Summary of Contents for Visioneer ROADWARRIOR 4D

  • Page 1 User’s Guide Mac Users...
  • Page 2 IF YOU FIND PHYSICAL DEFECTS IN THE MATERIALS OR THE WORKMANSHIP USED IN MAKING THE PRODUCT DESCRIBED IN THIS DOCUMENT, VISIONEER WILL REPAIR, OR AT ITS OPTION, REPLACE THE PRODUCT AT NO CHARGE TO YOU, PROVIDED YOU RETURN IT (POSTAGE PREPAID, WITH PROOF OF YOUR PURCHASE FROM THE ORIGINAL RESELLER) DURING THE 90-DAY PERIOD AFTER THE DATE OF YOUR ORIGINAL PURCHASE OF THE PRODUCT.
  • Page 3 IS POSA L If you are managing the disposal of your Visioneer® product, please note that the product may contain lead, mercury, Perchlorate, and other materials whose disposal may be regulated due to environmental considerations. The presence of these materials is fully consistent with global regulations applicable at the time that the product was placed on the market.
  • Page 4 Please read the following instructions carefully before operating the machine and refer to them as needed to ensure the continued safe operation of your machine. Your Visioneer® product and supplies have been designed and tested to meet strict safety requirements. These include safety agency evaluation and certification, and compliance with electromagnetic regulations and established environmental standards.

  • Page 5: Table Of Contents

    Visioneer® RoadWarrior 4D Specifications ........
  • Page 6 ® ISIONEER ARRIOR ABLE OF ONTENTS Appendix A: Copy Regulations ..........33 United States.

  • Page 7: Welcome

    E L C O M E ’ S IN THE Before proceeding, check the contents of the box. If items are missing or damaged, contact the dealer where you purchased the scanner. Visioneer® RoadWarrior 4D Carrying Bag USB Cable Quick Install Guide Carrier Sheet...

  • Page 8: System Requirements

    ® ISIONEER ARRIOR ELCOME YSTEM EQUIREMENTS ® ® ■ Apple Mac OS X operating system ® ■ 1.6 GHz or faster PowerPC G5 or 1.83 GHz or faster Intel Core Processor ■ DVD-ROM drive ■ Universal Serial Bus (USB) 2.0 port (Hi-Speed USB) ■...

  • Page 9: Unpack The Scanner

    ® ELCOME ISIONEER ARRIOR Universal Serial Bus (USB) port—connects the scanner to the computer. Paper feed—place an item face up in paper feed for scanning. ● Scanner lid—can be pulled away from the scanner body to open the scanner for cleaning. ●...

  • Page 10: Safety Lock

    ® ISIONEER ARRIOR ELCOME Remove the foam strip(s) from inside the scanner. Gently close the scanner lid. Press down on both sides of the lid until you hear a click as the arms lock the scanner lid in place. Safety Lock Your scanner may have a slot for installing a Kensington®...

  • Page 11: Installation

    N S T A L L A T I O N Insert the installation disc into your computer’s DVD-ROM drive. Double-click the disc icon that appears on the desktop. A window opens showing the disc contents. Note: The software provided with your scanner may differ slightly from the list shown in the window. NSTALL THE RIVER Double-click the scanner .pkg file to start the driver installer.
  • Page 12 NSTALLATION Click Continue. On the Visioneer License Agreement window, read the license agreement. If you accept the terms, select Agree and continue with the installation. If you choose not to accept the license agreement, close the installation window. The scanner driver will not be installed.

  • Page 13: Connect The Usb Cable

    ® NSTALLATION ISIONEER ARRIOR If you are prompted for a password, input the name and password for a user that has permission to install software on your computer. Click Close on the installation complete window. You can now connect the scanner to your computer. Technical Note: the Installation Complete screen may be blank when installing on OS X (10.9).

  • Page 14: Scanning Utility

    NSTALLATION Turn on the scanner power (if applicable). CANNING TILITY From the Finder window for the installation disc, click and drag the Visioneer Scan Utility icon to your desktop. Software About the Software Visioneer Scan Utility This utility uses the scanner’s TWAIN interface for scanning. You can select a destination folder on your computer and save the image as any one of several popular image file formats (PNG, JPG, TIF, Multi-Page TIF, PDF, Multi-Page PDF, etc...).

  • Page 15: Register Your Scanner

    ® NSTALLATION ISIONEER ARRIOR ■ RoadWarrior 4D guide—instructions for scanner setup, installation, operation, maintenance, safety, and warranty. ■ TWAIN scanning guide—instructions for scanning using the TWAIN interface. EGISTER CANNER Registering your scanner is important as it provides you with access to our free telephone support service.
  • Page 16 ® ISIONEER ARRIOR NSTALLATION ’ CANNER UIDE...

  • Page 17: Loading Documents To Scan

    O A D I N G O C U M E N T S T O C A N UPPORTED OCUMENT YPES You can scan the following types of documents and cards with this scanner. ■ Document size ● Minimum size (width x length) – 1.5 x 1.5 inches (38 x 38 mm) ●...

  • Page 18: Using The Carrier Sheet

    ® ISIONEER ARRIOR OADING OCUMENTS TO Using the Carrier Sheet WARNING: the plastic bag for the carrier sheet poses a suffocation hazard. Keep the bag away from children. Take the carrier sheet out of its plastic bag. We recommend that you keep the bag and place the carrier sheet back in the bag when you are done scanning.

  • Page 19: Documents To Avoid Scanning

    ® OADING OCUMENTS TO ISIONEER ARRIOR OCUMENTS TO VOID CANNING The documents in this list can be scanned, but please note that scanning documents of this type will reduce the life of the scanner. Maintenance will be required more often. These types of documents will jam more frequently and damage to the original documents may occur.

