2.2 Loading the SD-card

Camera uses SDHC grade cards of 4 to 32GB capacity. Standard speed SD cards or micro
SD cards fitted in SD card adapters should NOT BE USED.
THE POWER BUTTON MUST BE IN THE OFF POSITION BEFORE REMOVING OR
With the SD card label facing out insert the card into the slot on the underside of the front
panel, push card into the carrier until it clicks into place. It is recommended that SD cards
be formatted in the camera prior to use; this will erase any old data on the card.

2.3 Power Button

Power button is a slide switch with three positions (
1. OFF Camera is OFF safe to remove/ install SD card or batteries
2. SETUP LCD display visible – access menu options/ view photos/ take snapshot
3. ON Camera is ON & operational - ready to record
Slide the Power Button to the centre SET UP position. The camera will power up & beep 3
times, the LCD screen will come on with the Live Video View visible.
If no SD-card is present or the loaded card is write protected the camera will emit an audible
warning beep then shut down. Slide the Power Button to the left, OFF position & install a
new SD Card before powering the camera up again.
2.4 Manually take a Snapshot or record video
The camera can also be used to take still images or record video. Slide the Power
button to the SETUP position.
Press camera icon button;
with each button press. In video mode video press the button to start recording, press the
button again to end video recording.
www.starweb.com.au Covert Security & Wildlife Monitoring T.C. - User Manual March.2013
INSTALLING THE SD CARD
If the camera is in photo mode a single image is recorded
):
left to right
