Carrier 58UHV Installation, Start-Up, And Operating Instructions Manual

Upflow/horizontal variable-speed, 2-stage induced-combustion gas furnaces sizes 060-120, series 110 and 120

Hide thumbs Also See for 58UHV:

Installation, start-up, and operating instructions manual (28 pages)

User's information manual (9 pages)

Installation, start-up, and operating instructions manual (28 pages)

Table of Contents

Quick Links

SAFETY CONSIDERATIONS

Installation and servicing of heating equipment can be hazardous

due to gas and electrical components. Only trained and qualified

personnel should install, repair, or service heating equipment.

Untrained personnel can perform basic maintenance functions

such as cleaning and replacing air filters. All other operations must

be performed by trained service personnel. When working on

heating equipment, observe precautions in the literature, on tags,

and on labels attached to or shipped with the unit and other safety

precautions that may apply.

Follow all safety codes. In the United States, follow all safety

codes including the National Fuel Gas Code (NFGC) NFPA

54-1996/ANSI Z223.1-1996 and the Installation Standards, Warm

Air Heating and Air Conditioning Systems (NFPA 90B)

ANSI/NFPA 90B. In Canada, refer to the CAN/CGA-B149.1- and

.2-M95 National Standard of Canada, Natural Gas and Propane

Installation Codes (NSCNGPIC). Wear safety glasses and work

gloves. Have fire extinguisher available during start-up and

adjustment procedures and service calls.

Recognize safety information. This is the safety-alert symbol

When you see this symbol on the furnace and in instructions or

manuals, be alert to the potential for personal injury.

→

Understand the signal words DANGER, WARNING, CAUTION

and NOTE. These words are used with the safety-alert symbol.

DANGER identifies the most serious hazards which will result in

severe personal injury or death. WARNING signifies a hazard

which could result in personal injury or death. CAUTION is used

to identify unsafe practices which would result in minor personal

injury or product and property damage. NOTE is used to highlight

suggestions which will result in enhanced installation, reliability,

or operation.

These instructions cover minimum requirements and conform to

existing national standards and safety codes. In some instances,

these instructions exceed certain local codes and ordinances,

especially those that may not have kept up with changing residen-

tial construction practices. We require these instructions as a

minimum for a safe installation.

