1 ASSY. CAUTION : NEVER use the Trailer-1 for "HIGHWAY" towing purposes. This trailer is intended for jobsite towing ONLY! PAGE 40 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 40 AXLE AND HUB ASSY. 6109104 PIPE STAND 6109146 LOCATING PIN 0183 COTTER PIN 1U1304 WHEEL LUG NUTS 6109105 TOW BAR COUPLER 6119101A PUMP & ENGINE BASE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 41...

  • Page 41: Whl-2 Kit Assy

    MQ41TDH — WHL-2 KIT ASSY. WHL-2 KIT ASSY. PAGE 42 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 42 SPLIT PIN 6109210 CAP SCREW 8151 WASHER, FLAT, 3/4 IN. 4119149 TIRE/WHEEL 4119208 WASHER, FLAT 6109160 6119102 LIFTING BAIL 6109180 WASHER, SPRING 4119102 HANDLE 4119103 AXLE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 43...

  • Page 43: Tnkzz Assy. (Optional Fuel Tank)

    LINE TO FUEL PUMP NOTES: CAP IS INCLUDED WITH TANK. IF A GAP EXISTS BETWEEN THE TANK BRACKET AND THE THE TANK SHIM USING P/N 6109170. PAGE 44 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 44 WASHER 3/8 6109170 WASHER 020310080 NUT, HEX M1O ZN PLATED 2101030 BOLT, HEX 10 X 30 84454 ELBOW BRASS 1/4 MALE NPT X 5/16 2001040 BOLT MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 45...
  • Page 45 HATZ 1D81Z ENGINE — CRANKCASE ASSY. CRANKCASE ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 46 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 46 HEX SCREW M 9 X 28 50357700 GRUB SCREW M 8 X 10 04087400 STUD M 6 X 22 04084500 SEALING RING 04084500 SEALING RING MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 47...

  • Page 47: Table Of Contents ..................................................... 6 Crankcase Assembly

    HATZ 1D81Z ENGINE — CRANKCASE ASSY. (EXTERNAL PARTS) CRANKCASE ASSY.(EXTERNAL PARTS) LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 48 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 48 SHIM 1.2 0..3 04069800 SHIM 1.05 0..1 04069900 SHIM 1.20 0..1 04065400 CYLINDER HEAD BOLT 04084000 LIFTING SPRING 50139200 STUD M 6 X 16 05068900 GASKET MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 49...
  • Page 49 HATZ 1D81Z ENGINE — CRANKSHAFT ASSY. CRANKSHAFT ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 50 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 50 STUBSHAFT ITALIA 23 03962700 FITTING KEY A6.35 X 63 50017800 WOODRUFF KEY 4 X 6.5 50414400 WEAR SLEEVE 62 X 12.7 0..1 01512001 KIT, CRANKSHAFT REPLACEMENT60-81 1 MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 51...
  • Page 51 HATZ 1D81Z ENGINE — CAMSHAFT ASSY. CAMSHAFT ASSY. PAGE 52 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 52 COUNTER BALANCE ......1 ..CANNOT BE PURCHASED SEPARATELY 50324900 WOODRUFF KEY 3 X 3.7 PIN ............2 ..CANNOT BE PURCHASED SEPARATELY COUNTERBALANCE ......1 ..CANNOT BE PURCHASED SEPARATELY MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 53...
  • Page 53 HATZ 1D81Z ENGINE — PISTON/RINGS ASSY. PISTON/RINGS ASSY. PAGE 54 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 54 CONROD ASSY........1 ....INCLUDES ITEMS W/% CONROD ..........1 ....CANNOT BE PURCHASED SEPARATELY 04032200 BUSH FOR CONROD 04001800 CONROD SCREW 04001900 BIG END BEARING 04033100 ROD BEARING -0.5 MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 55...
  • Page 55 HATZ 1D81Z ENGINE — CYLINDER HEAD ASSY. K= HOT TEMPERATURE FELT 100g PAGE 56 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 56 CYL. HEAD SCREW 258 MM 04006111 VALVE COVER GASKET 16> 01245410 VALVE COVER 50081200 LOCK WASHER A6 50170800 ALLEN SCREW M 6 X 25 04008100 LIFTING BRACKET MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 57...
  • Page 57 HATZ 1D81Z ENGINE — CYLINDER HEAD ASSY. CYLINDER HEAD ASSY. PAGE 58 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 58 SHIM 0.2 04097200 PRES. SPRING DECOMPR. 04038500 OIL RESTRICTOR VALVE ASSY. 04104300 OIL RESTRICTOR VAVE 01557600 GEARWHEEL F. DECOMPR... 1 ... INCLUDES ITEMS W/% MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 59...
  • Page 59 HATZ 1D81Z ENGINE — FLYWHEEL ASSY. FLYWHEEL ASSY. PAGE 60 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 60 04002000 PRESSURE SPRING 04002000 PRESSURE RING 50330300 O-RING 23 X 3 04007410 PLATE 50363100 ALLEN SCREW M 10 X 40 04007131 FLYWHEEL , ELECTRIC START MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 61...
  • Page 61 HATZ 1D81Z ENGINE — OIL PUMP ASSY. OIL PUMP ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 62 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 62 ALLEN SCREW M 6 X 25 50051000 ALLEN SCREW M 6 X 30 50084901 PIN 8 X 12 03798720 GEARWHEEL 50260501 ROLL PIN 2 X 10 04046000 CIRCLIP MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 63...
  • Page 63 HATZ 1D81Z ENGINE — TIMING COVER ASSY. TIMING COVER ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 64 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 64: Timing Cover Assembly

    TIMING COVER ASSY. NO. 3 .... 1 ..INCLUDES ITEMS W/# TIMING COVER ........ 1 ..CANNOT BE PURCHASED SEPARATELY 04052400 NOZZLE 03797412 COVER F. OIL PUMP MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 65...

