- Page 1 IM3023 09/2019 REV04 POWERTEC 305S, 365S, 425S, 505S OPERATOR’S MANUAL ENGLISH Lincoln Electric Bester Sp. z o.o. ul. Jana III Sobieskiego 19A, 58-263 Bielawa, Poland www.lincolnelectric.eu...
-
Page 2: Table Of Contents
12/05 THANKS! For having chosen the QUALITY of the Lincoln Electric products. Please Examine Package and Equipment for Damage. Claims for material damaged in shipment must be notified immediately to the dealer. For future reference record in the table below your equipment identification information. Model Name, Code &... -
Page 3: Technical Specifications
Technical Specifications NAME INDEX POWERTEC 305S K14060-1 POWERTEC 365S K14061-1A POWERTEC 425S K14062-1A POWERTEC 505S K14063-1A INPUT Input Voltage U EMC Class Frequency 305S 365S 230 / 400V±10% 50 / 60 Hz 3 - phase 425S 505S Input Power at Rated Output Input amperes I cos φ... -
Page 4: Electromagnetic Compatibility (Emc)
Lincoln Electric Before installing the machine, the operator must check the work area for any devices that may malfunction because of electromagnetic disturbances. -
Page 5: Safety
Failure to follow the instructions in this manual could cause serious personal injury, loss of life, or damage to this equipment. Read and understand the following explanations of the warning symbols. Lincoln Electric is not responsible for damages caused by improper installation, improper care or abnormal operation. -
Page 6: Introduction
MGAW (MIG/MAG) Slow-blow fuse - 3A The following equipment has been added to Recommended equipment, which can be bought by user, POWERTEC 305S: was mentioned in the chapter "Suggested Accessories". Operator’s Manual Installation and Operator Instructions Read this entire section before installation or operation Duty cycle and Overheating of the machine. - Page 7 (most Innershield applications), set the switch to "-". The input cable must be disconnected from the mains supply and the machine switched OFF. POWERTEC 305S Remove the left side panel from the machine. Reconnect X11 and X12 according to the diagram...
- Page 8 12. Hole Plug: For CO gas heater socket (see "Suggested Accessories" chapter - K14009-1 CO Heater Connection Kit). POWERTEC 305S Machine and Circuit Protection The POWERTEC S is protected against overheating, overload and accidental short-circuits If the machine is overheated, the thermal protection circuit will decrease the output current to 0.Overheating...
- Page 9 We respond to our customers based on the best Keep the machine clean. Using a dry (and low information in our possession at that time. Lincoln Electric pressure) airflow, remove the dust from the external is not in a position to warrant or guarantee such advice, case and from the cabinet inside.
-
Page 10: Weee
12/05 Part List reading instructions Do not use this part list for a machine if its code number is not listed. Contact the Lincoln Electric Service Department for any code number not listed. Use the illustration of assembly page and the table below to determine where the part is located for your particular code machine. -
Page 11: Suggested Suggested Accessories
Source/wire feeder cable (gas). Available in 5, 10, 15m Source/wire feeder cable (gas and water). Available in 5, 10 or K10347-PGW-xxM 15m. K14011-1 Work lead 3m (POWERTEC 305S) K14018-1 Work lead 3m (POWERTEC 365S, 425S) K14033-1 Work lead 3m (POWERTEC 505S)