Form 58UHV-4SI

58UHV, 58UXV

ama

A PP R O VED

REGISTERED

QUALITY SYSTEM

Pg 1

7-99

Replaces: 58UHV-3SI

Table of Contents

Summary of Contents for Carrier 58UHV

Page 1: Table Of Contents
58UHV, 58UXV Upflow/Horizontal Variable-Speed, 2-Stage Induced-Combustion Gas Furnaces Visit www.carrier.com Installation, Start-Up, and Operating Instructions Sizes 060-120, Series 110 and 120 NOTE: Read the entire instruction manual before starting the installation. This symbol → indicates a change since the last issue.
Page 2: Electrostatic Discharge (Esd) Precautions Procedure
→ 2. Firmly touch a clean, unpainted, metal surface of the furnace The models 58UHV and 58UXV Series 110 or 120 Furnaces are chassis which is close to the control. Tools held in a person’s available in sizes 60,000 through 117,000 Btuh input capacities.
Page 3: Clearances To Combustibles
MINIMUM INCHES CLEARANCE TO COMBUSTIBLE CONSTRUCTION This forced air furnace is equipped for use with natural This furnace is approved for UPFLOW and HORIZONTAL gas at altitudes 0-5,500 ft (0-1,675 m) above sea level. The installations. high-altitude conversion kit MUST be installed above 5,500 ft (1,675 m).
Page 4: Location
clearance-to-combustible construction label. This furnace shall not be installed directly on carpeting, tile, or any combustible material other than wood flooring. LOCATION RELATIVE TO COOLING EQUIPMENT The cooling coil must be installed parallel with or on downstream side of furnace to avoid condensation in heat exchangers. When FRONT installed parallel with a furnace, dampers or other means used to °F...
Page 5: Unconfined Space
For Example: 1. All air from inside the structure requires 2 openings (for 58UHV AND 58UXV FURNACES MINIMUM SQ FT WITH structures not usually tight): HIGH-STAGE INPUT BTUH 7-1/2 FT CEILING a.
Page 6: Air Ducts
Table 2—Minimum Free Area Of Combustion Air Opening* AIR FROM INDOOR OUTDOOR AIR THROUGH OUTDOOR AIR THROUGH OUTDOOR AIR THROUGH 58UHV/58UXV UNCONFINED SPACE VERTICAL DUCTS HORIZONTAL DUCTS SINGLE DUCT FURNACE HIGH-FIRE Free Area Free Area of Round Free Area of...
Page 7: Filter Arrangement
FILTER ARRANGEMENT Never operate unit without a filter or with filter access door removed. A failure to follow this warning could result in fire, personal injury, or death. WASHABLE The factory-supplied filter(s) are shipped in the blower compart- FILTER ment. Determine location for the filter and move filter retaining hardware, if necessary, before attaching the return-air duct.
Page 8 LINE CONTACT ONLY PERMISSIBLE BETWEEN LINES FORMED BY INTERSECTIONS OF THE TOP AND TWO SIDES OF THE FURNACE JACKET, BUILDING JOISTS, STUDS, OR FRAMING. ENTRY MANUAL SHUTOFF GAS VALVE 30-IN. MIN WORK AREA FLUE VENT 24″ 6 ″ M SHEET METAL 24″...
Page 9: Leveling Legs (If Required)
Step 5—Gas Piping Emissions control devices located at the heat exchanger inlets MUST be removed for propane installations (Refer to gas conversion kit for instructions). Gas piping must be installed in accordance with national and local codes. Refer to the NFGC. Canadian installations must be installed in accordance with NSCNGPIC and all authorities having juris- diction.
Page 10: Electrical Connections
SUPPLY The cabinet MUST have an uninterrupted or unbroken ground according to NEC ANSI/NFPA 70-1999 and Canadian Elec- trical Code, CSA C22.1 or local codes to minimize personal injury if an electrical fault should occur. This may consist of electrical wire or conduit approved for electrical ground when MANUAL SHUTOFF installed in accordance with existing electrical codes.
Page 11 Table 5—Electrical Data OPERATING VOLTS— MAX WIRE MAX FUSE OR VOLTAGE RANGE UNIT SIZE HERTZ— UNIT WIRE LENGTH (FT)‡ CKT BKR AMPS† PHASE AMPS GAGE Max* Min* 060-12 115—60—1 10.1 080-16 115—60—1 10.6 100-20 115—60—1 12.6 120-20 115—60—1 13.9 * Permissible limits of the voltage range at which the unit will operate satisfactorily. †...
Page 12: Venting
2. Humidifier (HUM) Screw terminals (HUM and C 24V) are provided for 24-v humidifier connection. The terminals are energized with 24v, 0.5-amp maximum when the gas valve is energized. → Do not connect furnace control HUM terminal to HUM (humidifier) terminal on Thermidistat™, Zone Controller, or similar device.
