Lincoln Electric Python Push-Pull Gun Specification Sheet

CobraMAX
Push-Pull Gun
When you're ready to move up to a push-pull wire feeding system, consider the CobraMAX.
This easy-to-handle air-cooled gun shares many of the same features with our top-of-the-line
Python push-pull gun, including an ergonomic handle design, fingertip controls, and foolproof
set up. With a fixed gooseneck design and 150 amp 100% duty cycle rating, the CobraMAX is
an ideal push-pull gun.
Processes
MIG Pulsed
Advantage Lincoln
• Superior push-pull wire feeding technology for smooth
feeding and minimized damage to the wire.
• Lightweight, ergonomic handle - weight distribution is equally
balanced front and back for better feel and control.
• Sturdy bottom-mounted trigger can be operated with either
hand.
• Fine adjustment of wire feed speed is easily accomplished
using the multi-turn adjustment dial.
• Flip-up drive roll cover for easy access to wire. Quick wire
release for easy wire adjustments.
• Complete with a knurled drive roll and a grooved idler roll,
which will handle both steel and aluminum wire
from .030-1/16" (0.8-1.6mm) diameter.
• Interchangeable contact tips, drive and idler rolls, and
conduits between Prince ® XL, CobraMAX
guns – no need to stock multiple consumables.
CobraMAX Push-Pull Gun Selector Guide
Air Cooled
50 75 100 125 150
™
TM , and Python ®
3/64" (1.1mm)
.035" (0.9mm)
.030" (0.8mm)
175 200 225 250 275 300
ACCESSORIES
Description
Output Input
Recommended Expendable Parts Options
Drive Roll Kits, Drive and Idler Rolls, Contact Tips, Copper Gas
Cups, Gun Liners, Conduits
Recommended Wire Feeder Options
Cobramatic ® Wire Feeder
Recommended Power Source Options
CV-250, CV-300, CV-400, CV-655, Power MIG® 300
V350-PRO, DC-400, DC-600, DC-655
Order
K2252-1 Air-Cooled, 15 ft. (4.5m)
K2252-2 Air-Cooled, 25 ft. (7.6m)
(1)
Does not require Cobramatic. Requires Connection Kit (K2154-1).
Note: CobraMAX TM gun is a registered trademark of MK Products, Inc.
Duty Cycle Limitation
Amps
Allowable time within a 10 minute period
the maximum rated amperage can be maintained
1/16" (1.6mm)
Wire Diameter
325 350 375 400 425
Welding Current
(amps)
42
VAC
(1)
,
100% 50%
NOTE: Wire Diameter and
Current may vary depending
on your particular Power
Supply and Welding Voltage.
Wire Diameter and Current
based on 5356 Aluminum Wire.
Publication E12.12 12/03
