Summary of Contents for Covert NBF30
- Page 1 NBF30 Instruction Manual...
-
Page 2: Table Of Contents
3.1 Viewing album ........10 3.2 Manually taking photos or video ..11 3.3 Firmware Update……………………….……12 3.4 Tricks and Tips/Troubleshooting..………….13 3.5 Covert Scouting Cameras Warranty…………14 3.6 Covert Warranty Policy and Procedure………15 3.7 Covert International Warranty Procedure……16 Appendix 1: Technical Specifications ....21... -
Page 3: General Description
1 General Description Congratulations on your purchase of your NBF30 Covert Scouting Camera. NBF30 is a powerful and reliable high-performance scouting camera. Features: ⚫ 30MP invisible IR camera; ⚫ 0.22s trigger speed; ⚫ HD resolution: 720P/1080P ⚫ NO Glow black LEDs ⚫... - Page 4 1.IR Flash LEDs 2. Light Sensor 3. MIC 4. PIR Sensor 5. Lens 6. LCD 7. Keyboard 8. Switch 9. Batteries 10. 6V Jack 11. USB 12. SD Slot 13. Standard Tripod Mount...
-
Page 5: Installing Batteries
2.1 Installing batteries This camera can function on 8 AA batteries. Negative battery terminal always contacts the spring. To ensure maximum performance of the camera and prevent battery leakage, we recommend using new batteries. Note: ⚫ Do not mix different types of batteries ⚫... -
Page 6: Power Switch And Buttons
Power switch and buttons Buttons Instruction OFF: Power off（Please remove batteries when not in use）; SETUP: Setting the CAM; ON: Working mode (the screen off). 1. Enter to settings page. 2. Exit the settings page. MENU 3. Enter album operation page. 4. -
Page 7: Setting Map
3. Menu Value Decrease. ◄ 1.Left selection 1. In main screen, press ► to take photo or video manually. (Click again to stop the video.) 2. Right selection. 3. Adjust the speed of video playing. 2.4 Setting map MODE Camera Mode Photo/Video/Photo+Video PIR Interval 00 min 05 sec- 59 min 59 sec... - Page 8 card from filling up with too many redundant images. Time Lapse：When choosing time lapse, the camera takes photos or videos even when it is not triggered by heat or motion. It’s useful for constant monitoring of an area. Work Time: If you only want your camera to be on during part of the day each day you can set the Work Time function.
- Page 9 SYSTEM YY / MM / DD Set Clock HH : MM 12 HOUR Time Format 24 HOUR Camera Name Rename Option Time Stamp Off/On Password Password：0 0 0 0 Auto PowerOff Off/3m/5m/10m Language English SD overwrite Off/On Format SD card No/YES Default No/YES...
-
Page 10: Other Operations
Camera Name: Camera can be renamed with a max of 13 characters. Password：Make sure you write down your password or save it to your mobile phone so you can access your camera if you ever forget your password. 3 Other operations 3.1 Viewing album Make sure the Selector switch is set to SETUP. -
Page 11: Manually Taking Photos Or Video
This option deletes the photos that are showing. Press the ▼ button to highlight the Delete one or Delete all option and press OK. Use the ▲ and ▼ button to navigate to YES and press OK. If you do not want to delete, press the MENU button again to exit. -
Page 12: Firmware Update
time counter on the screen when you first press the ►. 3.3 FW Update Copy the new FW file onto the SD card, insert the SD card into your camera. Push the switch to SETUP. Press MENU into MENU mode, highlight System option and press OK, choosing FW Update option and press OK and choose Yes to update. -
Page 13: Tricks And Tips/Troubleshooting
• Use the Covert Tree60 mounting system to mount the camera up higher pointing down on them for a better look. Works great when you don’t have a straight tree to attach to. -
Page 14: Covert Scouting Cameras Warranty
Customer Service at 877-462-1799 or e-mail us at support@dlccovert.com 3.5 Covert Scouting Cameras Warranty: Covert Scouting Cameras warranties this product for a period of two years from the date of purchase. This warranty only covers manufacturer’s defects and does not cover damage caused by misuse or abuse of the product. -
Page 15: Covert Warranty Policy And Procedure
Please explain to the technician what issues you are having with your camera. 2. If you are asked to return your camera to Covert Scouting Cameras, you will be responsible for the cost of shipping to Covert Scouting Cameras. In... -
Page 16: Covert International Warranty Procedure
1. Outside the US, service is the available through the distributor/reseller of purchase. 2. All returns must have an RA# provided by Covert. Copy of Proof of Purchase is required for all returns. 3. Covert is not responsible for lost or damaged products incurred during the shipping process. - Page 17 Covert. Return and claims will be handled according to the current Covert Scouting Cameras, Inc. procedure. These warranties shall not apply to any defect, failure or damage caused by improper use or improper or inadequate maintenance and care. Covert shall not be obligated under these warranties: a.
- Page 18 To provide software or firmware updates or upgrades. Any service identified in the above list and provided by Covert at the Customer’s request shall be invoiced to the customer, at Covert’s then current rates for parts, labor and shipping. THE ABOVE WARRANTIES ARE GIVEN BY...
- Page 19 TO THE EXTENT ALLOWED BY LOCAL LAW, EXCEPT FOR THE OBLIGATIONS SPECIFICALLY SET FORTH IN THIS WARRANTY STATEMENT, IN NO EVENT SHALL COVERT AND ITS VENDORS BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES (INCLUDING LOSS OF PROFITS) WHETHER...
- Page 20 ADVANCE NOTICE OF THE POSSIBILITY OF SUCH DAMAGES.
-
Page 21: Appendix 1: Technical Specifications
Appendix Ⅰ: Technical Specifications Picture Resolution 2/5/8/18/30MP Lens F/NO=2.8 FOV=65° IR-Flash 100 feet Display Screen 2.4’ LCD Memory Card Up to 32GB Video Resolution 720P, 1080P PIR Sensor Multi Zone PIR Sensitivity Adjustable Trigger Time 0.22s Operation/Storage -4 - +140°F / -22 - +158°F Tem.