Page 13: Adaptive Heating Mode
Table 6—Setup Switch Description SETUP NORMAL DESCRIPTION SWITCH NO. POSITION OF USE Turn switch on to obtain only high-gas-heat operation on any call SW-1 OFF (Staged Gas Heat) for heat regardless of whether R-W/W1, or R-W/W1, -W2 is Only High-Gas Heat closed.
Page 15: Non-Adaptive Heating Mode
(1.) When in low-gas heat and thermostat is satisfied, b. Two-Speed Cooling Outdoor Unit (See Fig. 14 for thermo- blower will continue to operate at low-gas heat CFM stat connections.) until the blower-off delay reaches 90 sec. If blower-off (1.) The thermostat closes the R to G-and-Y1 circuits for delay switches (on the 2-stage furnace control) are set low cooling or closes the R to G-and-Y1-and-Y/Y2 for more than 90 sec, blower will operate at the...
Page 16: Defrost Mode
needed for 2-speed heat pumps. See 2-speed heat pump Installation 6. Defrost Instructions to determine whether a standard or dual-fuel heat a. When furnace control R to W/W1-and-Y/Y2 circuits are pump thermostat is required and for thermostat connections. closed, furnace control CPU continues BLWM operation at a.
Page 17: Start-Up Procedures
1. Component test—The furnace features a component test system to help diagnose a system problem in the case of a c. Verify furnace model. Table 11 can only be used for model component failure. To initiate the component test procedure, 58UHV and 58UXV Furnaces.
Page 18 Table 8—Gas Heat Airflow—Nominal CFM at up to 0.70-in. w.c. ESP (With Filter) GAS HEAT TEMP RISE* GAS HEAT TEMP RISE (°F)† GAS HEAT AIRFLOW (CFM) FURNACE SIZE Jumper Position High-Stage Low-Stage High-Stage Low-Stage Red Wire Violet Wire M-HI 1085 1250 1135 M-HI...
Page 19 Table 10—Heat Pump Comfort Heating Nominal CFM at up to 0.70-in. w.c. ESP (With Filter) AC/HP JUMPER POSITION: HP—CMFT HEAT PUMP—COMFORT, HEATING AIRFLOW Airflow Single-Speed Two-Speed (High/Low) Selection Furnace Cool CFM Per Ton Jumper Position Cool CFM Per Ton Cool Size Size Jumper Position Jumper...
Page 20 Table 11—Model 58UHV and 58UXV Orifice Size* and Manifold Pressure for Correct Input (Tabulated Data Based on 20,000 Btuh High Heat/13,000 Btuh Low Heat per Burner Derated 4% for Each 1000 Ft Above Sea Level) SPECIFIC GRAVITY OF NATURAL GAS...
Page 21 Table 11—Model 58UHV and 58UXV Orifice Size* and Manifold Pressure for Correct Input (Continued) (TABULATED DATA BASED ON 20,000 BTUH HIGH HEAT/13,000 BTUH LOW HEAT PER BURNER DERATED 4% FOR EACH 1000 FT ABOVE SEA LEVEL) SPECIFIC GRAVITY OF NATURAL GAS...
Page 22 Table 11—Model 58UHV and 58UXV Orifice Size* and Manifold Pressure for Correct Input (Continued) (TABULATED DATA BASED ON 20,000 BTUH HIGH HEAT/13,000 BTUH LOW HEAT PER BURNER DERATED 4% FOR EACH 1000 FT ABOVE SEA LEVEL) SPECIFIC GRAVITY OF NATURAL GAS...
Page 23 correct size. Never redrill an orifice. A burr-free and squarely Table 13—Altitude Derate Multiplier for U.S.A. aligned orifice hole is essential for proper flame characteristics. ALTITUDE % OF DERATE MULTIPLIER (FT) DERATE FACTOR FOR U.S.A.* e. Move setup switch SW-2 to OFF position after completing 0—2000 1.00 low-heat adjustment.
Page 24: Set Temperature Rise
BURNER FLAME EXAMPLE: (High-heat operation at 0—2000 ft altitude) BURNER Furnace input from rating plate is 85,000 Btuh Btu heating input = Btu/cu ft X cu ft/hr Heating value of gas = 1050 Btu/cu ft Time for 1 revolution of 2-cu ft dial = 90 sec Gas rate = 80 cu ft/hr (from Table 12) Btu heating input = 1050 X 80 = 84,000 Btuh In this example, the orifice size and manifold pressure adjustment...
Page 25: Checklist
has shut off burners, the return-air opening should be un- c. After normal start-up, allow furnace to operate for 2 blocked. By using this method to check the limit control, it can minutes, then block flue outlet 100 percent. Furnace should be established that the limit is functioning properly and will cycle off within 2 minutes.
Page 28 Manufacturer ____________ Model Number Copyright 1999 CARRIER Corp. • 7310 W. Morris St. • Indianapolis, IN 46231 58uhv3si Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations. Book 1 4 PC 101 Catalog No.