  • Page 65: Fuel Device

    HATZ 1D81Z ENGINE — FUEL DEVICE ASSY. FUEL DEVICE ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 66 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 66 CONNECTING NIPPLE 50357200 HOSE CLIP 5SKZ 50399801 CLAMP 11.3 50399900 CLAMP 9.5 01459700 CLIP 01498902 PIST. + CYL. EXTR. FUEL ....1 ... INCLUDES ITEMS W/# MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 67...
  • Page 67 HATZ 1D81Z ENGINE — AIR DUCTING ASSY. AIR DUCTING ASSY. PAGE 68 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 68 GRUB SCREW M 8 X 6 03225504 NAME PLATE 40002500 POP RIVET 2.4 MM 04080400 COVER F. BLOW DUCTING 50170900 LOCK WASHER 6 50177100 HEXSCREW M 6 X 16 MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 69...
  • Page 69 HATZ 1D81Z ENGINE — BREATHER ASSY. BREATHER ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 70 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 70 GRUB SCREW M 6 X 45 05038000 HOSE 7 X 12 X 120 50388300 HOSE CLAMP 01475600 ADJUST. SCREW ID 1D81 ....1 ... INCLUDES ITEMS W/ MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 71...
  • Page 71 HATZ 1D81Z ENGINE — FUEL TANK ASSY. FUEL TANK ASSY. PAGE 72 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 72: Fuel Tank Assembly

    CLAMP 21 MM 05044001 HOSE 10/12 MM 05036900 HOSE CLIP 05043900 WATER SEPARATOR 50414800 CLOS. SCREW M 10 01519401 WATER SEPARATOR ......1 .... INCLUDES ITEMS W/ MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 73...
  • Page 73 HATZ 1D81Z ENGINE — FUEL PUMP ASSY. FUEL PUMP ASSY. PAGE 74 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 74 50328300 HEXAGON NUT M6 50001200 JOINT A 14 X 18 50006400 BANJO BOLT A8 50015900 RING PIECE N W 8 01468801 FUEL PIPE 49062501 DIAPHRAM MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 75...
  • Page 75 HATZ 1D81Z ENGINE — AIR FILTER ASSY. AIR FILTER ASSY. L= SILICON SEALER PAGE 76 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 76: Air Filter Assembly

    RING PIECE N W 4 50006200 BANJO BOLT A 4 50062400 JOINT A 10 X 13.5 50358400 STRAP 01499800 MAINT. INDICATOR ......1 ..INCLUDES ITEMS W/# MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 77...
  • Page 77 HATZ 1D81Z ENGINE — EXHAUST SILENCER ASSY. EXHAUST SILENCER ASSY. J= HOT TEMPERATURE PASTE PAGE 78 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)

  • Page 78: Exhaust Silencer

    FLAT WASHER 10.5 40028600 HEX NUT M 10 03997100 EXHAUST TUBE 01191901 MUFFLER GUARD ID 05034200 LOCK WASHER 50255700 ALLEN SCREW M 6 X 12 MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 79...
  • Page 79 HATZ 1D81Z ENGINE — STARTER/ALTERNATOR ASSY. STARTER/ALTERNATOR ASSY. PAGE 80 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 80 INSULATING DISC 50426800 TOOTH LOCK J 10.5 03814200 INSULATING TUBE 50016800 DISC 8.4 50275300 HEXSCREW M 8 X 35 01430900 BATTERY CABLE MINUS 01193401 ELECTRIC WIRE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 81...
  • Page 81 HATZ 1D81Z ENGINE — INSTRUMENT BOX ASSY. INSTRUMENT BOX ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 82 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 82 01433601 WIRING HARNESS 05027800 INTERMED. PIECE. TEMP 50001000 JOINT A 10 X 16 01475200 TEMP. SWITCH 12 V “C” ....1 ... INCLUDES ITEMS W/# MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 83...

  • Page 83: Lifting Magnet/Stop Device

    HATZ 1D81Z ENGINE — LIFTING MAGNET/STOPDEVICE ASSY. LIFTING MAGNET/S TOP DEVICE ASSY. LETTERS IN BOLD INDICATE TYPE OF BONDING ADHESIVE TO BE USED. D= LOCTITE 221 H= SILICON E= LOCTITE 648 PAGE 84 —MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07)
  • Page 84 CLAMP 8-12 03999001 FUEL HOSE 7/70 03996600 SHAFT 03565400 RUBBER SLEEVE 05069200 BUSH F. BELT TENSION 04021700 LEVER 50144500 WASHER 50328300 HEXAGON NUT M6 50248900 BELLOWS MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 85...
  • Page 85 NOTE PAGE MQ41TDH TRASH PUMP — PARTS & OPERATION MANUAL — REV. #3 (04/02/07) — PAGE 87...
  • Page 86 © COPYRIGHT 2007, MULTIQUIP INC. Multiquip Inc and the MQ logo are registered trademarks of Multiquip Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their respective owners and used with permission.