  • Page 20: Scanning Interfaces

    ® ISIONEER ARRIOR OADING OCUMENTS TO CANNING NTERFACES ■ TWAIN Interface—this option uses your scanner’s TWAIN interface to scan. The TWAIN scanning interface can be accessed from any TWAIN scanning application you have installed on the computer. ■ ICA Interface—this option uses the Apple Mac Image Capture Application (ICA) interface to scan. You can access the ICA interface from the Image Capture application.

  • Page 21: Maintenance

    A I N T E N A N C E This section contains information about maintenance, troubleshooting, scanner specifications, and spare parts. AFETY RECAUTIONS When servicing the scanner you should take the following precautions to ensure your safety and prevent damage to the scanner.

  • Page 22: Clearing Paper Jams

    ® ISIONEER ARRIOR AINTENANCE LEARING APER If your scanner stops scanning due to a paper jam, a warning opens after a few moments. WARNING: do NOT attempt to remove the jammed page with the scanner closed. Damage to the scanner will occur if forcing the page out of the scanner. Follow the instructions below to remove the jammed page.
  • Page 23 ® AINTENANCE ISIONEER ARRIOR You should clean the inside of the scanner at least once a week or as needed depending on how often the scanner is used. If cleaning the scanner does not resolve any image quality issues, please follow the instructions in the next section for calibrating the scanner.

  • Page 24: Additional Cleaning Method

    ® ISIONEER ARRIOR AINTENANCE Using the cleaning cloth, wipe down all surfaces in the scanner. Make sure to clean the glass in the underside of the scanner lid and the feed rollers in the body of the scanner. Gently close the scanner lid. Press down on both sides of the lid until you hear a click as the arms lock the scanner lid in place.
  • Page 25 The calibration routine will fail and indicate the failed calibration by flashing a red LED on the scanner. A calibration page was included with your scanner, if you do not have one available, you can order a replacement from the Parts & Accessories page for your scanner at www.visioneer.com. To calibrate the scanner: Open the scanner’s interface.

  • Page 26: Calibration Error

    ® ISIONEER ARRIOR AINTENANCE Place the calibration page, with the black bar face up, into the scanner. The scanner pulls in the calibration page and feeds it slowly through the paper path. When calibration is complete the scanner will clear the calibration page out of the scanner. Remove the calibration page when the utility prompts you to.

  • Page 27: Setting Auto Power Off

    ® AINTENANCE ISIONEER ARRIOR ETTING OWER The scanner will automatically power off after a specified period of inactivity. Open the scanner’s TWAIN interface and click on the Settings tab. Adjust the Power Off timeout field and then click on OK to save the changes. When the scanner is powered off, firmly press the button on the scanner to turn the scanner on.

  • Page 28: Status Light Troubleshooting

    ® source for images. Make sure Visioneer RoadWarrior 4D is selected as the scanner. Problem: My computer keeps giving me out of hard drive space error messages. The minimum requirement of free hard drive space is for the installation of the software and basic, low resolution, scanning.

  • Page 29: Visioneer® Roadwarrior 4D Specifications

    ® AINTENANCE ISIONEER ARRIOR Error Codes If your scanner experiences a hardware error, the status light will blink red. It will flash in a numerical sequence, pause, then repeat the same number of flashes. The number of times the light blinks between pauses indicates the error code number.

  • Page 30: Visioneer® Roadwarrior 4D Parts List

    ® ISIONEER ARRIOR AINTENANCE Scanner Specifications Certifications UL/C-UL, FCC Class B, CE, CB, USB-IF, WEEE, RoHS, ENERGY STAR Operating Temperature 50° ~ 95° F (10° ~ 35° C without condensation) Relative Humidity 15% ~ 85% (@25° C without condensation) Scanner Dimensions Width 11.5 inches (291 mm) Depth...
  • Page 31 ® AINTENANCE ISIONEER ARRIOR Part Name Part Number Carrier sheet 05-0912-000 Micro USB cable 35-0249-000 Calibration page 05-0914-000 Cleaning cloth 05-0913-000 ’ CANNER UIDE...
  • Page 32 ® ISIONEER ARRIOR AINTENANCE ’ CANNER UIDE...

  • Page 33: Appendix A: Copy Regulations

    A : C P P E N D I X O P Y E G U L A T I O N S NITED TATES Congress, by statute, has forbidden the reproduction of the following subjects under certain circumstances. Penalties of fine or imprisonment may be imposed on those guilty of making such reproductions. ■...

  • Page 34: Canada

    ® A: C ISIONEER ARRIOR PPENDIX EGULATIONS ■ Passports. (Foreign Passports may be photographed.) ■ Immigration Papers. ■ Draft Registration Cards. ■ Selective Service Induction Papers that bear any of the following Registrant’s information: Earnings or Income Dependency Status Court Record Previous military service Physical or mental condition Exception: U.

  • Page 35: Other Countries

    ® A: C PPENDIX EGULATIONS ISIONEER ARRIOR THER OUNTRIES Copying certain documents may be illegal in your country. Penalties of fine or imprisonment may be imposed on those found guilty of making such reproductions. ■ Currency notes ■ Bank notes and cheques ■...
  • Page 36 ® A: C ISIONEER ARRIOR PPENDIX EGULATIONS ’ CANNER UIDE...
  • Page 37 I N T E L L I G E N T S C A N N I N G S O L U T I O N S 05-0920-000 Copyright ©2015 Visioneer, Inc.
